61
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CS78 4822 124 90362 ELECT. 22µF 50V OA22605020
CS79 4822 121 10792 FILM 220pF J 100V OF15221540
CS80 4822 121 10792 FILM 220pF J 100V OF15221540
CS83 4822 124 90362 ELECT. 22µF 50V OA22605020
CS84 4822 124 90362 ELECT. 22µF 50V OA22605020
CS85 4822 121 10792 FILM 220pF J 100V OF15221540
CS86 4822 121 10792 FILM 220pF J 100V OF15221540
CS87 4822 122 40617 CER. 0.1µF 50V DD38104010
CS88 4822 122 40617 CER. 0.1µF 50V DD38104010
CS92
CS93 9965 000 01569 CER. 0.01µF 50V DD38103010
CS94 9965 000 01569 CER. 0.01µF 50V DD38103010
CS95
CS96 4822 124 90354 ELECT. 100µF 16V OA10701620
CS97 4822 124 90354 ELECT. 100µF 16V OA10701620
C401 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
C402 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
C403 /F,/L 4822 121 10792 FILM 220pF 100V PP OF15221540
C403 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
C404 /F,/L 4822 121 10792 FILM 220pF 100V PP OF15221540
C404 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
C405 5322 124 21731 ELECT. 10µF 50V OA10605020
C406 5322 124 21731 ELECT. 10µF 50V OA10605020
C407 4822 121 70437 FILM 1000pF 100V OF15102540
C408 4822 121 70437 FILM 1000pF 100V OF15102540
C409 4822 124 12276 FILM 0.01µF 100V OF15103540
C410 4822 124 12276 FILM 0.01µF 100V OF15103540
C413 4822 124 22277 ELECT. 470µF 16V M OA47701620
C414 4822 124 22277 ELECT. 470µF 16V OA47701620
C415 4822 124 90362 ELECT. 22µF 50V OA22605020
C416 4822 124 90362 ELECT. 22µF 50V OA22605020
C419 4822 122 40617 CER. 0.1µF 50V DD38104010
C420 4822 122 40617 CER. 0.1µF 50V DD38104010
C421 4822 124 12404 ELECT. 220µF 16V OA22701620
C422 4822 124 12404 ELECT. 220µF 16V OA22701620
C423
4822 122 40617 CER. 0.1µF 50V DD38104010
C427
PS04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CS89 CS90
PLASTIC FILM CAPACITOR
±5% 50V :
C411 C412 C417 C418
PS04-RESISTORS
RS57
0Ω J 1/6W GD05000160
RS70
RS82 4822 052 10109 10Ω ±5% 1/6W GG05100160
RS83 4822 052 10109 10Ω ±5% 1/6W GG05100160
R401 /N,/S 4822 156 11019 CHOKE COIL 320mH TOROID. LC13240010
R402 /N,/S 4822 156 11019 CHOKE COIL 320mH TOROID. LC13240010
R423 4822 052 10109 10Ω ±5% 1/6W GG05100160
R424 4822 052 10109 10Ω ±5% 1/6W GG05100160
R425 4822 052 10109 10Ω 1/6W GG05100160
PS04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R401-R406
R411-R422 RS01-RS54
RS59-RS66 RS71-RS74
RS77-RS81
PS04-SEMICONDUCTORS
QS01 4822 209 32553 IC LC78212 HC10309030
QS02 4822 209 32552 IC LC78211 HC10308030
QS03 4822 209 73064 IC NJM-2068-DD HC10053090
QS04 4822 209 73064 IC NJM-2068-DD HC10053090
QS05 4822 209 32553 IC LC78212 HC10309030
QS06 4822 209 73064 IC NJM-2068-DD HC10053090
Q405 4822 209 73064 IC NJM-2068-DD HC10053090
PS04-MISCELLANEOUS
JS01
9965 000 09131 TERMINAL YKC21-3439 YT02060510
JS04
J401 4822 290 61242 TERMINAL 14X14 RA 2L2P B YT02021360
LS01 4822 242 73843 EMI FILTER 0.022uF FM12223010
LS03 4822 242 73843 EMI FILTER 0.022uF FM12223010
PU04-FRONT(CPU/FL)
CIRCUIT BOARD
PU04-CAPACITORS
CU01
4822 126 11558 CER. 0.1µF 50V DA17104110
CU06
CU07 4822 126 10364 CER. 100pF 50V DA16101110
CU08 4822 126 10364 CER. 100pF 50V DA16101110
CU09 4822 126 11558 CER. 0.1µF 50V DA17104110
CU10 4822 126 11558 CER. 0.1µF 50V DA17104110
CU11 4822 126 10513 CER. 47pF DA15470110
CU12 4822 126 11558 CER. 0.1µF 50V DA17104110
CU13 4822 122 33639 CER. 1000pF 50V DA16102110
CU14 4822 122 40617 CER. 0.1µF 50V DD38104010
CU15 4822 126 10935 ELECT. 100µF 6.3V EJ10700610
CU17 4822 126 11558 CER. 0.1µF 50V DA17104110
CU18 4822 126 11558 CER. 0.1µF 50V DA17104110
CU21 4822 122 40617 CER. 0.1µF 50V DD38104010
CU22 5322 124 21731 ELECT. 10µF 50V OA10605020
CU23 4822 122 40588 CER. 22000pF 25V DA17223110
CU24 4822 122 40617 CER. 0.1µF 50V DD38104010
CU25 4822 122 40617 CER. 0.1µF 50V DD38104010
CU28 4822 122 40617 CER. 0.1µF 50V DD38104010
CU41 4822 122 40617 CER. 0.1µF 50V DD38104010
CU42 4822 124 23056 ELECT. 47µF 10V EJ47601010
CU43 4822 122 40617 CER. 0.1µF 50V DD38104010
CU44 4822 124 23056 ELECT. 47µF 10V EJ47601010
CU45 4822 126 10364 CER. 100pF 50V DA16101110
CU46 4822 126 10364 CER. 100pF 50V DA16101110
CU50 4822 122 40617 CER. 0.1µF 50V DD38104010
CU51 CER. 100pF DK16101300
PU04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RU01-RU05 RU07
RU08 RU10-RU28 RU34 RU35
RU41-RU49 RU51 RU52 RU57
RU58-RU66 RU68-RU71 RU80
RU81-RU89
PU04-SEMICONDUCTORS
DU01 4822 130 32362 DIODE HD20002000
DU50
4822 130 32362 DIODE HD20002000
DU59
DU80
4822 130 11569 L.E.D. LHMF-K2 RED HI10005340
DU89
QU01 9965 000 09125 IC TMP93PW44ADF
PROGRAMED
*
HS330JT3R
QU02 9965 000 03868 IC ML9205-01GA FL DRIVER HC10039260
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
