Marantz NR1605/U1B - REG_SMPS_FCNT PCB ASSY

REG_SMPS_FCNT
REG
_
SMPS
_
FCNT PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D4140-4146 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 7
D4147 963201500160D 1N4007 52REEL 1000V 1A U/F K000400700220S 1
! D4147 203050019501S
A
P01C-V1 52RE-AX FAST RECOVERY RECTIFIER DIODE
S
N K050000015000S 1
D4148 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 1
D4149 963204500210D S30SC6MT 60V 30A TO-3P(MTO-3PT) SHINDENGEN K120300600010S 1
D4150 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4600 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 1
D4602,4603 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
D4604-4607 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 4
D4612-4627 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 16
D4629-4632 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 4
! IC4140 231010091708S TOP258MG SDIP10 OFF-LINE POWER SUPPLY IC J122258001010S 1
! IC4142 00D2623047008 PC123X2YFZ
(
DIP4P SHARP
)
K614123000010S 1
IC4143 212050010508S KIA2431AP,0.7W TO-92 J126243118010S 1
IC4600 00D2631100005 KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4602 00D2631099006 KIA7905PI,20W-TO220IS MOLD J126790500070S 1
IC4603 00D2631251006 KIA7908PI,20W-TO220IS J126790800060S 1
IC4604 00D2631100005 KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4605 00D2631100050 KIA7808API,20W-TO220IS J126780800050S 1
IC4608 00D9600100301 KIA7812API,20W-TO220IS MOLD J126781200040S 1
TR4140 963222500150D KMB2D0N60SA N-CH MOSFET 60V SOT23 J543206005510S 1
TR4142 963213500170D KTC3198G,0.6W/TO92-REEL J5023198G0000S 1
ZD4147-4149 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH U/F K06039R044522S 3
ZD4150-4157 963202500350D ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 8
ZD4158 963202500370D ZJ39B-0.5W/5MA-52MM SEMTECH K06039R044522S 1
ZD4159 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH K06005R644522S 1
ZD4160 963202500320D ZJ5.6B-0.5W/5MA-52MM SEMTECH U K06005R644522S 1
ZD4160 963202500340D ZJ5.6B-0.5W/5MA-52MM SEMTECH N K06015R044522S 1
ZD4160 963202500310D ZJ5.6B-0.5W/5MA-52MM SEMTECH F K06005R144522S 1
RESISTOR GROUP
R4141,4142 nsp 1M-J,1/5W-52RE-AX C00001056P520S 2
R4143 nsp 330K-J,1/5W-52RE-AX C00003346P520S 1
R4145 nsp 1M-J,1/16W-1608REEL C20001056M160S 1
R4147 nsp 270K-J,1/16W-1608REEL U/F C20002746M160S 1
R4147 nsp 56K-J,1/16W-1608REEL N C20005636M160S 1
R4148,4149 nsp 2.2M-J,1/5W-52RE-AX U/F C00002256P520S 2
R4150 nsp 1M-J,1/5W-52RE-AX U/F C00001056P520S 1
R4151 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R4152 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4153 nsp 6.8-J,1/5W-52RE-AX C0006R806P520S 1
R4154 nsp 10-J,1/16W-1608REEL C20001006M160S 1
R4155 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4156 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4157 nsp 56-J,1/5W-52RE-AX C00005606P520S 1
R4158 nsp 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4159 nsp 5.6K-J,1/5W-52RE-AX C00005626P520S 1
R4160 nsp 22K-F,1/16W-1608REEL C20002234M161S 1
R4161 00D2472041967 6.8K-D,1/16W-1608REEL C20006821M160S 1
R4164 nsp 1M-J,1/5W-52RE-AX C00001056P520S 1
CAPACIITORS GROUP
! C4140,4141 963134011730S DE1B3KX471KB4BL01 AC250V BULK MURAT
A
D00847127H010S 2
! C4142 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURAT
A
D008103589010S 1
! C4143 ns
p
0.1UF-K/275V BULK X2 MPX104K3ID2 P=15MM CARL
I
D02110407H010S 1
C4145-4147 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 3
! C4148,4149 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURAT
A
N D008103589010S 2
C4151 943134501590S 100UF-M/200V,16*20 BULK NHA SY U/F D04110108G000S 1
C4151 963134010200S 100UF-M/400V,18*31.5 BULK NHA SY N D04110108K000S 1
C4152 963134010210S 47UF-M/25V,5*11-5RE NXA SY D041470084050S 1
C4153 963132010120S DEHR33A102KB2B D00810207Q010S 1
C4154 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4155 963134010190S 10UF-M/50V,5*11-5RE NXA SY D041100087050S 1
! C4156 963132011930S DE1E3KX222MB4BL01 AC250V BULK MURAT
A
D00822248H010S 1
C4159,4160 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4161 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4162-4164 963134010220S 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 3
C4166 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4600 963134502440S 470UF-M/50V,12.5*15 BULK MHA SY D040471087070S 1
C4602 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4604,4605 00D9630333203 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 2
C4606,4607 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4608,4609 90M-OA000500R 4700UF-M/25V(MHA),16*25 P=7.5 L.BLK D040472084240S 2
C4610 963134011290S 4700UF-M/16V,16*25-L.BLK SMS 5.0MC SY D040472083020S 1
C4611 00D9630217002 3300UF-M/16V,12.5*25L.BLK SHL 5.0MC SY D040332083010S 1
C4612,4613 963134502400S MI-0.1UF-J/50V-5RE D020104167050S 2
C4646 963134010700S 2200UF-M/25V,16*25-L.BLK SMS 5.0MC SY D040222084030S 1
C4648 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
OTHER PARTS GROUP
BKT4141 nsp VSX523K/CUXESM(PIONEER) BURRING HOLE SPTE 0.8t/SCR 4010215796000S 1 *
BKT4142 nsp AVR3300(E3)(DENON) SPTE 0.8t/SCREW 4010210196000S 1
BKT4602 nsp AVR3300(E3)(DENON) SPTE 0.8t/SCREW 4010210196000S 1
CLP4605-4607 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 3
CLP4609-4611 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 3
CLP4613 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4141 nsp 120MM/5P TJC2508-05=CKM2509HV-05 WH1007#22 L000121050160S 1 *
CN4600,4601 nsp C125Z2-09 9P BtoB SOCKET(FEMALE) P=1.25MM L109012520930S 2 *
CN4607 nsp
120MM/4P 20010HS-04=CKM2002HV-04 WH1007#26 연접
L002121040110S 1
CN4615 nsp
120MM/11P 20010HS-11=CKM2002HV-11 WH1007#26 연접
L002121110041S 1
! CP4142 ns
p
LWB1143-02P 7.92MM HEADER,VER,2CK
T
L108011430210S 1
CP4600,4601 nsp C125Z1-09 9P BtoB HEADER(MALE) P=1.25MM L109012510920S 2
CP4607 nsp YMW025-08R DIP ST L102025080020S 1 *
CP4611 nsp C125Z1-21 21P BtoB HEADER(MALE) P=1.25MM L109012512120S 1
CP4612 nsp C125Z1-11 11P BtoB HEADER(MALE) P=1.25MM L109012511120S 1
CP4613 nsp C125Z1-17 17P BtoB HEADER(MALE) P=1.25MM L109012511720S 1
CP4614 nsp C125Z1-11 11P BtoB HEADER(MALE) P=1.25MM L109012511120S 1
CP4615 nsp 20010WR-04A00 DIP4P RIGHT ANGLE L101200100420S 1
! F4140 963652010510S T2A/250V-IVBSUCPCcUR S50
6
U/F N751502001160S 1
! F4140 963132011940S DE2F3KY103MB3BM02 AC250V BULK MURAT
A
N D008103589010S 1
F4140_1 nsp PI5.2-REEL G645000050010S 1
