Marantz PM-11S2 Service Manual

105
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
PD31 DU74 00MHI10048080 00MHI10048080 L.E.D. SEL6E10C
(
F-RANK
)
BLUE LED
PD31 DU75 00MHI10048080 00MHI10048080 L.E.D. SEL6E10C
(
F-RANK
)
BLUE LED
PD31 QU71 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT
PD31 QU72 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT
PD31
QU73
00MBA21303000
00MBA21303000
TRS
DTC124EU RN1303 UMT
PD31
QU73
00MBA21303000
00MBA21303000
TRS
.
DTC124EU
RN1303
UMT
PD31 QU74 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT
PD31 RU81 ns
p
00MNN05562610 CHIP RES. 5.6K OHM +- 5% 1/16W
PD31 RU82 ns
p
00MNN05102610 CHIP RES. 1K OHM +- 5% 1/16W
PD31 RU83 ns
p
00MNN05122610 CHIP RES. 1.2K OHM +- 5% 1/16W
PD31 RU84 ns
p
00MNN05182610 CHIP RES. 1.8K OHM +- 5% 1/16W
PD31 RU86 ns
p
00MGD05182160 RES. 1.8K OHM +- 5% 1/6W
PD31 RU87 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +- 5% 1/16W
PD31 RU88 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +- 5% 1/16W
PD31
RU89
nsp
00MNN05222610
CHIP RES
2 2K OHM +- 5% 1/16W
PD31
RU89
nsp
00MNN05222610
CHIP
RES
.
2
.
2K
OHM
+-
5%
1/16W
PD31 RU90 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD31 RU91 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD31 RU92 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD31 RU93 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD31 SU71 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PD31 SU72 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PD31 SU73 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PD31 SU74 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
BACK LIGHT PWB
(
PD41
)
(
00MWG04AJ707-
)
( )( )
PD41 DD11 00MHI10005980 00MHI10005980 L.E.D. NSPW515BS-S-CO
PD41 RD11 ns
p
00MGD05103160 RES. 10K OHM +- 5% 1/6W
SELECTOR PWB
(
PD61
)
(
00MWG04AJ706-
)
PD61 SU82 00MSR01120070 00MSR01120070 ROTARY SW SRRSIC
VOLUME PWB
(
PD71
)
(
00MWG04AJ305-
)
PD71 RU57 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD71 RU58 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD71 RU59 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD71 RU60 ns
p
00MNN05103610 CHIP RES. 10K OHM +- 5% 1/16W
PD71 SU81 00MSR02010140 00MSR02010140 ROTARY SW EC12E2470811
REGULATOR PWB
(
PG01
)
(
00MWA04AJ805-
)
PG01 CG01 ns
p
00MOA15905010 ELECT. CAP. LKG1H153MESBZT
PG01 CG02 ns
p
00MOA15905010 ELECT. CAP. LKG1H153MESBZT
PG01 CG03 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
PG01 CG04 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
PG01 CG05 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
PG01 CG06 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
PG01 CG07 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
PG01
CG08
nsp
00MOA227010R0
ELECT CAP
ROA 10V 221M H3#PE T2 (220UF 10V)
PG01
CG08
nsp
00MOA227010R0
ELECT
.
CAP
.
ROA
-
10V
221M
-
H3#PE
-
T2
(220UF
10V)
PG01 CG09 ns
p
00MOA22703520 ELECT. CAP. 220UF 35V M RA-2
PG01 DG01 ns
p
00MHD20002000 DIODE 1SS133 T-77
PG01 DG02 ns
p
00MHD20002000 DIODE 1SS133 T-77
PG01 DG03 ns
p
00MHD20002000 DIODE 1SS133 T-77
PG01 DG04 ns
p
00MHD20002000 DIODE 1SS133 T-77
PG01 DG05 00MHD32401000 00MHD32401000 ZENER DIODE 24V ZENER EQUIVALENT
PG01 DG06 00MHD32401000 00MHD32401000 ZENER DIODE 24V ZENER EQUIVALENT
PG01 DG08 ns
p
00MHD20002000 DIODE 1SS133 T-77
P
G0
1D
G09
00
MHD
3068
1
000
00
MHD
3068
1
000
ZENER DI
O
DE
6
.
8
V ZENER E
QU
IVALENT
G0
G09
00 3068 000
00 3068 000
O
6 8 QU
PG01 LG01 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
PG01 LG02 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
PG01 QG01 00D2710311906 00D2710311906 TRS. KTA1267-GR-AT/P
PG01 QG02 00D2730468907 00D2730468907 TRS. KTC3199-GR-AT/P
PG01 QG03 00MHT41415100 00MHT41415100 TRS. 2SD1415
PG01 QG04 00MHT21020100 00MHT21020100 TRS. 2SB1020
PG01 QG05 00D2710311906 00D2710311906 TRS. KTA1267-GR-AT/P
PG01 QG06 00MHT41415100 00MHT41415100 TRS. 2SD1415
PG01 RG01 ns
p
00MGD05683160 RES. 68K OHM +- 5% 1/6W
PG01 RG03 ns
p
00MGD05221160 RES. 220 OHM +- 5% 1/6W
PG01 RG04 ns
p
00MGD05221160 RES. 220 OHM +- 5% 1/6W
PG01 RG05 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6W
PG01 RG06 ns
p
00MGD05101160 RES. 100 OHM +- 5% 1/6W
PG01 RG07 00MGG05033160 00MGG05033160 RES. ! 3.3 OHM +- 5% 1/6W
PG01 RG08 00MGG05033160 00MGG05033160 RES. ! 3.3 OHM +- 5% 1/6W
PG01 RG09 ns
p
00MGD05333160 RES. 33K OHM +- 5% 1/6W
