Marantz PM-15S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POWER SUPPLY
(
00MWA10AJ205-
)
P801 C803 00MOC3380504
0
00MOC3380504
0
ELECT. CAP. 3300UF/50V NICHICON UFW1H332MHDIA
A
P801 C804 00MOC3380504
0
00MOC3380504
0
ELECT. CAP. 3300UF/50V NICHICON UFW1H332MHDIA
A
P801 C807 00MOA47802520 00MOA47802520 ELECT. CAP. 4700UF/25V RA-2
P801 C808 00MOA106025R0 00MOA106025R0 ELECT. CAP. ROA-25V 100M - E3#PE - T2
(
10UF 25V
)
P801 C809 00MOA47702520 00MOA47702520 ELECT. CAP. 470UF 25V M RA-2
P801 C810 00MOA10505020 00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P801 C811 00MOA10505020 00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P801 C812 00MOA47701020 00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
P801 C813 00MOA10605020 00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P801 C814 00MOA47701020 00MOA47701020 ELECT. CAP. 470 UF M 10V RA-2
P801 D801 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D802 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D803 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D804 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D806 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D807 00MHD3160100
0
00MHD3160100
0
ZENER DIODE 16V ZENER EQUIVALEN
T
P801 D808 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D809 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D811 00MHE1000510
0
00MHE1000510
0
DIODE SBD UNIT FCH20A15 TO-22
0
P801 D812 00MHE1000610
0
00MHE1000610
0
DIODE SBD UNIT FRH20A15 TO-22
0
P801 D813 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D814 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D815 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 D816 00MHD2004529
0
00MHD2004529
0
DIODE D1NJ10 100V 1A SBD TAPING
P801 F881
/
F N ns
p
00MFS10800960 FUSE # LF.8A/125V 0233008. 233 PSE UL CSA
P
P801 F881
/
K1G ns
p
00MFS10400850 FUSE # 4 A 250V BS LISTED
P801 F881
/
L1G ns
p
00MFS10800960 FUSE # LF.8A/125V 0233008. 233 PSE UL CSA
P
P801 F881
/
N1G 00MFS10400850 00MFS10400850 FUSE # 4 A 250V BS LISTED
P801 F881
/
N1S 00MFS10400850 00MFS10400850 FUSE # 4 A 250V BS LISTED
P801 F881
/
S1G ns
p
00MFS10400850 FUSE # 4 A 250V BS LISTED
P801 F882
/
F N ns
p
00MFS10125350 FUSE # 1.25A 125V UL,CSA,MITI
P801 G801 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474
K
P801 G802 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474
K
P801 G803 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474
K
P801 J881
/
F N ns
p
00MYJ04001590 JACK AC OUTLET 1P
P801 L802 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEA
D
P801 L803 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEA
D
P801 L804 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEA
D
P801 L805 00MLC2106072
0
00MLC2106072
0
CHOKE COI
L
10MH SL1923-103KR3
3
P801 L806 00MLC2106072
0
00MLC2106072
0
CHOKE COI
L
10MH SL1923-103KR3
3
P801 L807 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEA
D
P801 Q804 00MHT800931A0 00MHT800931A0 TRS. KTC3200 NPN TRANSISTOR RANK=G
R
P801 Q805 00MHT41415100 00MHT41415100 TRS. TRANSISTOR 2SD1415
P801 Q806 00MHT600111B0 00MHT600111B0 TRS. KTA1267 PNP TRANSISTOR RANK=
Y
P801 Q807 00MHC3850509
0
00MHC3850509
0
IC NJM78M05F
A
P801 R801 00MNK0501012
0
00MNK0501012
0
METAL RES. 1.0 OHM +-5% 1/2W ERG12SJW-E
P801 R802 00MNK0501012
0
00MNK0501012
0
METAL RES. 1.0 OHM +-5% 1/2W ERG12SJW-E
P801 R803 ns
p
00MGD0568216
0
RES. 6.8K OHM +- 5% 1/6
W
P801 R804 00MNK0501012
0
00MNK0501012
0
METAL RES. 1.0 OHM +-5% 1/2W ERG12SJW-E
P801 R805 ns
p
00MGD0510216
0
RES. 1K OHM +- 5% 1/6
W
P801 R806 ns
p
00MGD0515316
0
RES. 15K OHM +- 5% 1/6
W
P801 R807 ns
p
00MGD0568116
0
RES. 680 OHM +- 5% 1/6
W
P801 R808 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P801 R810 ns
p
00MGD0510416
0
RES. 100K OHM +- 5% 1/6
W
P801 R811 ns
p
00MGD0510416
0
RES. 100K OHM +- 5% 1/6
W
P801 R812 ns
p
00MGD0522216
0
RES. 2.2K OHM +- 5% 1/6
W
P801 R813 ns
p
00MGD0518316
0
RES. 18K OHM +- 5% 1/6
W
P801 R814 ns
p
00MGD0518316
0
RES. 18K OHM +- 5% 1/6
W
P801 R815 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
POWER SW
(
00MWA10AJ104-
)
P891 S891 00MSP01012500 00MSP01012500 PUSH S
W
ESB92S13B TV-5 STROKE=1.5MM
SPK
,
PROTECTION
(
00MWA10AJ204-
)
P901 C901 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P901 C902 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P901 C903
/
K1G ns
p
00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
57
