Marantz NR1606/U1B - Page 144

W9864G6KH-5 Block diagram
W9864G6KH
Publication Release Date: Nov. 12, 2013
- 6 - Revision A02
6. BLOCK DIAGRAM
CLK
CKE
A10
CLO CK
BUFFER
COMMA ND
DECO DER
ADDRESS
BUFFER
REFRESH
CO UNT ER
CO LUM N
CO UNT ER
CONTROL
SIGN AL
GENER ATOR
MODE
REGIST ER
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #2
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #0
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #3
DATA CO NTROL
CI RCUI T
DQ
BUFFER
COLUMN DECODER
SENSE AMPLIFIER
CELL ARRAY
BANK #1
NOT E:
The cell array configuration is 4096 * 256 * 16
