69
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
D705
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
D712 30V 0.1A
D713 4822 130 33948 ZENER DIODE 5.6V HD30561000
D714 4822 130 33948 ZENER DIODE 5.6V HD30561000
D715 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
D716 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
D717 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
Q701 9965 000 09127 UNIT & H-IC NEW HDAM KH313J1010
Q702 4822 130 60526 TRS. 2SD1508 DARLINGTON HT415080A0
Q703 4822 130 42949 TRS. 2SA970GR OR BL HT109702A0
Q704 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q705 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q706 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q707 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
Q708 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q709 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q710 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
Q711 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
Q712 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
Q713 4822 130 63635 TRS. 2SC4793 O OR Y HT347932A0
Q714 4822 130 63634 TRS. 2SA1837 O OR Y HT118372A0
Q715 4822 130 63676 TRS. 2SC3284 O P Y 125W HT332843D0
Q716 4822 130 63674 TRS. 1 2SA1303 O P Y 125W HT113033D0
Q717 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
Q718 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
P804-POWER SUPPLY
CIRCUIT BOARD
P804-CAPACITORS
CN01 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CN02 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CN03 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
CN04 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CN05 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CN06 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
CN07 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CN08 4822 124 22273 ELECT. 0.47µF M 50V RA-2 OA47405020
CN09 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CN12 /L,/N,/S 4822 122 40586 CER. 10000pF DA17103110
CN13 /L,/N,/S 4822 122 40586 CER. 10000pF DA17103110
CN14 4822 122 30043 CER. 0.01µF Z 50V DK18103310
C801 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C802 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C803 9965 000 09128 ELECT. UFW1V222MHA1AA G OC22803530
C804 9965 000 09128 ELECT. UFW1V222MHA1AA G OC22803530
C805
4822 122 30043 CER. 0.01µF Z 50V DK18103310
C808
C809 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
C810 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
C811 9965 000 08115 ELECT. OA33701640
C812 9965 000 08115 ELECT. OA33701640
C813 9965 000 01569 CER. 0.01µF +80%-20% 50V DD38103010
C814 9965 000 01569 CER. 0.01µF +80%-20% 50V DD38103010
C815 9965 000 09129 ELECT. UFW1H222MHA1AA G OC22805030
C816 9965 000 09129 ELECT. UFW1H222MHA1AA G OC22805030
C817 9965 000 01569 CER. 0.01µF +80%-20% 50V DD38103010
C818 9965 000 01569 CER. 0.01µF +80%-20% 50V DD38103010
C819 4822 124 11583 ELECT. 2200µF M 35V RA-2 OA22803520
C820 4822 124 11583 ELECT. 2200µF M 35V RA-2 OA22803520
C821 4822 122 30043 CER. 0.01µF Z 50V DK18103310
C822 4822 122 30043 CER. 0.01µF Z 50V DK18103310
C823 4822 122 40617 CER. 0.1µF +80%-20% DD38104010
C824 4822 122 40617 CER. 0.1µF +80%-20% DD38104010
C825 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C826 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C827 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C828 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C830 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
C850 4822 122 30043 CER. 0.01µF Z 50V DK18103310
C851 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C852 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C853 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
C854 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C855 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C857 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C860 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C861 4822 122 30043 CER. 0.01µF Z 50V DK18103310
C862 4822 122 30043 CER. 0.01µF Z 50V DK18103310
C870 CER. DE1607-1F 103M-KH DK17103910
C871 4822 122 30043 CER. 0.01µF Z 50V DK18103310
PV04-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±5% 50V :C856 CN10 CN11
P804-RESISTORS
RN01 4822 052 10229 22
Ω
±5% 1/6W GG05220160
RN24 4822 053 10109 10
Ω
±5% 1W GA05100010
RN25 4822 053 10109 10
Ω
±5% 1W GA05100010
R801 4822 117 10158 1
Ω
±5% 1/4W GG05010140
R802 4822 117 10158 1
Ω
±5% 1/4W GG05010140
R805 4822 116 60323 5.6
Ω
±5% 1W GA05056010
R806 4822 116 60323 5.6
Ω
±5% 1W GA05056010
R809 4822 052 10478 4.7
Ω
±5% 1/6W GG05047160
R810 4822 052 10478 4.7
Ω
±5% 1/6W GG05047160
R811 4822 050 21108 1
Ω
±5% 1/2W GG05010120
R812 4822 050 21108 1
Ω
±5% 1/2W GG05010120
R813 4822 117 10158 1
Ω
±5% 1/4W GG05010140
R814 4822 117 10158 1
Ω
±5% 1/4W GG05010140
R851 4822 052 10109 10
Ω
±5% 1/4W GG05100140
R857 0
Ω
±5% 1/6W GD05000160
R863 4822 117 10158 1
Ω
±5% 1/4W GG05010140
P804-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R803 R804 R807
R808 R852-R856 R859-R862
RN01-RN17 RN19-RN23
RN26-RN30
P804-SEMICONDUCTORS
DN01 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DN02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DN03 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DN04 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D801 4822 130 10413 BRIDGE DIODE D2SBA20 HE20027290
D803 4822 130 80674 ZENER DIODE 16V HD31601000
D804 4822 130 80674 ZENER DIODE 16V HD31601000
D805
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D814
D830 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D831 4822 130 33948 ZENER DIODE 5.6V HD30561000
D832 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D851 9322 143 37687 DIODE FCH20A15 HE10005100
D852 9965 000 09130 DIODE FRH20A15 HE10006100
D870 4822 130 82421 DIODE 1D3 1A 200V HD20002710
QN01 4822 209 83312 IC TA7317P HC10042050
QN03 4822 130 43233 TRS. 2SC2240 GR OR BL HT322402A0
QN04 4822 130 42292 TRS. 2SC2120 O HT321201A0
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
