H
REMOTE CONTROL IN/OUT connectors
Used to connect to a Marantz amplifier that is compatible with the
remote control function. (v p. 32)
I
EXTERNAL/INTERNAL switch
Turn this switch to “EXTERNAL” to operate the unit by pointing the
remote control at the amplifier connected to this unit using the remote
control connection. (v p. 32)
J
Wi-Fi CONNECT iOS button
Connects to iOS.
(See the separate “Quick Start Guide”.)
K
AC inlet (AC IN)
Used to connect the power cord. (v
p. 33)
L
Bluetooth/wireless LAN antenna connectors
Used to connect the included external antennas for Bluetooth/wireless
connectivity when connecting to a network via wireless LAN, or when
connecting to a handheld device via Bluetooth. (v p. 29)
A
Place the external antennas for Bluetooth/wireless connectivity
evenly over the screw terminal of rear.
B
Turn clockwise until the antennas is fully connected.
C
Rotate the antenna upwards for best reception.
.
