Marantz PS-17 - Page 50

68
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q604 9965 000 09116 IC AK7706VT DSP HC10032480
Q605 9965 000 09117 IC ICS502M HC10142990
Q606 4822 209 12079 IC TCW125FU HC715300Z0
Q607 4822 209 90597 IC TCW125FU HC10409050
Q608 9965 000 09118 IC XCB56362PV100 HC10112170
Q609 9965 000 09119 IC TMP93PW44ADF
PROGRAMMED
HS330JT2R
Q610 9965 000 09120 IC SRAM 1M 3.3V 10NS HC10143990
Q611 9965 000 09120 IC SRAM 1M 3.3V 10NS HC10143990
Q612 9965 000 09120 IC SRAM 1M 3.3V 10NS HC10143990
Q613 4822 209 90685 IC TC7SH04FU HC007705K0
Q614 4822 209 90685 IC TC7SH04FU HC007705K0
Q615 9965 000 01326 IC TCW32FU HC10419050
Q616 4822 209 90685 IC TC7SH04FU HC007705K0
Q651 9965 000 09121 IC µPD78F0034GC-AB8
PROGRAMMED
HS330JN0R
Q652 4822 209 12848 IC 74HC573 FLAT HC757300R0
Q653 9965 000 09122 IC 4M EEPROM
PROGRAMMED
HC330JSTR
Q654 4822 209 13267 IC TC74HCT7007AF SOP HC800705Q0
Q655 9965 000 06673 IC TC7WHU04FµF
TRIPLE INVERTER
HC008005K0
Q694 4822 209 33521 IC TC7W04FU HC10382050
Q695 4822 209 32921 IC S-80745AN HC10048530
P604-MISCELLANEOUS
JR01 4822 267 41157 TERMINAL 14X14 RA 1L3P B YT02030610
JR04 9322 155 48687 OPT RECEIVER P1FA550RZ YJ15000180
JR05 9322 155 48687 OPT RECEIVER P1FA550RZ YJ15000180
JR06 9322 155 48687 OPT RECEIVER P1FA550RZ YJ15000180
JR07 4822 290 81638 TERMINAL 14X14 RA 1L1P B YT02010790
JR08 9322 155 28667 OPT OUTPUT P1FA550TZ YJ15000190
JR12 9965 000 03413 TERMINAL 14X14 RCA 1L2P O YT02021640
LD01
4822 526 10584 FERRITE CORE FC90090010
LD08 ZBF-503D-00TA
LD09
4822 157 10884 INDUCTOR BLM11 FN31000010
LD12
LD59 4822 242 73843 EMI FILTER 0.022uF FM12223010
LK01
4822 526 10584 FERRITE FC90090010
LK03 CORE ZBF-503D-00TA
LK05 4822 526 10584 FERRITE CORE
ZBF-503D-00TA
FC90090010
LK41
4822 526 10584 FERRITE CORE FC90090010
LK49 ZBF-503D-00TA
LR01 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LR02 4822 242 73843 EMI FILTER 0.022uF FM12223010
LR50
4822 242 73843 EMI FILTER 0.022uF FM12223010
LR53
LR54 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LR55
4822 242 73843 EMI FILTER 0.022uF FM12223010
LR58
L602 4822 242 73843 EMI FILTER 0.022uF FM12223010
L650 4822 526 10584 FERRITE CORE
ZBF-503D-00TA
FC90090010
L651 4822 242 73843 EMI FILTER 0.022uF FM12223010
L692
4822 157 10884 INDUCTOR BLM11 FN31000010
L698
X601 4822 242 10851 CRYSTAL 12.288MHz AT-49 JX12013260
X692 9965 000 01346 CERAMIC VIB. CST20 00MXW FQ02005030
X693 9965 000 04977 CERAMIC VIB.
CSTS MG 8MHz 15pF
FQ08004060
P704-MAIN AMP LCH
CIRCUIT BOARD
P704-CAPACITORS
C701 9965 000 01560 FILM 270pF ±5% 100V OFC OF55271540
C702 4822 121 10867 FILM 0.1µF ±5% 100V OFC OF55104540
C703 4822 124 90365 ELECT. 220µF M 25V RA-2 OA22702520
C704 4822 124 90365 ELECT. 220µF M 25V RA-2 OA22702520
C705 9965 000 01561 MICA 10pF ±0.5pF 500V FE DF31100520
C707 4822 124 23562 ELECT. 10µF M 100V RA-2 OA10610020
C708 4822 124 12276 FILM 0.01µF 100V PP OF15103540
C710 4822 124 22273 ELECT. 0.47µF M 50V RA-2 OA47405020
C711 9965 000 01562 ELECT. 10µF M 50V RA2BP EQ10605090
C712 9965 000 01562 ELECT. 10µF M 50V RA2BP EQ10605090
C713 9965 000 02014 ELECT. 220µF 50V ARS OA22705040
C714 9965 000 02014 ELECT. 220µF 50V ARS OA22705040
C715 9965 000 01564 FILM 680pF ±5% 100V OFC OF55681540
P704-RESISTORS
R705 4822 111 20413 220
Ω
±1% 1/4W ERD NR01221140
R707 4822 052 10102 1k
Ω
±5% 1/6W GG05102160
R708 4822 052 10102 1k
Ω
±5% 1/6W GG05102160
R709 4822 111 31001 330
Ω
±5% 1/6W GG05331160
R710 4822 111 31001 330
Ω
±5% 1/6W GG05331160
R713 9965 000 01565 68
Ω
±1% 1/4W ERD NR01680140
R714 4822 111 20413 220
Ω
±1% 1/4W ERD NR01221140
R715 4822 111 20413 220
Ω
±1% 1/4W ERD NR01221140
R716 4822 111 20413 220
Ω
±1% 1/4W ERD NR01221140
R717 4822 050 23308 3.3M
Ω
±5% 1/6W GD05335160
R718 4822 050 23308 3.3M
Ω
±5% 1/6W GD05335160
R719 4822 050 23308 3.3M
Ω
±5% 1/6W GD05335160
R721
4822 116 52115 680
Ω
±5% 1W GA05681010
R724
R727 9965 000 01566 TRIM. 2.2K
Ω
VERT RA02220760
R728 4822 052 10109 10
Ω
±5% 1/6W GG05100160
R729 4822 052 10101 100
Ω
±5% 1/6W GG05101160
R730 4822 052 10101 100
Ω
±5% 1/6W GG05101160
R731 4822 050 22209 22
Ω
±5% 1/4W GG05220140
R732 4822 050 22209 22
Ω
±5% 1/4W GG05220140
R733 4822 052 10471 470
Ω
±5% 1/6W GG05471160
R734 4822 052 10471 470
Ω
±5% 1/6W GG05471160
R735 4822 050 26809 68
Ω
±5% 1/6W GG05680160
R736 4822 050 26809 68
Ω
±5% 1/6W GG05680160
R737 4822 052 10151 150
Ω
±5% 1/6W GG05151160
R738 JUMPER 75060501P0
R739 4822 052 10109 10
Ω
±5% 1/6W GG05100160
R740 4822 052 10109 10
Ω
±5% 1/6W GG05100160
R741 4822 111 91402 FIXED 0.10
Ω
x 2 3W BZ10102010
R742 4822 052 10102 1k
Ω
±5% 1/6W GG05102160
R743 4822 052 10102 1k
Ω
±5% 1/6W GG05102160
P704-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :R701-R704 R711
R712 R720 R725 R726
R744-R747
P704-SEMICONDUCTORS
D701 4822 130 83385 ZENER DIODE HZ20L-1 HD30020010
D702 4822 130 83385 ZENER DIODE HZ20L-1 HD30020010
D703 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D704 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
*
*
*
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
