Marantz NR1606/U1B - Exploded View

EXPLODED
EXPLODED
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
1 963412100780M KNOB NR1403U1B(MARANTZ) BLACK A3/VOLUME KNOB BK
5080212691000
S
5080212691000C
N
2
1 963412100790M KNOB NR1403/1603 SG A3/VOLUEM KNOB SG
5087212691100
S
5087212691100C
N
2
2 nsp NUTS -2
3 963419006180M DECORATION NR1501FB(MARANTZ) ABS BK HF380-9001 RING KNOB BK
5127210901000
S
5127210901000C
N
2
3 963419006190M DECORATION NR1501N1SG(MARANTZ) ABS SG HF380-8A529 RING KNOB SG
5127210901100
S
5127210901100C
N
2
4 963421006200M BADGE NR1501FB(MARANTZ) SILVER/GRAY 11c AL 5630210678000S 1
5 963416100560M WINDOW NR-1402/1602(ALL) ACRYL RED WINE COLOR A4/WINDOW
5077212733020
S
5077212733020C
N
1
6 963402105510S PANEL NR1606U1B ABS BK A2 / FRONT U 3067216441000S 1 *
6 963402105520S PANEL NR1606N1B ABS BK A2 / FRONTB N1BK, K 3067216441010S 1 *
6 963402105530S PANEL NR1606N1SG ABS BK A2 / FRONT N1SG 3067216441100S 1 *
6 963402105540S PANEL NR1606F ABS BK A2 / FRONT F 3067216441020S 1 *
7 411510021005M BUTTON NR1501FB(MARANTZ) ABS BK HF380-9001 POWER TACT BK
5090213961000
S
5090213961000C
N
1
7 963411012000M BUTTON NR1601(N1SG) ABS(HF380-8A529) POWER TACT SG
5097213961100
S
5097213961100C
N
1
8 963481006080M LENS NR1506U1B PMMA MILKY/STANDBY
3710210873000
S
3710210873000C
N
1
9 nsp P.C.B SUB ASSY NR1506U1B(MARANTZ)/HP 7028078242010 1
10 963481006070M LENS NR1506U1BACRYL MILKY A4/HDMI
3710210843000
S
3710210843000C
N
2
11 963411101820M BUTTON NR-1403/1603 ABS BK A3/4KEY BK
5097215011000
S
5097215011000C
N
2
11 963411101830M BUTTON NR-1403/1603 ABS SG A3/4KEY SG
5097215011100
S
5097215011100C
N
2
13 nsp CLAMP
(
SECC+PVC
)
DARB-2･5.6-6X50/MTG 4330210189000
S
3
14 nsp P.C.B SUB ASSY NR1506U1B(MARANTZ)/FRONT 7028078241010 1
15 nsp P.C.B SUB ASSY NR1506U1B(MARANTZ)/HDMI_GUIDE_B 7028078294010 1
16 nsp P.C.B SUB ASSY NR1506U1B(MARANTZ)/HDMI_GUIDE_A 7028078293010 1
17 nsp HEAT SINK NR1606U1B AL6063S A4/MAIN HEAT SINK 2120212408000S 1
18 nsp P.C.B SUB ASSY NR1506U1B(MARANTZ)/GUIDE_L 7028078235010 1
19 nsp TAPE NR1606U1B(MARANTZ) NO_156(15X45)SCETATE CLOTH TAPE 1220210059050SV 8
20-Q4808 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
20-Q4818 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
20-Q4827 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
20-Q4836 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
20-Q4845 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
20-Q4854 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
20-Q4863 00D9960018706 TR PNP 2SB1560-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011560Y0000S 1
21-Q4805 963219003340S KTC3964/TO126S-BULK J502396400010S 1
21-Q4815 963219003340S KTC3964/TO126S-BULK J502396400010S 1
21-Q4824 963219003340S KTC3964/TO126S-BULK J502396400010S 1
21-Q4833 963219003340S KTC3964/TO126S-BULK J502396400010S 1
21-Q4842 963219003340S KTC3964/TO126S-BULK J502396400010S 1
21-Q4851 963219003340S KTC3964/TO126S-BULK J502396400010S 1
21-Q4860 963219003340S KTC3964/TO126S-BULK J502396400010S 1
22-Q4802 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
22-Q4813 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
22-Q4822 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
22-Q4831 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
22-Q4840 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
22-Q4849 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
22-Q4858 00D9960018706 TR NPN 2SD2390-Y (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032390Y0000S 1
23 nsp BRACKET R925 SECC 1.0T/H SINK 4010056906010S 5
24 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/7CH_AMP 7028078211050 1
25 00M243W057210 FOOT NR1605U1B(MARANTZ) ABS/FOOT (ANAM COM)
4007210841000
S
4007210841000C
N
4
26 00M32CW107010 CUSHION NR1605U1BFELT+EEA(BK)A4/FOOT 4050215145000S 4
27 nsp CHASSIS NR1606U1B SECC 1.0T A2/MAIN 3200215226000S 1
28 963403101240M CABINET NR1606U1B(MARANTZ) NR1606U1BSECC t0.8 TOP COVER BK
3007211786100
S
3007212156000
S
1
28 963403101250M CABINET NR1606N1SG(MARANTZ) NR1606U1B(MARANTZ) NR1606U1BSE SG
3007211786110
S
3007212156010
S
1
29 nsp CUSHION AVR1911BKE3 RUBBER(HARDNESS50~70)BK/SCREW 4050213025000S 2
！ 31 963101102310M POWER TRANS (U) U 8200858630740S 1
！ 31 963101102320M POWER TRANS (N) N 8200858630750S 1
！ 31 963101102730S POWER TRANS (K) K 8200858630810S 1 *
！ 31 963101102330M POWER TRANS (F) F 8200858630760S 1
32 nsp SUPPORTER AVR1601(KE2) KIFCO(PS801) /P.C. 4070210192000S 1
33 nsp CUSHION NR1606U1B(MARANTZ) RUBBER BK 8*12*10t/MD DOOR BK 4050212005000SV 1
34 nsp SUPPORTER UPAF07 ABS BK/PCB 4070001601010S 1
35 nsp BACK CHASSIS U 3207215206000S 1 *
35 nsp BACK CHASSIS N 3207215206100S 1 *
35 nsp BACK CHASSIS K 3207215206110S 1 *
35 nsp BACK CHASSIS F 3207215206120S 1 *
36 nsp BRACKET AVR1911BKE3 SECC t1.0 A4 /SMPS 401021488600DS 1
37 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/SMPS 7028078234050 1 *
38 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/SPK 7028078291050 1 *
39 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/REG_CNT 7028078232050 1 *
40 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/REG 7028078231050 1 *
41 nsp SOCKET,POWER AC AC INLET R-301(B21) G430040807010S 1
42 nsp P.C.B SUB ASSY NR1506U1B(MARANTZ)/USB 7028078243010 1
43 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/FRONT_CNT 7028078233050 1 *
44 nsp BUSHING N,K 2410040353010S 14
45 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/AV 7028078251050 1 *
46 nsp P.C.B SUB ASSY NR1606U1B(MARANTZ)/SIDE_CNT 7028078292050 1 *
47 9U6391022600S HDMI PCB ASSY (U) U 7025HK1407015 1 *
┗12 - F-HDMI PCB 1*
47 9U6391022700S HDMI PCB ASSY (N) N 7025HK1407025 1 *
┗12 - F-HDMI PCB 1*
47 9U6391022800S HDMI PCB ASSY (K) K 7025HK1407045 1 *
┗12 - F-HDMI PCB 1*
47 9U6391022900S HDMI PCB ASSY (F) F 7025HK1407055 1 *
┗12 - F-HDMI PCB 1*
48 nsp PLATE NR1606U1BSPTE 0.3T A4/SHIELD PLATE 4470213046000S 1
49 nsp BRACKET NR1606U1BSECC t1.0 A4/HDMI 4010215226000V 1 *
50 nsp SUPPORTER KRFV6300D(E)DONG-A DASS-4N(Locking) 4.8mm/PCB 4070211653000S 1
51 nsp SHEET SR5006U1BHIMELON 10*70*t0.35 A4/HIMELON 1210211629000S 2
52 nsp SPRING NR1605U1BSUS304 PI1.2 PI7.4 A4/KNOB 3720210576000S 1
53 963419100910S BUSHING ABS(HB)(CMH1A357) A4/WIFI ANT
2410210161000
S
2410210161000C
N
2
