Marantz NR1606/U1B - 7 CH_AMP PCB Assy

7CH_AMP
7CH_AMP PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4800 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
D4805 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
D4812 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
D4817 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
D4822 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
D4827 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
D4832 00D9600197000 D,SWITCHING CHIP KDS160(UF) /USC K005016000010S 1
Q4800 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4801 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4803 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 1
Q4804 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4806,4807 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4809 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4810 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4811 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 1
Q4812 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4814 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4816,4817 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4819 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4820 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4821 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4823 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4825,4826 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4828 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4829 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4830 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4832 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4834,4835 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4837 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4838 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4839 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4841 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4843,4844 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4846 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4847 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4848 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4850 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4852,4853 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4855 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
Q4856 00D2710314903 SEMI,TR/GE PNP 2SA KTA1024Y,1W/TO92L-REEL J5001024Y0050S 1
Q4857 00D2710318909 SEMI,CHIP TR/PNP 2SA 2N5401S 0.35W/SOT-23 REEL J520254010010S 1
Q4859 00D2730479909 SEMI,CHIP TR/NPN 2SC 2N5551S 0.35W/SOT-23 REEL J522255510010S 1
Q4861,4862 00D9600196205 SEMI,TR/GE PNP 2SA KSA992F,0.5W/TO92-REEL J5000992F0050S 2
Q4864 00D2730471907 SEMI,TR/GE NPN 2SC KTC3206Y,1W/TO92L-REEL J5023206Y0050S 1
ZD4800 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4803 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4806 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4809 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4812 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4815 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
ZD4818 963202500300D D,ZENER ZJ5.1A-0.5W/5MA-52MM SEMTECH K06005R134522S 1
RESISTOR GROUP
R4800 nsp R,CARBON FILM 1.8K-J,1/5W-52RE-AX C00001826P520S 1
R4801 nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520S 1
R4802 nsp R,CARBON FILM 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R4803 963125003140S R,METAL FILM 100PPM 5.6K-J,1W-R.REEL C060056265050S 1
R4804 963252100140D POSISTOR DHPTF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R4805 nsp R,CHIP THICK 56K-J,1/16W-1608REEL C20005636M160S 1
R4806 963125003140S R,METAL FILM 100PPM 5.6K-J,1W-R.REEL C060056265050S 1
R4807 nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520S 1
R4809 nsp R,CARBON FILM 680K-J,1/5W-52RE-AX C00006846P520S 1
R4810 nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520S 1
R4811,4812 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4813 963125012630S R,METAL FILM 100PPM 22-J,1W-5REEL C060022065050S 1
R4814 nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520S 1
R4815 nsp R,CHIP THICK 270K-J,1/16W-1608REEL C20002746M160S 1
R4816,4817 nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520S 2
R4818 nsp R,CHIP THICK 220K-J,1/16W-1608REEL C20002246M160S 1
R4819 nsp R,CARBON FILM 2.7K-J,1/5W-52RE-AX C00002726P520S 1
R4820 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4821 963124500500S R,FIXED,M.O. RSD-R1-2WJ-0.22 3.5*8.6 P=5MM R.REEL N113136622820S 1
R4823 nsp R,CHIP THICK 5.6K-J,1/16W-1608REEL C20005626M160S 1
R4825 nsp R,CARBON FILM 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R4826 nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520S 1
R4827 nsp R,CARBON FILM 33K-J,1/5W-52RE-AX C00003336P520S 1
R4829 963124500500S R,FIXED,M.O. RSD-R1-2WJ-0.22 3.5*8.6 P=5MM R.REEL N113136622820S 1
R4831 nsp R,METAL FILM 100PPM 3.3K-J,1W-R.REEL C060033265050S 1
R4832 nsp R,CHIP THICK 220K-J,1/16W-1608REEL C20002246M160S 1
R4833 nsp R,CARBON FILM 560-J,1/5W-52RE-AX C00005616P520S 1
R4834 nsp R,CARBON FILM 470K-J,1/5W-52RE-AX C00004746P520S 1
R4835 nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520S 1
R4836,4837 nsp R,CARBON FILM 220-J,1/5W-52RE-AX C00002216P520S 2
R4838 963125012630S R,METAL FILM 100PPM 22-J,1W-5REEL C060022065050S 1
R4839 nsp R,CARBON FILM 150-J,1/5W-52RE-AX C00001516P520S 1
R4840 nsp R,CARBON FILM 270-J,1/5W-52RE-AX C00002716P520S 1
R4841 nsp R,METAL FILM 100PPM 1.2K-J,1W-5REEL C060012265050S 1
R4842 nsp R,METAL FILM 100PPM 47-J,1W-R.REEL C060047065060S 1
R4843 nsp R,CARBON FILM 1.8K-J,1/5W-52RE-AX C00001826P520S 1
R4844 nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520S 1
R4845 nsp R,CARBON FILM 1.2K-J,1/5W-52RE-AX C00001226P520S 1
R4846 963125003140S R,METAL FILM 100PPM 5.6K-J,1W-R.REEL C060056265050S 1
R4847 00D9630337908 R,METAL FILM 100PPM 33-J,1W-R.REEL C060033065050S 1
R4848 963252100140D POSISTOR DHPTF1608 471P 105T SMD PTC THERMISTOR F320471001050S 1
R4849 963125003140S R,METAL FILM 100PPM 5.6K-J,1W-R.REEL C060056265050S 1
R4850 nsp R,CARBON FILM 100K-J,1/5W-52RE-AX C00001046P520S 1
R4852 nsp R,CARBON FILM 680K-J,1/5W-52RE-AX C00006846P520S 1
R4853 00D9639005639 R,METAL FILM 100PPM 100-J,1W-R.REEL C060010165060S 1
R4854 nsp R,CARBON FILM 47K-J,1/5W-52RE-AX C00004736P520S 1
R4855,4856 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4857 963125012630S R,METAL FILM 100PPM 22-J,1W-5REEL C060022065050S 1
R4858 nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520S 1
R4859 nsp R,CHIP THICK 270K-J,1/16W-1608REEL C20002746M160S 1
R4860 nsp R,CARBON FILM 22K-J,1/5W-52RE-AX C00002236P520S 1
R4861 nsp R,CHIP THICK 220K-J,1/16W-1608REEL C20002246M160S 1
R4862 nsp R,CARBON FILM 2.7K-J,1/5W-52RE-AX C00002726P520S 1
19
