Marantz NR1606/U1B - SPK_SCNT PCB Assy

SPK_SCNT
SPK_SCNT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4003 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4006 963203500300D D,RECTIFIER BRIDGE DIODE BRIDGE D10SB60 600V/10A STRAIGHT TYPE K047100600220S 1
D4007-4020 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 14
DZ4000 963202500330D D,ZENER ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
DZ4001 963202500290D D,ZENER ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
IC4000 963232100400S IC,LINEAR OP UTC4580E SOP8 DUAL OP AMP J121458001010S 1
Q4000 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 1
Q4002 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 1
Q4004 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 1
Q4006 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 1
Q4008 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 1
Q4011 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 1
Q4606 963212500280S SEMI,CHIP TR/PNP 2SA 2SA2166 0.2W/SC-59 ISAHAYA J520216601210S 1
Q4607 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
ZD4057 963202500290D D,ZENER ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
ZD4700 963202500400S D,ZENER ZJ16B-0.5W/5MA-52MM SEMTECH K06016R044522S 1
RESISTOR GROUP
R4000-4006 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 7
R4007-4013 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 7
R4016,4017 nsp R,METAL FILM 100PPM 470-J,1W-R.REEL C060047165050S 2
R4020 nsp R,METAL FILM 100PPM 10K-J,1/4W-R.REEL C060103063050S 1
R4022 963125500070D R,METAL FILM 100PPM 1.1K-J,1W-R.REEL C060011265050S 1
R4024 963125500070D R,METAL FILM 100PPM 1.1K-J,1W-R.REEL C060011265050S 1
R4027 963125500070D R,METAL FILM 100PPM 1.1K-J,1W-R.REEL C060011265050S 1
R4034-4040 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 7
R4041 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4042 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4043 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4044 nsp R,CARBON FILM 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4045 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R4046 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160S 1
R4047 nsp R,CHIP THICK 330K-J,1/16W-1608REEL C20003346M160S 1
R4048 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4049 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R4050 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4051 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4052,4053 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4055-4059 nsp R,CHIP THICK 0-J,1/8W-3216REEL C200000061301S 5
R4061 963129501010S R,CEMENT MPR 0.01-J/5W W14*H18 9MM PITCH C144R01069000S 1
R4636,4637 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 2
R4641 nsp R,CHIP THICK 3.3K-J,1/16W-1608REEL C20003326M160S 1
R4642 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
CAPACIITORS GROUP
C4000-4006 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 7
C4007 nsp C,ELECT GE 85C 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C4008-4014 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 7
C4015 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4016-4022 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL U, K, F D011222777160S 7
C4016-4022 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL N D011103777160S 7
C4030,4031 00D9639003107 C,ELECT GE 85C 6800UF-M/63V DL,30*40-VNSN SY D040682088010S 2
C4033 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4033 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4036 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4036 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4039 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4039 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4042 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4042 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4045 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4045 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4048 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4048 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4051 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K, F D011102777160S 1
C4051 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4053 nsp C,FILM POLYESTER RED-0.1UF-K/250V-5RE PCMT365 D02010407H080S 1
C4054 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL D011102777160S 1
C4056 nsp C,ELECT GE 85C 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080S 1
C4057 nsp C,FILM POLYESTER RED-0.1UF-K/250V-5RE PCMT365 D02010407H080S 1
C4058 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C4059 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4060,4061 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 2
C4062 nsp C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C4064 nsp C,CERAMIC CHIP T.C COG)10PF-J/50V-1608REEL D010100167161S 1
C4065 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C4066-4068 nsp C,ELECT GE 85C 1UF-M/100V,5*11-5RE.SMS SY D040010086060S 3
C4702 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C4704 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C4705 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL D011102777160S 1
OTHER PARTS GROUP
BKT4000 nsp TERMINAL MET37-0002/TAPIG EARTH FITTING 3790040886000S 1
CLP4000-4005 nsp CLAMP HMX9800(ON) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 6
CLP4008-4010 nsp CLAMP HMX9800(ON) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 3
CN4000 nsp CN,WIRE 230MM/5P YMH025-05=CKM2509HV-05 RD1569#22 105C L000231050090S 1
CN4003 nsp CN,WIRE 210MM/3P YMH025-03=CKM2509HV-03 WH1007#22 L000211030020S 1 *
CN4005 nsp CN,WIRE 220MM/8P YMH025-08=CKM2509HV-08 WH1569#22 105C L000221080090S 1
CN4602 nsp CN,WAFER 1.25B-2-13Y 13P BtoB SOCKET(FEMALE) P=1.25MM L109125421310S 1
CN4603 nsp CN,WAFER 1.25B-2-15Y 15P BtoB SOCKET(FEMALE) P=1.25MM L109125421510S 1
CN4605 nsp CN,WAFER 1.25B-2-23Y 23P BtoB SOCKET(FEMALE) P=1.25MM L109125422310S 1
CN4606 nsp CN,WAFER 1.25B-2-11Y 11P BtoB SOCKET(FEMALE) P=1.25MM L109125421110S 1
CP4000 nsp CN.WAFER 2.0MM 20010WS-13A00 DIP13P STRAIGHT L101200101310S 1
CP4001 nsp CN.WAFER 7.92MM LWB1143-07P 7.92MM HEADER,VER,7CKT L108011430710S 1
CP4002 nsp CN.WAFER 2.0MM 20010WS-04A00 DIP4P STRAIGHT L101200100410S 1
CP4603 nsp CN,WAFER 1.25B-2-23A 23P BtoB HEADER(MALE) P=1.25MM L109125322310S 1
CP4604 nsp CN,WAFER 1.25B-2-27A 27P BtoB HEADER(MALE) P=1.25MM L109125322710S 1
CP4607 nsp CN,WAFER 1.25B-2-15A 15P BtoB HEADER(MALE) P=1.25MM L109125321510S 1
CP4617 nsp CN.WAFER 2.0MM 20010WR-11A00 DIP11P RIGHT ANGLE L101200101120S 1
! F4000 963652010520S FUSE GLASS TUBE 20MM T6.3A/250V-IVBSUCPCcUR S506 N751506301160S 1
F4000A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F4000B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
! F4001 963652010520S FUSE GLASS TUBE 20MM T6.3A/250V-IVBSUCPCcUR S506 N751506301160S 1
F4001A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F4001B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
JACK4000 963646100530S TER,BOARD SCREW 6P JB-601AW-02
(
3RD/3BK 투명
)
G613602AW020YS 1
JACK4001 963643101960S TER,BOARD SCREW 8P JB-801AW-02
(
4RD/4BK 투명
)
G614801AW020YS 1
JACK4602 00D9630244703 JACK,D3.5 EARPHONE JACK PJ-308-02 G40130802000YS 1
