REG_SMPS_FCNT
REG_SMPS_FCNT PCB ASS'Y
※Parts indicated b
"ns
"on this table cannot be su
lied
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4140-4146 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 7
! D4147 203050019501S D,FAST RECOVERY AP01C-V1 52RE-AX FAST RECOVERY RECTIFIER DIODES K050000015000S 1
D4148 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4149 963204500210D D,SCHOTTKY S30SC6MT 60V 30A TO-3P(MTO-3PT) SHINDENGEN K120300600010S 1
D4150 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4600 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4604-4607 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 4
D4612-4627 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 16
D4629-4632 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 4
IC4140 943231102160S IC,LINEAR POWER TOP268VG eDIP-12 OFF-LINE POWER SUPPLY IC J122268001010S 1
! IC4142 00D2623047008 PHOTO,COUPLER PC123X2YFZ (DIP4P SHARP) K614123000010S 1
IC4143 212050010508S IC,LINEAR-REGULATOR KIA2431AP,0.7W TO-92 J126243118010S 1
IC4600 00D2631100005 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4602 00D2631099006 IC,LINEAR-REGULATOR KIA7905PI,20W-TO220IS MOLD J126790500070S 1
IC4603 00D2631251006 IC,LINEAR-REGULATOR KIA7908PI,20W-TO220IS J126790800060S 1
IC4604 00D2631100005 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4605 00D2631100050 IC,LINEAR-REGULATOR KIA7808API,20W-TO220IS J126780800050S 1
IC4608 00D9600100301 IC,LINEAR-REGULATOR KIA7812API,20W-TO220IS MOLD J126781200040S 1
U4002 943239100730S IC,LINEAR-RESET PST8448UR SYSTEM RESET SC-82AB MITSUMI J125844800010S 1
TR4141 943229500110S SEMI,FET CHIP INK0010AC1 N-CH MOSFET SC-59 ISAHAYA J543001012010S 1
TR4142 963213500170D SEMI,TR/GE NPN 2SC KTC3198G,0.6W/TO92-REEL J5023198G0000S 1
ZD4147-4149 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM SEMTECH U, F K06039R044522S 3
ZD4150 963202500970S D,ZENER ZJ27B-0.5W/5MA-52MM SEMTECH K06027R044522S 1
ZD4151-4157 963202500350D D,ZENER ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 7
ZD4158 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM SEMTECH K06039R044522S 1
ZD4159 963202500320D D,ZENER ZJ5.6B-0.5W/5MA-52MM SEMTECH K06005R644522S 1
ZD4160 963202501020S D,ZENER ZJ7.5B-0.5W/5MA-52MM SEMTECH U K06007R544522S 1
ZD4160 963202500340D D,ZENER ZJ15B-0.5W/5MA-52MM SEMTECH N, K K06015R044522S 1
ZD4160 963202500310D D.ZENER ZJ5.1B-0.5W K06005R144522S F K06005R144522S 1
ZD4162-4164 963202500960S D,ZENER ZJ12B-0.5W/5MA-52MM SEMTECH K06012R044522S 3
RESISTOR GROUP
R4141,4142 nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520S 2
R4143 nsp R,CARBON FILM 330K-J,1/5W-52RE-AX C00003346P520S 1
R4145 nsp R,CHIP THICK 1M-J,1/16W-1608REEL C20001056M160S 1
R4147 nsp R,CHIP THICK 270K-J,1/16W-1608REEL U, F C20002746M160S 1
R4147 nsp R,CHIP THICK 56K-J,1/16W-1608REEL N, K C20005636M160S 1
R4148,4149 nsp R,CARBON FILM 2.2M-J,1/5W-52RE-AX U, F C00002256P520S 2
R4150 nsp R,CARBON FILM 1M-J,1/5W-52RE-AX U, F C00001056P520S 1
R4151 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R4152 nsp R,CHIP THICK 10K-J,1/16W-1608REEL U, F C20001036M160S 1
R4152 nsp R,CHIP THICK 20K-J,1/16W-1608REEL N, K C20002036M160S 1
R4153 nsp R,CARBON FILM 6.8-J,1/5W-52RE-AX C0006R806P520S 1
R4154 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R4155 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4156 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4157 nsp R,CARBON FILM 56-J,1/5W-52RE-AX C00005606P520S 1
R4158 nsp R,CARBON FILM 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4159 nsp R,CARBON FILM 5.6K-J,1/5W-52RE-AX C00005626P520S 1
R4160 nsp R,CHIP THICK 22K-D,1/16W-1608REEL C20002231M161S 1
R4161 nsp R,CHIP THICK 6.8K-D,1/16W-1608REEL C20006821M160S 1
R4163 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4164 nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520S 1
CAPACIITORS GROUP
! C4140,4141 963134011730S C,CERAMIC AC(SAFETY) DE1B3KX471KB4BL01 AC250V BULK MURATA D00847127H010S 2
! C4142 963132011940S C,CERAMIC AC(SAFETY) DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 1
! C4143 nsp C,FILM P.PROPYLENE 0.1UF-K/275V BULK X2 MPX104K3ID2 P=15MM CARLI D02110407H010S 1
C4145-4147 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 3
! C4148,4149 963132011940S C,CERAMIC AC(SAFETY) DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 2
C4151 943134501590S C,ELECT GE 105C 100UF-M/200V,16*20 BULK NHA SY U, F D04110108G000S 1
C4151 963134010200S C,ELECT GE 105C 100UF-M/400V,18*31.5 BULK NHA SY N, K D04110108K000S 1
C4152 963134010210S C,ELECT GE 105C 47UF-M/25V,5*11-5RE NXA SY D041470084050S 1
C4153 963132010120S C,CERAMIC AC(SAFETY) DEHR33A102KB2B D00810207Q010S 1
C4154 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4155 963134010190S C,ELECT GE 105C 10UF-M/50V,5*11-5RE NXA SY D041100087050S 1
! C4156 963132011930S C,CERAMIC AC(SAFETY) DE1E3KX222MB4BL01 AC250V BULK MURATA D00822248H010S 1
C4159 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4160 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C4161 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4162-4164 963134010220S C,ELECT GE 105C 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 3
C4165,4166 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4167 nsp C,CERAMIC CHIP HIK X7R0.015UF-K/50V-1608REEL D011153777160S 1
C4170 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4600 963134502440S C,ELECT GE 85C 470UF-M/50V,12.5*15 BULK MHA SY D040471087070S 1
C4602 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4604,4605 nsp C,ELECT GE 85C 100UF-M/16V,5*11 KR3-016V101MC110-T/A5.0S KOSHIN D040101083650S 2
C4606,4607 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4608,4609 90M-OA000500R C,ELECT GE 85C 4700UF-M/25V(MHA),16*25 P=7.5 L.BLK D040472084240S 2
C4610 963134011290S C,ELECT GE 85C 4700UF-M/16V,16*25-L.BLK SMS 5.0MC SY D040472083020S 1
C4611 00D9630217002 C,ELECT GE 85C 3300UF-M/16V,12.5*25L.BLK SHL 5.0MC SY D040332083010S 1
C4612,4613 963133502380S C,FILM POLYESTER MI-0.1UF-J/100V-5RE HMM104J2AP050T DAEHUNG D02010416C250S 2
C4646 963134010700S C,ELECT GE 85C 2200UF-M/25V,16*25-L.BLK SMS 5.0MC SY D040222084030S 1
C4648 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
OTHER PARTS GROUP
BKT4141 nsp BRACKET VSX523K/CUXESM BURRING HOLE SPTE 0.8t/SCR 4010215796000S 1
BKT4142 nsp BRACKET AVRX2200WBKE3 SPCC t0.8+SN plating A4/SCREW 401021019600DS 1
BKT4602 nsp BRACKET AVRX2200WBKE3 SPCC t0.8+SN plating A4/SCREW 401021019600DS 1
CLP4600 nsp CLAMP HMX9800(ON) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLP4604 nsp CLAMP HMX9800(ON) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CLP4606,4607 nsp CLAMP HMX9800(ON) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 2
CN4141 nsp CN,WIRE 140MM/6P YMH025-06=CKM2509HV-06 WH1007#22 L000141060050S 1 *
CN4600,4601 nsp CN,WAFER 1.25B-2-9Y 9P BtoB SOCKET(FEMALE) P=1.25MM L109125420910S 2
CN4607 nsp CN,WIRE 2MM 120MM/4P 20010HS-04=CKM2002HV-04 WH1007#26 연접 L002121040110
1
CN4615 nsp CN,WIRE 2MM 120MM/11P 20010HS-11=CKM2002HV-11 WH1007#26 L002121110041S 1
! CP4142 nsp CN.WAFER 7.92MM LWB1143-02P 7.92MM HEADER,VER,2CKT L108011430210S 1
CP4600,4601 nsp CN,WAFER 1.25B-2-9A 9P BtoB HEADER(MALE) P=1.25MM L109125320910S 2
CP4607 nsp CN.WAFER 2.5MM YMW025-08R DIP ST L102025080020S 1
CP4611 nsp CN,WAFER 1.25B-2-21A 21P BtoB HEADER(MALE) P=1.25MM L109125322110S 1
CP4613 nsp CN,WAFER 1.25B-2-25A 25P BtoB HEADER(MALE) P=1.25MM L109125322510S 1
CP4614 nsp CN,WAFER 1.25B-2-11A 11P BtoB HEADER(MALE) P=1.25MM L109125321110S 1
CP4615 nsp CN.WAFER 2.0MM 20010WR-04A00 DIP4P RIGHT ANGLE L101200100420S 1
! F4140 963652010510S FUSE GLASS TUBE 20MM T2A/250V-IVBSUCPCcUR S506 U, F N751502001160S 1
! F4140 963652010500S FUSE GLASS TUBE 20MM T1.6A/250V-IVBSUCPCcUR S506 N, K N751501601160S 1
! F4141 963652010520S FUSE GLASS TUBE 20MM T6.3A/250V-IVBSUCPCcUR S506 U, F N751506301160S 1
! F4141 963652010910S FUSE GLASS TUBE 20MM T3.15A/250V-IVBSUCPCcUR S506 N, K N751503151160S 1
! F4600 963644101950S FUSE,MICRO 2.5A 250V SS-5 TIME DELAY RADIAL LEADED FUSE G658252250050S 1
3
To Next Page
