HDMI

HDMI PCB ASS'Y

※Parts indicated b

"ns

"on this table cannot be su

lied

※The

arts listed below are onl

for maintenance. Therefore the

ht differ from the

arts used in the unit in a

earances or dimension

NOTE:The symbols in the column Remarks indicate the following destinations.

U : North America model N : Europe model K : China model F : Japan model

B : Black model SG : Silver Gold model

REF No. Part No. Part Name Remarks Q'ty New Ver

SEMICONDUCTORS GROUP

D1089 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1

D1094 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 U K005041480230S 1

D1095 963263101000S LED,IR BIR-BM1341W 3PI INFRARED LED U K505134101050S 1

D1097 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1

D1104,1105 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 2

D1138 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G SOD523 SCHOTTKY BARRIER DIODE K125521305230S 1

Q1000 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1001 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1002 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1003 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1004 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1005 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1009 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1010 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1011 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1012 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1013 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1014 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1015 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1016 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1018,1019 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2

Q1022-1029 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 8

Q1030,1031 963212500030S SEMI,CHIP TR/PNP 2SA ISA1530AC1 0.2W/SC-59 ISAHAYA J520015301210S 2

Q1037 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA U J520101411210S 1

Q1041,1042 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 2

Q1043 963219002180S SEMI,CHIP TR/NPN 2SD 2SD2114KT146W SMT3 SOT23-REEL J5232114K0010S 1

Q1046 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1047 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1050 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1051 963219004200S SEMI,FET CHIP FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1

Q1052 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1

Q1055 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1

Q1056 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1057 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1058 963219004200S SEMI,FET CHIP FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1

Q1059 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1

Q1060 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1062 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1063 963219004200S SEMI,FET CHIP FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1

Q1064 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1

Q1065 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1066 943216500050S SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA J522104411210S 1

Q1067 963219004200S SEMI,FET CHIP FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1

Q1068 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1

Q1069,1070 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 2

Q1071 963219004200S SEMI,FET CHIP FDC608PZ P-CH 2.5V MOSFET SOT6 J543608000010S 1

Q1072 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1

Q1073 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1075 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q1076 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U SOT323 40V LOW VCEsat PNP TR J521051401010S 1

Q2202 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

Q3630 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1

U1000 23681050460AS IC,LOGIC MN864788 HDMI HQFP144P J040864788010S 1

U1002 963239101350S IC,LOGIC SN74CBT3251PWR TSSOP16 FET MUX/DEMUX J040743251030S 1

U1003 23681050460AS IC,LOGIC MN864788 HDMI HQFP144P J040864788010S 1

U1005 23671011050AS IC,LOGIC-DECODER MFI337S3959 COPROCESSOR(IPOD) SAGUB J044337395910S 1

U1006 963239101360S IC,LOGIC-INTERFACE BD82065FVJ CURRENT LIMIT 2.4A TSSOP-B8J J046820650010S 1

U1007,1008 nsp PIN JUMPER PIN HEADER 1.27MM 64P S1210-64SVB-S01-1R L424012102640S 2

U1010 24681009260AS IC,MEMORY FLASH MX25L25635FMI-10G 256M SERIAL FLASH SOP16 J005252561010S 1

U1016 00D2623444902 IC,LOGIC TC74VHC08FT CMOS 2-INPUT AND GATE TSSOP14 P-0.65 J040740800280S 1

U1017 963239101320S IC,MEMORY-EEPROM R1EX24128BSAS0I 128Kbit SERIAL SOP8 RENESAS J000241282010S 1

U1018 963243103100S IC, R5F564MJCDFC NR1606 (MAIN CPU) 8952160600010 1 *

┗U1018 - IC,CPU MICRO PROCESS R5F564MJCDFC J020556400010S 1

U1019 963262012150M MODULE,REMOCON R94EV1A 36KHZ STRAIGHT LEAD P=2.54MM U E940941003610S 1

U1022 236810064604S IC,LOGIC AD8195 HDMI/DVI BUFFER EQ LFCSP40 J040819505510S 1

U1023 963246101150S IC,MEMORY-RAM W9864G6KH-5 1M*4BANKS*16BIT(64MB) TSOP54 200MHz J001986465020S 1

U1025 963248103280S MX25L6406EM2I-12G (WITH DSP SOFTWARE) 8952220000090 1 *

┗U1025 - IC,MEMORY FLASH MX25L6406EM2I-12G 64M SERIAL FLASH SOP8 J005256401210S 1

U1026 23681016160AS IC,LOGIC-ENCODER ADV8003KBCZ-8B (AD55/058Z-0) J045800305010S 1

U1027 963248103390S IC, MX25L12835FMI-10G NR1606 (GUI) Non-fixed-2 1 *

┗U1027 - IC,MEMORY FLASH MX25L12835FMI-10G 128M SERIAL FLASH SOP16 J005251281060S 1

U1028,1029 963246101010S IC,MEMORY-RAM A3R12E40CBF-8E 512Mb DDR2 SDRAM FBGA84 J001030124080S 2

U1030 943239010400S IC,LINEAR-REGULATOR NJM2845DL1-33 3.3V TO-252-3 LOW-DROP VOL REGULATOR J126284533010S 1

U1039 23681050460AS IC,LOGIC MN864788 HDMI HQFP144P J040864788010S 1

U1040 23681014050AS IC,LOGIC-INTERFACE PCM9211 TRANSCEIVER LQFP48 J046921100010S 1

U1041 963239101710S 5M80ZT100C5N TQFP100 (WITH AUDIO PLD SOFTWARE) 8952220000110 1 *

┗U1041 - IC,PAL/PLD 5M80ZT100C5N TQFP100 J003058010050S 1

U1042 00D2623077900 IC,LOGIC TC74VHCU04FT HEX INVERTER TSSOP14 J040740405580S 1

U1043 963239101100S MODULE BCR-802-M25 25MBPS OPTICAL RECEIVER INTERFACE E100802000250S 1

U1045 963239002150S IC,LOGIC SN74LVC244APWR TSSOP 20P/OCTAL BUFFER/DRIVER J040742440230S 1

U1048 236810082503S IC,LOGIC-D/A CONVER PCM1690 HTSSOP48 J042169000010S 1

U1050 943239010400S IC,LINEAR-REGULATOR NJM2845DL1-33 3.3V TO-252-3 LOW-DROP VOL REGULATOR J126284533010S 1

U1052 23681012050AS IC,LOGIC-D/A CONVER PCM5100 TSSOP20 AUDIO STEREO DAC J042510005510S 1

U1055 23681012760AS IC,LOGIC ADV7850 HDMI 1.4A RECEIVER BGA425 J040785005510S 1

U1060-1062 234810014504S IC,LOGIC MC14094BDTR2G SHIFT REGISTER TSSOP16P J040140940020S 3

U1063-1072 963231102200S IC,LINEAR POWER MP2143DJ 3A STEP DOWN SWITCHER T-SOT23-8 J122214300010S 10

U1073 963245100680S IC,ANALOG CS49844A AUDIO DSP J080498440010S 1

U3204 963233102120S IC,LOGIC SN74LVC827APWR TSSOP24 10BIT BUFFER/DRIVER J040748270010S 1

RESISTOR GROUP

R1000 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1

R1001 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1

R1006 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1

R1010,1011 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 2

R1012 nsp R,CHIP THICK 10-J,1/16W-1005REEL C20001006M101S 1

R1013 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1

R1014 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1

R1015,1016 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 2

R1017 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1

R1018 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1

R1019 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1

R1021 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1

R1038 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1

R1039 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1

R1040,1041 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 2

R1042 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
