58
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RG70
4822 051 30479 CHIP 47Ω 1/16W NN05470610
RG74
RG75 4822 051 30152 CHIP 1.5kΩ 1/16W NN05152610
RG76 4822 051 30152 CHIP 1.5kΩ 1/16W NN05152610
RG77 4822 117 11817 CHIP 1.2kΩ 1/16W NN05122610
RG78 4822 117 11817 CHIP 1.2kΩ 1/16W NN05122610
RG79 4822 051 30152 CHIP 1.5kΩ 1/16W NN05152610
RG80 4822 051 30152 CHIP 1.5kΩ 1/16W NN05152610
RG81 4822 117 11817 CHIP 1.2kΩ 1/16W NN05122610
RG82 4822 117 11817 CHIP 1.2kΩ 1/16W NN05122610
RG83
4822 116 83829 CHIP 270Ω 1/16W NN05271610
RG86
RW01 4822 051 30471 CHIP 470Ω 1/16W NN05471610
RW02 4822 051 30471 CHIP 470Ω 1/16W NN05471610
RW03 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RW04 4822 051 30223 CHIP 22kΩ ±5% 1/16W NN05223610
RW05
4822 051 30103 CHIP 10kΩ 1/16W NN05103610
RW09
RW11 4822 051 30103 CHIP 10kΩ 1/16W NN05103610
RW12 4822 051 30103 CHIP 10kΩ 1/16W NN05103610
RW14 4822 051 30103 CHIP 10kΩ 1/16W NN05103610
RW15
4822 052 10109 10Ω 1/6W GG05100160
RW18
RW19 4822 053 10109 10Ω ±5% 1W GA05100010
RW20 4822 053 10109 10Ω ±5% 1W GA05100010
RW21
4822 052 10109 10Ω 1/6W GG05100160
RW28
PG04-RESISTORS
DG01
4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DG08
DW01 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DW02 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DW05 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
QG01 9965 000 01373 IC TC9459FELE-VOL UMEN HC10449050
QG02 4822 209 17155 IC NJM2068M HC10102090
QG03 4822 130 60107 TRS. 2SA1048 Y OR R HT110482B0
QG04 4822 130 60107 TRS. 2SA1048 Y OR R HT110482B0
QG05 4822 130 60839 TRS. 2SC2458 Y OR R HT324582B0
QG06 4822 130 60839 TRS. 2SC2458 Y OR R HT324582B0
QG07 4822 130 60839 TRS. 2SC2458 Y OR R HT324582B0
QG08 4822 130 60839 TRS. 2SC2458 Y OR R HT324582B0
QG09 4822 130 60107 TRS. 2SA1048 Y OR R HT110482B0
QG10 4822 130 60107 TRS. 2SA1048 Y OR R HT110482B0
QG11 4822 130 60107 TRS. 2SA1048 Y OR R HT110482B0
QG12 4822 130 60107 TRS. 2SA1048 Y OR R HT110482B0
QG13 4822 130 60839 TRS. 2SC2458 Y OR R HT324582B0
QG14 4822 130 60839 TRS. 2SC2458 Y OR R HT324582B0
QG15 4822 130 43233 TRS. 2SC2240 HT322402A0
QG16 4822 130 43233 TRS. 2SC2240 HT322402A0
QG17 4822 130 42949 TRS. 2SA970 HT109702A0
QG18 4822 130 42949 TRS. 2SA970 HT109702A0
QG19 4822 130 43818 TRS. 2SC2878 A OR B HT328782A0
QG20 4822 130 43818 TRS. 2SC2878 A OR B HT328782A0
QG21 4822 130 42292 TRS. 2SC2120 HT321201A0
QW01 4822 209 17155 IC NJM2068M HC10102090
QW03 4822 130 43233 TRS. 2SC2240 HT322402A0
QW04 4822 130 43233 TRS. 2SC2240 HT322402A0
QW05 4822 130 42949 TRS. 2SA970 HT109702A0
QW06 4822 130 42949 TRS. 2SA970 HT109702A0
PG04-MISCELLANEOUS
LG01 9965 000 01576 RELAY MR82-24USR LY20240480
LG02 9965 000 01576 RELAY MR82-24USR LY20240480
LG03 4822 242 73843 EMI FILTER 0.022uF FM12223010
LG04 4822 242 73843 EMI FILTER 0.022uF FM12223010
LW01 9965 000 01576 RELAY MR82-24USR LY20240480
PL04-VIDEO CIRCUIT BOARD
PL04-CAPACITORS
CL01
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL05
CL07 4822 122 31205 CER. 47pF J CH 50 DD15470300
CL08 4822 122 31205 CER. 47pF J CH 50 DD15470300
CL09
5322 124 21731 ELECT. 10µF 50V OA10605020
CL12
CL13 JUMPER 75060501P0
CL14 5322 124 21731 ELECT. 10µF 50V OA10605020
CL15 JUMPER 75060501P0
CL16 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CL17 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CL18 4822 122 40617 CER. 0.1µF 50V DD38104010
CL19 4822 122 31205 CER. 47pF J CH 50 DD15470300
CL20 4822 122 40617 CER. 0.1µF 50V DD38104010
CL21 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CL22 4822 122 40617 CER. 0.1µF 50V DD38104010
CL23 4822 124 90353 ELECT. 100µF 10V OA10701020
CL25 4822 124 40763 ELECT. 2.2µF 50V OA22505020
CL26 4822 124 41543 ELECT. 1µF 50V OA10505020
CL27 5322 122 32143 CER. 22pF J CH 50 DD15220300
CL28 4822 126 11591 CER. 24pF J CH 50 DD15240300
CL29 5322 122 32143 CER. 22pF J CH 50 DD15220300
CL30 5322 122 32143 CER. 22pF J CH 50 DD15220300
CL31 5322 124 21731 ELECT. 10µF 50V OA10605020
CL33 4822 124 41543 ELECT. 1µF 50V OA10505020
CL34 4822 122 40617 CER. 0.1µF 50V DD38104010
CL35 4822 124 90353 ELECT. 100µF 10V OA10701020
CL36 4822 124 41543 ELECT. 1µF 50V OA10505020
CL37 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL38 4822 124 90352 ELECT. 10µF 16V OA10601620
CL39 4822 124 90352 ELECT. 10µF 16V OA10601620
CL40
9965 000 01569 CER. 0.01µF 50V DD38103010
CL43
CL45 4822 122 40617 CER. 0.1µF 50V DD38104010
CL46 /L,/N,/S 5322 122 32143 CER. 22pF J CH 50V BLK DD15220300
CL47 /L,/N,/S 5322 122 32143 CER. 22pF J CH 50V BLK DD15220300
CX80 /N,/S 5322 122 32143 CER. 22pF J CH 50V BLK DD15220300
CX87 /N,/S 5322 122 32143 CER. 22pF J CH 50V BLK DD15220300
PL04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CL32 CL44
PL04-RESISTORS
RL05 4822 111 41355 75Ω J 1/6W GD05750160
RL07 4822 111 41355 75Ω J 1/6W GD05750160
RL08 4822 111 41355 75Ω J 1/6W GD05750160
RL09
4822 122 40586 CER. 10000pF DA17103110
RL13
RL28 JUMPER 75060501P0
RL33 /F JUMPER 75060501P0
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
