Marantz NR1606/U1B - FRONT PCB Assy

FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4400,4401 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 2
D4409,4410 963209003510S D,ESD CHIP CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 2
D4411 963209500020S D,ESD CHIP CDS3C15GTA 1608REEL CERADIODE ESD B72500D0150A060 K067031500010S 1
D4412-4415 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 4
Q4400 00D9630226705 SEMI,TR/GE NPN 2SC KTC1027Y,1W/TO92L-REEL J5021027Y0020S 1
Q4401 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4402 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4403 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q4404 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4405 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q4406 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4407 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1
Q4408 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
ZD4400 963202500330D D,ZENER ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
ZD4401 963202500350D D,ZENER ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 1
ZD4402 963202500340D D,ZENER ZJ15B-0.5W/5MA-52MM SEMTECH K06015R044522S 1
ZD4404-4406 963202500310D D,ZENER ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 3
RESISTOR GROUP
R4400,4401 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R4402 00D9639006272 R,FIXED,M.O. RSD-R1-1WJ-4.7 3*9 P=5MM SMALL R.REEL N113135647920S 1
R4403 nsp R,CHIP THICK 0-J,1/16W-1608REEL U C20000006M160S 1
R4403 nsp R,CHIP THICK 1.2-J,1/16W-1608REEL N, K C2001R200M160S 1
R4405-4408 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 4
R4410 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4411-4414 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 4
R4415,4416 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 2
R4418,4419 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R4420 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4421-4423 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 3
R4424 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4425 nsp R,CHIP THICK 39K-J,1/16W-1608REEL C20003936M160S 1
R4426,4427 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R4428 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4429 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4430 nsp R,CARBON FILM 220-J,1/5W-52RE-AX C00002216P520S 1
R4431 nsp R,CHIP THICK 39K-J,1/16W-1608REEL C20003936M160S 1
R4433 nsp R,CHIP THICK 390-J,1/16W-1608REEL C20003916M160S 1
R4434 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4435-4437 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 3
R4439 nsp R,CHIP THICK 300-J,1/16W-1608REEL C20003016M160S 1
R4441 nsp R,CHIP THICK 39K-J,1/16W-1608REEL C20003936M160S 1
R4442,4443 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 2
R4444 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4445 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R4446 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4447 nsp R,CHIP THICK 18K-J,1/16W-1608REEL C20001836M160S 1
R4449 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R4450 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4451 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4452 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4453 nsp R,CHIP THICK 560-J,1/16W-1608REEL C20005616M160S 1
R4454 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R4455 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4456 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4459 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4460 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
CAPACIITORS GROUP
C4400,4401 nsp C,ELECT GE 85C 10UF-M/16V,3*5-5RE SY D040100083050S 2
C4402,4403 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4404 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4405,4406 963133502530S C,FILM POLYESTER ST-0.1UF-J/100V-5RE HPE104J2AP050T DAEHUNG D02010406C250S 2
C4407 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4408 nsp C,ELECT GE 85C 100UF-M/63V,8*11.5 SHL SY D040101088050S 1
C4409 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4411 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4412-4415 nsp C,CERAMIC CHIP T.C COG470PF-J/50V-1608REEL D010471167160S 4
C4416,4417 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 2
C4418 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4419 nsp C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C4420-4422 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 3
C4424 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C4425-4427 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 3
C4428 nsp C,CERAMIC CHIP HIK Y5V1UF-Z/50V-1608REEL D011105597160S 1
C4430-4435 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 6
C4437 nsp C,CERAMIC CHIP T.C COG82PF-J/50V-1608REEL D010820167160S 1
C4438 nsp C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C4439 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C4441 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4442 nsp C,ELECT GE 85C 220UF-M/6.3V,8*5-5RE SRE SY D040221081070S 1
C4443,4444 nsp C,CERAMIC CHIP T.C C0G)1000PF-J/50V-1608REEL D010102167160S 2
C4446 nsp C,ELECT GE 85C 10UF-M/16V,3*5-5RE SY D040100083050S 1
C4448 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4449 nsp C,ELECT GE 85C 1UF-M/50V,3*5-5RE SY (Pb Free) D040010087090S 1
C4451,4452 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4453,4454 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 2
OTHER PARTS GROUP
BD4400,4401 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 2
BD4402 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1
CN4400 nsp CN,WIRE 2MM 300MM/8P 20010HS-08=CKM2002HR-08 WH1007#26 L002301082630S 1
CN4401 nsp CN,WIRE 2MM 540MM/6P 20010HS-06=CKM2002HV-06 RD2725#24 SH 105C L002541060020S 1
CP4400 nsp CN.FPC 1.0MM 1.0-11S-40PW 40P AN DIP TOP CONTACT L130100114050S 1
CP4401 nsp CN.WAFER 2.5MM YMAW025-07R DIP RA L102025070010S 1
CP4402 963643101610D CN,PLUG CONTACT USB A F 180 DIP L=15.0 G480040000180S 1
CP4403 nsp CN.WAFER 2.0MM 20010WS-08A00 DIP8P STRAIGHT L101200100810S 1
! F4400 963652500020S FUSE CHIP 6125FF500-R 500mA FAST-ACTING SUBMINIATURE FUSE G657612505030S 1
IC4400 963232100400S IC,LINEAR OP UTC4580E SOP8 DUAL OP AMP J121458001010S 1
J4455-4457 nsp R,CHIP THICK 0-J,1/8W-3216REEL C200000061300S 3
JACK4400 963643006910M JACK,D3.5 MINIJACK(PJ-3234A-4)SILVER RINNG G401PJ323A40YS 1
JACK4401 963643101120S JACK,D6.5 PHONE (YUQIU) D6.5 9P SILVER PJ-612A-9 G402PJ612A09YS 1
LED4400 963263100990S LED,ROUND BL-BUF4V5K-1-HS-NP-AV-FP3.5-TBF19.5C 3PI RED K500032001260S 1
LED4401 963209006790M LED,ROUND BZ-BB43V4V-2-FP5-TBF22A 5PI BLUE P=5MM K500056000130S 1
LED4402 963263100510S LED,ROUND WEJ3290W-R2H0-BA 3PI RED/YELLOW GREEN BI-COLOR K500032451010S 1
PLT4400 nsp PLATE NR1504U1B(MARANTZ) SPTE t0.3/FRONT HP 4470212826000S 1
RMC4400 963262012130S MODULE,REMOCON R34ES9A 36KHZ IR REMOCON MODULE P=2.54MM E940349003610S 1
SW4400-4408 00D9630045708 SW,TACT SKHV10920A,5MM/260G-REEL G180000270010S 9
