Rear panel
rty
q w e
q AUDIO OUT connectors
Used to connect devices equipped with analog audio inputs connectors
or an external power amplifier (vpage18).
w REMOTE CONTROL IN/OUT connectors
Used to connect to a Marantz amplifier that is compatible with the
remote control function (vpage24).
e EXTERNAL/INTERNAL switch
Turn this switch to “EXTERNAL” to operate the unit by pointing the
remote control at the amplifier connected to this unit using the remote
control connection (vpage24).
r AC inlet (AC IN)
Used to connect the power cord (vpage26).
t DIGITAL AUDIO IN connectors
Used to connect devices equipped with digital audio output connectors
and PC (vpage20, 21).
y DIGITAL AUDIO OUT connectors
Used to connect an AV receiver or D/A converter equipped with digital
audio input connectors (vpage19).
