Marantz PS-17 - Page 44

62
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QU03 9965 000 08235 IC AT24C04N-10SI-2.5 HC10033990
QU04 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QU05 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QU06 4822 130 42594 DIG.TRS. DTC144ES BA20002000
QU07 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QU08 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QU09 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QU10 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
QU11 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QU12 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
QU13 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QU38 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QU39 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QU51 5322 209 11532 IC 74HC4094 16PIN HC709449B0
QU52
4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QU56
QU57 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
QU58 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
QU80 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
QU81 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
PU04-MISCELLANEOUS
JU01 JACK 29FE-ST-VK-N YJ07020250
LU01 4822 242 73843 EMI FILTER 0.022uF FM12223010
SU01
9965 000 00373 TACT SWITCH SP01013370
SU16
VU01 9965 000 09126 DISPLAY UNIT 24-BT-12GN F HQ32402410
XU01 9965 000 01346 SERAMIC VIB.
CERALOCK 20MHz
FQ02005030
PU34-TEMP. METER
CIRCUIT BOARD
CU30 4822 126 11558 CER. 0.1µF 50V DA17104110
MU30 4822 134 40925 LAMP 8V 100mA LAMP
(DC IGN.)BLUE
IN10080680
MU31 4822 344 14034 D.C METER MG-28 IM11030030
RU30 4822 052 10109 10Ω ±5% 1/6W GG05100160
PU44-DOOR SW
CIRCUIT BOARD
SU40 9965 000 09124 MINI SWITCH SPPB5A0100 SM01013100
PU54-CONNECTOR
CIRCUIT BOARD
JU50 JACK 29FE-BT-VK-N 29PIN YJ07020620
PU64-IR SENSOR
CIRCUIT BOARD
CU61 4822 122 40588 CER. 22000pF 25V DA17223110
CU62 4822 124 80087 ELECT. 220µF 6.3V EJ22700610
RU67 100Ω 1/6W GD05101160
QU60 4822 130 63211 DIG.TRS. DTA114TS UN4115
KRA111M 10K
BA10004000
QU61 4822 209 16157 PHOTO UNIT PNA4655M00XB
IR SENSOR
HW10005020
PU74-FUNC.SEL.SW
CIRCUIT BOARD
RU72 4822 117 10158 1Ω UKIBOUSHI GG05010140
SU70 4822 273 20368 ROTARY SWITCH
SRRSIC-F12-1 L30
SR01120070
PU94-MASTER VOL.
CIRCUIT BOARD
PU94-CAPACITORS
CU90 ELECT. 100µF 50V EA10700610
CU91 9965 000 01569 CER. 0.01µF 50V DD38103010
CU92 9965 000 01569 CER. 0.01µF 50V DD38103010
CU93 9965 000 01569 CER. 0.01µF 50V DD38103010
CU94 CER. 470pF 25V DK16471300
CU95 CER. 470pF 25V DK16471300
CU96 9965 000 01569 CER. 0.01µF 50V DD38103010
CU97 9965 000 01569 CER. 0.01µF 50V DD38103010
CU98 9965 000 01569 CER. 0.01µF 50V DD38103010
CU99 ELECT. 100µF 50V EA10700610
PU94-RESISTORS
RU90 4822 052 10109 10Ω 1/6W GG05100160
RU91 100Ω 1/6W GD05101160
RU92 100Ω 1/6W GD05101160
RU93 4822 052 10109 10Ω 1/6W GG05100160
RU94 4822 052 10109 10Ω 1/6W GG05100160
RU95 9965 000 09123 VARI. 5kΩ B RK16312MC M9 RY05020010
PU94-SEMICONDUCTORS
DU90 4822 130 10667 ZENER DIODE NTJ4.7B 4.7V HD30471000
QU90 4822 209 30193 IC LB1641 MOTOR DRIVER HC10279030
PW04-HEADPHONE
CIRCUIT BOARD
CW50 4822 122 40586 CER. 10000pF DA17103110
CW51 4822 122 40586 CER. 0.01µF 16V DA17103110
CW52 4822 122 40617 CER. 0.1µF 50V DD38104010
CW53 4822 122 40586 CER. 0.01µF 16V DA17103110
JW50 4822 265 11525 H.P JACK GLD
HLJ2307-01-3163
YJ01004330
JW51 4822 267 30894 JACK B4B-PH-K-S YJ06006240
P604-DSP/ADC/DAC
CIRCUIT BOARD
P604-CAPACITORS
CC01 5322 124 21731 ELECT. 10µF 50V OA10605020
CC02 5322 124 21731 ELECT. 10µF 50V OA10605020
CC03 4822 126 11703 CER. CHIP 0.01uF DK98103300
CC04 4822 126 11703 CER. CHIP 0.01uF DK98103300
CC05 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC06 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC07 4822 124 90353 ELECT. 100µF 10V OA10701020
CC08 4822 124 90353 ELECT. 100µF 10V OA10701020
CC09 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC10 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC11 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
CC12 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
CC21 5322 124 21731 ELECT. 10µF 50V OA10605020
CC22 5322 124 21731 ELECT. 10µF 50V OA10605020
CC23 4822 126 11703 CER. CHIP 0.01uF DK98103300
CC24 4822 126 11703 CER. CHIP 0.01uF DK98103300
CC25 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC26 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC27 4822 124 90353 ELECT. 100µF 10V OA10701020
CC28 4822 124 90353 ELECT. 100µF 10V OA10701020
CC29 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC30 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC31 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CC32 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CC51 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC52 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC55 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CC56 4822 122 10172 CER. CHIP 220pF 50V DK96221300
CD01 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CD02 4822 124 90353 ELECT. 100µF 10V OA10701020
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
