Marantz sr-18 u - Page 44

70
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C373 KS 4822 122 40617 CER. 0.1µF +80 -20% DD38104010
C374 KS 4822 122 40586 CER. 10000pF ±20% DA17103110
C501 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
C502 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
C503 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C504 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C505 4822 124 90357 ELECT. 2.2µF M 50V OA22505020
C507 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C508 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C511 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
P104-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C220 C222 C227[U] C317 C318
C367 C368 C371[K KS]
C372[K KS] C510
CC09-CC12[KS]
CC83 CV03 CV05-CV07
PLASTIC FILM CAPACITOR
±5% 50V : C217 C301 C302
C309 C310 CC01-CC04
CC14-CC17 CC75 CC76
CF07-CF14 CF23-CF30
P104-RESISTORS
RA11 4822 100 11351 TRIM. 10kΩ RH0638CJ4R RA01030780
RC51 JUMPER 75060501P0
RC52 JUMPER 75060501P0
RF37 JUMPER 75060501P0
RF38 JUMPER 75060501P0
RF39 JUMPER 75060501P0
RF40 JUMPER 75060501P0
RG55 JUMPER 75060501P0
RG56 JUMPER 75060501P0
RG59 JUMPER 75060501P0
RG60 JUMPER 75060501P0
R101 U 4822 050 21003 10kΩ ± 5% 1/2W GG05103120
R201 U JUMPER 75060501P0
R207 4822 050 21801 180Ω ± 5% 1/4W GG05181140
R211 K KS 4822 100 11352 TRIM. 22kΩ RH0638CJ4R RA02230780
R211 U 4822 100 11351 TRIM. 10kΩ RH0638CS3R RA01030780
R212 4822 100 11351 TRIM. 10kΩ RH0638CS3R RA01030780
R217 4822 050 21801 180Ω ± 5% 1/4W GG05181140
R301 U JUMPER 75060501P0
R302 U JUMPER 75060501P0
R303 U JUMPER 75060501P0
R304 U JUMPER 75060501P0
R313 K KS 4822 116 83929 220Ω ± 5% 1/4W GG05221140
R314 K KS 4822 116 83929 220Ω ± 5% 1/4W GG05221140
R356 KS 4822 053 10471 470Ω ± 5% 1W GA05471010
R512 4822 053 10271 270Ω ± 5% 1W GA05271010
R516 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
P104-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R201[K KS]
R202-R206 R208-R210
R213-R216 R220 R221[KS]
R301-R304[K KS] R307-R310
R315 R316 R352-R354[KS]
R357[KS] R502 R504-R507
R508[K U] R509-R511 R513
R515 RA01 RA02 RC01-RC33
RC35-RC42 RC53-RC62
RC71-RC82 RF01-RF36
RC41-RC46 RF48 RF49
RG51-RG54 RV01-RV14
P104-SEMICONDUCTORS
DA01 4822 125 50416 VARICAP SVC342-L TYPE HD40009030
DA02 JUMPER 75060501P0
DA05 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DA06 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DF01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DF02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DF03 DIODE 1SS201 HE10201050
DF04 DIODE 1SS201 HE10201050
DV05
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
DV12 30V 0.1A
DV13 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D201 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D202 4822 130 80319 ZENER DIODE 9.1V
RD9.1JB2 MTZJ9.1C
HD30911000
D351 KS 4822 130 80317 ZENER DIODE 5.1V
RD5.1JB2 MTZJ5.1B
HD30511000
D501 4822 130 80317 ZENER DIODE 5.1V
RD5.1JB2 MTZJ5.1B
HD30511000
QC01
4822 209 73064 IC NJM2068DD HC10053090
QC05
QC06 4822 209 32554 IC LC78213 HC10310030
QC07 4822 209 62784 IC TC9215P HC10262050
QC51 4822 209 73064 IC NJM2068DD HC10053090
QC71 4822 209 73064 IC NJM-2068-DD HC10053090
QC72 4822 209 62784 IC TC9215P ANALOGUE HC10262050
QF01 4822 209 73064 IC NJM2068DD HC10053090
QF02 IC TC9184AP ELE.TONE HC10444050
QF03 4822 209 73064 IC NJM2068DD HC10053090
QF04 IC TC9184AP ELE.TONE HC10444050
QG51 IC TC9459F ELE.VOLUME HC10443050
QG52 IC TC9459F ELE.VOLUME HC10443050
QG53 IC TC9459F ELE.VOLUME HC10443050
QG54 4822 209 17155 IC NJM2068M HC10102090
QG55 4822 209 17155 IC NJM2068M HC10102090
QV01 4822 209 90532 IC NJU3713D HC10161090
QV02
4822 130 61227 DIG.TRS. DTA114ES UN4111 BA10001000
QV05 10K 10K
QV06 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QV07
4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QV12
Q201 IC LA1837 FM/AM IF/MPX IC HC10384030
Q202 4822 130 62294 TRS. 2SC1809S P 150MW
500MHz
HT318091P0
Q203 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
Q204 4822 130 42594 DIG.TRS. DTC144ES UN4213
47K 47K
BA20002000
Q209 KS 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC
HT30001000
Q301 K KS 4822 209 83631 IC NJM4558D-D HC10008090
Q351 KS 4822 209 16175 IC LC72720L RDS DECODER HC10385030
Q352 KS 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
Q353 KS 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
Q501 IC LC72130 HC10394030
