59
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PL04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RL01-RL04 RL06
RL14-RL21 RL23-RL27 RL29
RL30-RL32 RL36-RL41
PL04-SEMICONDUCTORS
DL01 4822 130 32362 DIODE HD20002000
QL01 9965 000 09133 IC NJM2296 DVIDEO SW HC10217090
QL02 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QL03 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QL04 4822 209 15524 IC OSD IC LC74781 HC10377030
QL05
/L,/N,/S 4822 130 61227 DIG.TRS BA10001000
QL07 DTA114ES UN4111 10K 10K
QL08 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QL09 5322 209 11532 IC 74HC4094 16PIN DIP HC709449B0
PL04-MISCELLANEOUS
JL01 9965 000 07100 TERMINAL 14X14 RCA 1L3P Y YT02030600
JL02 9965 000 07100 TERMINAL 14X14 RCA 1L3P Y YT02030600
JL03 4822 265 11619 TERMINAL 14X14 RCA 1L2P Y YT02021630
LL01 4822 157 62922 CHOKE COIL 33µH J LC13333800
LL02 4822 242 73843 EMI FILTER 0.022µF FM12223010
LL03 4822 242 73843 EMI FILTER 0.022µF FM12223010
XL01 4822 242 80288 CRYSTAL .31818MHz JX14001260
XL02 /L,/N,/S 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
PL54-S-VIDEO
CIRCUIT BOARD
PL54-CAPACITORS
CX01 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX02 5322 124 21731 ELECT. 10µF 50V OA10605020
CX03 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX04 5322 124 21731 ELECT. 10µF 50V OA10605020
CX05 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX06 5322 124 21731 ELECT. 10µF 50V OA10605020
CX07 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX08 5322 124 21731 ELECT. 10µF 50V OA10605020
CX09 4822 124 41796 ELECT. 22µF 16V OA22601620
CX10 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CX11 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX12 5322 124 21731 ELECT. 10µF 50V OA10605020
CX13 4822 124 41796 ELECT. 22µF 16V OA22601620
CX14 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CX15 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX16 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CX17 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX18 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX19 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX20 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX21 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX22 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CX23 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CX24 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CX25 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CX26
4822 122 40617 CER. 0.1µF 50V DD38104010
CX29
CX30 4822 122 31205 CER. 47pF J CH 50V BLK DD15470300
CX31 4822 122 31205 CER. 47pF J CH 50V BLK DD15470300
CX32 5322 124 21731 ELECT. 10µF 50V OA10605020
CX33 4822 124 40763 ELECT. 2.2µF 50V OA22505020
CX34 4822 124 41543 ELECT. 1µF 50V OA10505020
CX35 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CX36 4822 122 40617 CER. 0.1µF 50V DD38104010
CX37 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CX38 4822 124 90353 ELECT. 100µF 10V OA10701020
CX39 4822 122 40617 CER. 0.1µF 50V DD38104010
CX41 5322 122 32143 CER. 22pF J CH 50 DD15220300
CX42 4822 126 11591 CER. 24pF J CH 50 DD15240300
CX43 5322 122 32143 CER. 22pF J CH 50 DD15220300
CX44 5322 122 32143 CER. 22pF J CH 50 DD15220300
CX45 CER. 1200pF DK16122300
CX46 4822 124 41543 ELECT. 1µF 50V OA10505020
CX47 4822 124 41543 ELECT. 1µF 50V OA10505020
CX48 4822 122 40617 CER. 0.1µF 50V DD38104010
CX49 4822 124 90353 ELECT. 100µF 10V OA10701020
CX50 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX51 5322 124 21731 ELECT. 10µF 50V OA10605020
CX52 4822 122 40617 CER. 0.1µF 50V DD38104010
CX53
4822 122 30043 CER. 0.01µF Z 50V DK18103310
CX56
CX57 4822 122 40617 CER. 0.1µF 50V DD38104010
CX58 4822 124 90353 ELECT. 100µF 10V OA10701020
CX59 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CX60
4822 122 31205 CER. 47pF J CH 50V BLK DD15470300
CX63
CX64
4822 122 40586 CER. 10000pF DA17103110
CX69
CX70
5322 124 21731 ELECT. 10µF 50V OA10605020
CX75
CX76 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CX77 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CX78 9965 000 01040 ELECT. 470µF 6.3V OA47700620
CX80 /L 5322 122 32143 CER. 22pF J CH 50V BLK DD15220300
CX82 4822 122 40617 CER. 0.1µF 50V DD38104010
CX83 4822 124 41537 ELECT. 220µF 6.3V OA22700620
CX84 4822 122 40617 CER. 0.1µF 50V DD38104010
CX85 4822 122 40617 CER. 0.1µF 50V DD38104010
CX86 4822 124 11947 ELECT. 10µF 16V EQ10601630
CX87 /L 5322 122 32143 CER. 22pF J CH 50V BLK DD15220300
CX88 4822 124 90352 ELECT. 10µF 16V OA10601620
CX89 4822 124 90352 ELECT. 10µF 16V OA10601620
CX90
9965 000 01569 CER. 0.01µF 50V DD38103010
CX93
CX94 4822 122 40617 CER. 0.1µF 50V DD38104010
CX95 4822 124 41537 ELECT. 220µF 6.3V OA22700620
CX96 4822 122 40586 CER. 10000pF DA17103110
CX97 4822 122 40586 CER. 10000pF DA17103110
CX98 4822 122 40586 CER. 10000pF DA17103110
PL54-RESISTORS
RX09 4822 111 41355 75Ω J 1/6W GD05750160
RX10 4822 111 41355 75Ω J 1/6W GD05750160
RX13
4822 111 41355 75Ω J 1/6W GD05750160
RX16
RX17
4822 122 40586 CER. 10000pF DA17103110
RX21
RX39 JUMPER 75060501P0
RX41 /F JUMPER 75060501P0
RX70
4822 111 41355 75Ω J 1/6W GD05750160
RX75
RX77 JUMPER 75060501P0
RX78 JUMPER 75060501P0
RX82 4822 111 41355 75Ω J 1/6W GD05750160
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
