Marantz PM-15S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P101 C114
/
K1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C114
/
L1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C114
/
N1G 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C114
/
N1S 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C114
/
S1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C115 00MOA227025R0 00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
P101 C121 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P101 C122 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P101 C123 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P101 C124 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P101 C125 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P101 C126 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P101 C129 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P101 C130 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P101 C140 00MDF15332350 00MDF15332350 FILM CAP. 0.0033UF,J,M,50
V
P101 C141 00MDF15102350 00MDF15102350 FILM CAP. 0.001UF,J,M,50
V
P101 C145 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P101 C146 00MOA33701020 00MOA33701020 ELECT. CAP. 330 UF M 10V RA-2
P101 C201 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C202 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C203 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C204 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P101 C205 00MOA47602520 00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P101 C206 00MOA47602520 00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P101 C207 00MOA227025R0 00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
P101 C208 00MOA227025R0 00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
P101 C209 00MOA10605020 00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P101 C210 00MOA10605020 00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P101 C501 00MOA226025Z0 00MOA226025Z0 ELECT. CAP. ROS-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C502 00MOA226025Z0 00MOA226025Z0 ELECT. CAP. ROS-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C503 00MOA226025Z0 00MOA226025Z0 ELECT. CAP. ROS-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C504 00MOA226025Z0 00MOA226025Z0 ELECT. CAP. ROS-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C505 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P101 C506 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P101 C507 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P101 C508 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P101 C509 00MOA106025R0 00MOA106025R0 ELECT. CAP. ROA-25V 100M - E3#PE - T2
(
10UF 25V
)
P101 C510 00MOA106025R0 00MOA106025R0 ELECT. CAP. ROA-25V 100M - E3#PE - T2
(
10UF 25V
)
P101 C511 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P101 C512 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P101 C513 00MOA226025R0 00MOA226025R0 ELECT. CAP. ROA-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C514 00MOA226025R0 00MOA226025R0 ELECT. CAP. ROA-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C515 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
P101 C516
/
F N ns
p
00MOA22702520 ELECT. CAP. 220 UF M 25V RA-2
P101 C516 00MOA227025R0 00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
P101 C517
/
F N ns
p
00MOA22702520 ELECT. CAP. 220 UF M 25V RA-2
P101 C517 00MOA227025R0 00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5#PE - T2
(
220UF 25V
)
P101 C518 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
P101 C521 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P101 C524 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P101 C551 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P101 C552 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P101 C553 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +- 5% FAS
P101 C554 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +- 5% FAS
P101 C555 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P101 C556 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P101 C557 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P101 C558 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P101 C851 00MOA108035R0 00MOA108035R0 ELECT. CAP. ROA-35V 102M -K8#PE - S1
(
1000UF 35V
)
P101 C852 00MOA108035R0 00MOA108035R0 ELECT. CAP. ROA-35V 102M -K8#PE - S1
(
1000UF 35V
)
P101 C853 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P101 C854 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P101 C855 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P101 C856 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P101 D101 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P101 D102 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
49
