Marantz PM-15S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P601 C605 00MOB47708050 00MOB47708050 ELECT. CAP. 470UF/80V NICHICON PB-FRE
E
P601 C606 00MOB47708050 00MOB47708050 ELECT. CAP. 470UF/80V NICHICON PB-FRE
E
P601 C607 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P601 C608 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P601 C609 00MOF55331580 00MOF55331580 FILM CAP. 330PF 100V +- 5% FNS
P601 C610 00MOA476025Z0 00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3#PE - T2
(
47UF 25V
)
P601 C611 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
P601 C612 00MOA47405020 00MOA47405020 ELECT. CAP. 0.47UF M 50V RA-2
P601 D601 00MHD3200100
0
00MHD3200100
0
ZENER DIODE 20V ZENER EQUIVALEN
T
P601 D602 00MHD3200100
0
00MHD3200100
0
ZENER DIODE 20V ZENER EQUIVALEN
T
P601 D603 00MHI1000534
0
00MHI1000534
0
L.E.D. HLMF-K200 #2UL RED H=9 3M
M
P601 D604 00MHI1000534
0
00MHI1000534
0
L.E.D. HLMF-K200 #2UL RED H=9 3M
M
P601 D605 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P601 D606 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P601 D609 00MHD2002701
0
00MHD2002701
0
DIODE HSS81TD 150V 150MA AXIAL.
P601 J607 00MYP07001960 00MYP07001960 PLUG IMSA-1068-06Z042 6
P
P601 J608 00MYP07001960 00MYP07001960 PLUG IMSA-1068-06Z042 6
P
P601 Q601 00MHC1226309
0
00MHC1226309
0
IC NJM5532LD
P601 Q602 00MKH04AJ1020 00MKH04AJ1020 UNIT & H-IC HDAM-SA2 MODULE WITHOUT COATING
P601 Q603 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=G
R
P601 Q604 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=G
R
P601 Q605 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=G
R
P601 Q606 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=G
R
P601 Q607 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=G
R
P601 Q608 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=G
R
P601 Q609 00MHT111452A0 00MHT111452A0 TRS. 2SA1145 O OR Y TAPING TOSHIB
A
P601 Q610 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y TAPING TOSHIB
A
P601 Q611 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y TAPING TOSHIB
A
P601 Q612 00MHT111452A0 00MHT111452A0 TRS. 2SA1145 O OR Y TAPING TOSHIB
A
P601 K603 00MHK185919C
0
00MHK185919C
0
TRS. KIT 2SA1859/C4883 PAIR FOR Q614/Q61
3
P601 Q613 ns
p
ns
p
TRS. 2SC4883 O OR Y PAIR WITH Q61
4
P601 Q614 ns
p
ns
p
TRS. 2SA1859 O OR Y PAIR WITH Q61
3
P601 Q615 00MHT332843D
0
00MHT332843D
0
TRS. 2SC3284 O,P,Y 125W FMG112
P601 Q616 00MHT113033D
0
00MHT113033D
0
TRS. 2SA1303 O,P,Y 125W FMG112
P601 Q617 00MHT334191Y0 00MHT334191Y0 TRS. TRANSISTOR C3419 Y 40V 0.8A PC=1.2W
(
5W
)
P601 Q618 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=G
R
P601 Q619 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=G
R
P601 R601 ns
p
00MGD0510516
0
RES. 1M OHM +- 5% 1/6
W
P601 R602 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P601 R603 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P601 R604 ns
p
00MGD0547316
0
RES. 47K OHM +- 5% 1/6
W
P601 R605 ns
p
00MGD0512316
0
RES. 12K OHM +- 5% 1/6
W
P601 R606 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P601 R607 ns
p
00MGD0510016
0
RES. 10 OHM +- 5% 1/6
W
P601 R608 ns
p
00MGD0547316
0
RES. 47K OHM +- 5% 1/6
W
P601 R612 ns
p
00MGD0547316
0
RES. 47K OHM +- 5% 1/6
W
P601 R614 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P601 R617 ns
p
00MGD0510516
0
RES. 1M OHM +- 5% 1/6
W
P601 R618 ns
p
00MGD0510516
0
RES. 1M OHM +- 5% 1/6
W
P601 R621 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P601 R622 ns
p
00MGD0510216
0
RES. 1K OHM +- 5% 1/6
W
P601 R623 00MRA0222076
0
00MRA0222076
0
TRIM. RES. VARIABLE RESISTOR 2.2KOHM
P601 R624 ns
p
00MGD0510416
0
RES. 100K OHM +- 5% 1/6
W
P601 R634 00MGO05001050 00MGO05001050 RES. 0.1 OHMS +-5% 5W PBR5
8
P601 R635 00MGO05001050 00MGO05001050 RES. 0.1 OHMS +-5% 5W PBR5
8
P601 R638 ns
p
00MGD0522316
0
RES. 22K OHM +- 5% 1/6
W
P601 R639 ns
p
00MGD0522316
0
RES. 22K OHM +- 5% 1/6
W
P601 R640 ns
p
00MGD0568216
0
RES. 6.8K OHM +- 5% 1/6
W
P601 R641 ns
p
00MGD0522316
0
RES. 22K OHM +- 5% 1/6
W
P601 R642 ns
p
00MGD0522216
0
RES. 2.2K OHM +- 5% 1/6
W
P601 U629 00MHD2002701
0
00MHD2002701
0
DIODE HSS81TD 150V 150MA AXIAL.
POSISTOR L
(
00MWA10AJ206-
)
P661 R661 00MHP0003324
0
00MHP0003324
0
VARISTOR VARISTOR PTH9M04BC222TS2F333
(
MURATA
)
POWER AMP R
(
00MWA10AJ202-
)
P701 C701 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P701 C702 00MOF55220590 00MOF55220590 FILM CAP. 22PF 200V +- 5% FAS
55
