Marantz SACD 10 - Specifications; Audio Performance

Specifications
o
Audio performance
0
Analog output [Super Audio CD] [CD]
Channels: 2-channels 2-channels
Playable frequency range: 2 Hz – 100 kHz 2 Hz – 20 kHz
Playable frequency response: 2 Hz – 50 kHz (-3 dB) 2 Hz – 20 kHz (±1 dB)
S/N: 118 dB (Audible range) 116 dB
Dynamic range: 112 dB (Audible range) 98 dB
Harmonic distortion: 0.0004 % (1 kHz, Audible range) 0.0015 % (1 kHz)
Wow & flutter: Crystal accuracy Crystal accuracy
0
Output level
Unbalanced: 2.5 V (10 kΩ/kohms) 2.0 V (10 kΩ/kohms)
Balanced: 5.0 V (10 kΩ/kohms) 4.0 V (10 kΩ/kohms)
Headphone output: 130 mW/32 Ω/ohms (variable maximum) 130 mW/32 Ω/ohms (variable maximum)
0
Digital output
Coaxial: - 0.5 Vp-p / 75 Ω/ohms
Optical: - –19 dBm
0
Optical readout system
Laser: AlGaAs AlGaAs
Wave length: 650 nm 780 nm
Signal type: 1-bit DSD 16-bit linear PCM
Sampling frequency: 2.8224 MHz 44.1 kHz
