Marantz NR1605/U1B - AUDIO_VIDEO PCB ASSY

AUDIO_VIDEO
AUDIO
_
VIDEO PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D5221-5223 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 3
D5229 963201500170D LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
IC5200 963239000650S R2A15218FP-U00R 8CH-VOL WITH 11 INPUT QFP100P J084152180010S 1
IC5201 963232100400S UTC4580E SOP8 DUAL OP AMP J121458001010S 1
IC5202 00D2631193902 BD3812F-E2 2CH-VOL SOP14P J084381200010S 1
IC5401 963235100700S NJM2595M-TE1 DMP16 5-INPUT 3-OUTPUT VIDEO SWITCH J171259500010S 1 *
IC5402 963235100630S NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
Q5202 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5205 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5206,5207 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5209 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5210 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5212 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5214 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5215,5216 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5218 943214500030S INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5219 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5220 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q5221 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5222,5223 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5224 943214500020S 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
U5500-5503 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 4
ZD5200 963202500290D ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
RESISTOR GROUP
R5200 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5203,5204 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R5205-5212 nsp 10K-J,1/16W-1608REEL C20001036M160S 8
R5213-5218 nsp 470-J,1/16W-1608REEL C20004716M160S 6
R5220 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5221 nsp 820K-J,1/16W-1608REEL C20008246M160S 1
R5225 nsp 820K-J,1/16W-1608REEL C20008246M160S 1
R5227 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5228,5229 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5232 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R5233 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5234 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R5235 nsp 820K-J,1/16W-1608REEL C20008246M160S 1
R5247 nsp 820K-J,1/16W-1608REEL C20008246M160S 1
R5248 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5250 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5251 nsp 820K-J,1/16W-1608REEL C20008246M160S 1
R5253 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R5255 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R5257,5258 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5259 nsp 820K-J,1/16W-1608REEL C20008246M160S 1
R5260 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R5261,5262 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5263 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5264 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R5266 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R5267,5268 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5269,5270 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R5271 nsp 220-J,1/16W-1608REEL C20002216M160S 1
R5272,5273 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R5274 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R5276 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5277-5288 nsp 470K-J,1/16W-1608REEL C20004746M160S 12
R5289 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R5290,5291 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5292,5293 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R5295,5296 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R5297,5298 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R5299 nsp 220-J,1/16W-1608REEL C20002216M160S 1
R5300 nsp 47-J,1/16W-1608REEL C20004706M160S 1
R5301,5302 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R5303 nsp 220-J,1/16W-1608REEL C20002216M160S 1
R5304 nsp 47K-J,1/16W-1608REEL C20004736M160S 1
R5305,5306 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R5308 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5309 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R5310 nsp 47K-J,1/16W-1608REEL C20004736M160S 1
R5311 nsp 47-J,1/16W-1608REEL C20004706M160S 1
R5312,5313 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R5314 nsp 220-J,1/16W-1608REEL C20002216M160S 1
R5317 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5319 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R5320,5321 nsp 100K-J,1/16W-1608REEL C20001046M160S 2
R5322 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R5323 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R5324,5325 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5326 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R5328 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5329-5331 nsp 100K-J,1/16W-1608REEL C20001046M160S 3
R5332 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5333,5334 nsp 470-J,1/16W-1608REEL C20004716M160S 2
R5335 nsp 220-J,1/16W-1608REEL C20002216M160S 1
R5336 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R5337,5338 nsp 1K-J,1/16W-1608REEL C20001026M160S 2
R5340,5341 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R5342 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R5343 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R5344 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R5345 nsp 2.2K-J,1/16W-1608REEL C20002226M160S 1
R5346,5347 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R5348,5349 nsp 100-J,1/16W-1608REEL C20001016M160S 2
R5352 nsp 33K-J,1/16W-1608REEL C20003336M160S 1
R5353 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R5354 nsp 18K-J,1/16W-1608REEL C20001836M160S 1
