60
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RX83 4822 111 41355 75Ω J 1/6W GD05750160
RX84 4822 111 41355 75Ω J 1/6W GD05750160
PL54-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RX01-RX08 RX11
RX12 RX22-RX38 RX40 RX42
RX43-RX45 RX47-RX62
PL54-SEMICONDUCTORS
DX01 4822 130 32362 DIODE HD20002000
DX02 4822 130 32362 DIODE HD20002000
DX03 4822 130 32362 DIODE HD20002000
DX04 9965 000 01374 ZENER DIODE MTZ2.7B HD30271000
DX05 4822 130 32362 DIODE HD20002000
QX01 9965 000 09133 IC NJM2296 DVIDEO SW HC10217090
QX02 9965 000 09133 IC NJM2296D VIDEO SW HC10217090
QX03 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QX04 9965 000 09136 IC NJM2264 HC10185090
QX05 4822 209 15524 IC LC74781 OSD HC10377030
QX06 /L,/N,/S 4822 130 61189 DIG.TRS.
DTC114TS UN4215 10K
BA20004000
QX07 /L,/N,/S 4822 130 61189 DIG.TRS.
DTC114TS UN4215 10K
BA20004000
QX08 /L,/N,/S 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
QX09 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QX10 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QX11 9965 000 01380 IC C-MOS IC 74HC4051 HC705100B0
QX12 4822 209 83088 IC NJM2903D DUAL COMPAR. HC10022090
QX13 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QX14 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QX70 9965 000 09137 IC RGB VIDEO SW MAX499 HC10141990
PL54-MISCELLANEOUS
JX01 9965 000 01375 TERMINAL 3P S-VIDEO GOLD YT02030550
JX02 9965 000 01375 TERMINAL 3P S-VIDEO GOLD YT02030550
JX03 9965 000 01376 TERMINAL 2P S-VIDEO GOLD YT02021520
JX04 9965 000 09134 TERMINAL DVD COMPONENT YT02030680
JX05 9965 000 09134 TERMINAL DBS/VCR2 COMP. YT02030680
JX06 9965 000 09135 TERMINAL 3P RCA - YT02030580
LX01 4822 157 62922 CHOKE COIL 33µH J LC13333800
LX02 4822 242 73843 EMI FILTER 0.022µF FM12223010
LX03 4822 242 73843 EMI FILTER 0.022µF FM12223010
XX01 4822 242 80288 CRYSTAL 14.31818MHz JX14001260
XX02 /L 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
XX02 /N 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
XX02 /S 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
PS04-FUNCTION
CIRCUIT BOARD
PS04-CAPACITORS
CS01 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS01 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS02 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS02 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS03 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS03 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS04 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS04 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS05 9965 000 05891 FILM 470pF J 100V OF15471540
CS06 9965 000 05891 FILM 470pF J 100V OF15471540
CS07 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS07 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS08 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS08 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS09 4822 124 90362 ELECT. 22µF 50V OA22605020
CS10 4822 124 90362 ELECT. 22µF 50V OA22605020
CS11 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS11 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS12 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS12 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS13 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS13 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS14 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS14 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS15 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS15 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS16 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS16 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS17 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS17 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS18 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS18 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS19 4822 124 90362 ELECT. 22µF 50V OA22605020
CS20 4822 124 90362 ELECT. 22µF 50V OA22605020
CS21 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS21 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS22 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CS22 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CS23 9965 000 05891 FILM 470pF J 100V OF15471540
CS24 9965 000 05891 FILM 470pF J 100V OF15471540
CS25
9965 000 01344 FILM 100pF J 100V OF15101540
CS28
CS29 4822 124 90362 ELECT. 22µF 50V OA22605020
CS30 4822 124 90362 ELECT. 22µF 50V OA22605020
CS31 9965 000 01344 FILM 100pF J 100V OF15101540
CS32 9965 000 01344 FILM 100pF J 100V OF15101540
CS33 9965 000 05891 FILM 470pF J 100V OF15471540
CS34 9965 000 05891 FILM 470pF J 100V OF15471540
CS35
9965 000 01344 FILM 100pF J 100V OF15101540
CS39
CS40 9965 000 01344 FILM 100pF J 100V OF15101540
CS41 9965 000 01344 FILM 100pF J 100V OF15101540
CS42 9965 000 01344 FILM 100pF J 100V OF15101540
CS43 9965 000 05891 FILM 470pF J 100V OF15471540
CS44 9965 000 05891 FILM 470pF J 100V OF15471540
CS45 9965 000 01344 FILM 100pF J 100V OF15101540
CS46 9965 000 01344 FILM 100pF J 100V OF15101540
CS47 4822 124 90362 ELECT. 22µF 50V OA22605020
CS48 4822 124 90362 ELECT. 22µF 50V OA22605020
CS49
4822 122 40617 CER. 0.1µF 50V DD38104010
CS56
CS57 5322 124 21731 ELECT. 10µF 50V OA10605020
CS58 5322 124 21731 ELECT. 10µF 50V OA10605020
CS59 9965 000 01344 FILM 100pF J 100V OF15101540
CS60 9965 000 01344 FILM 100pF J 100V OF15101540
CS61 5322 124 21731 ELECT. 10µF 50V OA10605020
CS62 5322 124 21731 ELECT. 10µF 50V OA10605020
CS63 4822 121 42327 FILM DF15471350
CS64 4822 121 42327 FILM DF15471350
CS65 4822 122 40617 CER. 0.1µF 50V DD38104010
CS66 4822 122 40617 CER. 0.1µF 50V DD38104010
CS67 4822 124 90362 ELECT. 22µF 50V OA22605020
CS68 4822 124 90362 ELECT. 22µF 50V OA22605020
CS69 9965 000 01344 FILM 100pF J 100V OF15101540
CS70 9965 000 01344 FILM 100pF J 100V OF15101540
CS73 4822 124 90362 ELECT. 22µF 50V OA22605020
CS74 4822 124 90362 ELECT. 22µF 50V OA22605020
CS75 4822 121 42327 FILM 470pF DF15471350
CS76 4822 121 42327 FILM 470pF DF15471350
CS77 4822 124 90362 ELECT. 22µF 50V OA22605020
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
