Marantz NR1606/U1B - AV PCB Assy

AV
AV PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D5221-5223 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 3
D5229 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D5231,5232 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 2
IC4200 963235100750S IC,ELECT VR BD34704KS2 SQFP-T80C 7.1CH SOUND PROCESSOR J084347040010S 1
IC5201 963232100450S IC,LINEAR OP NJM4580CG SOP8 J121458000050S 1
IC5401 963235100700S IC,MONITOR SW NJM2595M-TE1 DMP16 5-INPUT 3-OUTPUT VIDEO SWITCH J171259500010S 1
IC5402 963235100630S IC,MONITOR SW NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
Q5202 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5205 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5206,5207 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5209 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5210 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5212 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5214 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5215,5216 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5218 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
Q5219 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5220 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q5221 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5222,5223 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5224 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q5226 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 0.2W/SC-59 ISAHAYA J522020011210S 1
U5500-5503 963232100390S IC,LINEAR OP NJM8080G SOP8 DUAL OP AMP J121808000010S 4
ZD5200 963202500290D D,ZENER ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
RESISTOR GROUP
R5200 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R5203,5204 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R5205-5212 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 8
R5213-5218 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 6
R5220 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5221 nsp R,CHIP THICK 91K-J,1/16W-1608REEL C20009136M160S 1
R5225 nsp R,CHIP THICK 91K-J,1/16W-1608REEL C20009136M160S 1
R5227 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5233 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5235 nsp R,CHIP THICK 91K-J,1/16W-1608REEL C20009136M160S 1
R5239,5240 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 2
R5242-5245 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 4
R5247 nsp R,CHIP THICK 91K-J,1/16W-1608REEL C20009136M160S 1
R5248 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5250 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5251 nsp R,CHIP THICK 91K-J,1/16W-1608REEL C20009136M160S 1
R5253,5254 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R5255 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5257,5258 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R5259 nsp R,CHIP THICK 91K-J,1/16W-1608REEL C20009136M160S 1
R5260 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5261-5264 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 4
R5265 nsp R,METAL FILM 100PPM 270-J,1W-R.RELL C060027165060S 1
R5266 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R5267,5268 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R5269,5270 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R5271 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 1
R5272,5273 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R5274 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R5276-5278 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 3
R5281 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R5282 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R5283 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R5284 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R5285,5286 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R5289 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R5290,5291 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 2
R5292,5293 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R5295,5296 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R5297,5298 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R5299 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 1
R5300 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
R5301,5302 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R5303 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 1
R5304 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R5305,5306 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R5308 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5309 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R5310 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R5311 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
R5312,5313 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R5314 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 1
R5315 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5317 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5319 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R5320,5321 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R5322 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R5323 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5324,5325 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 2
R5326 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R5328 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5329,5330 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R5331 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 1
R5332 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5333,5334 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R5335 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 1
R5336 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R5337 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R5338 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R5340,5341 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R5342 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5343 nsp R,CHIP THICK 12K-J,1/16W-1608REEL C20001236M160S 1
R5344 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5345-5347 nsp R,CHIP THICK 12K-J,1/16W-1608REEL C20001236M160S 3
R5348,5349 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R5352 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160S 1
R5353 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R5354 nsp R,CHIP THICK 18K-J,1/16W-1608REEL C20001836M160S 1
R5355 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
R5408 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 1
