Marantz sr-18 u - Page 45

71
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P104-MISCELLANEOUS
A101 K KS U VHF TUNER TFFJ4E AV00903010
FA01 CER. FILTER SFZ450JL3 451K FF10045410
F201 K KS 4822 242 70665 CER. FILTER SFE10.7MS3-A FF11070620
F201 U 4822 242 70911 CER. FILTER SFF10.7MA8-A FF11070610
F202 4822 242 70665 CER. FILTER SFE10.7MS3-A FF11070620
JC04 JACK S16B-PH-K-S YJ06006370
JC05 TERMINAL 2P DIRECT IN GLD
BL/BL CNT.SWF
YT02021550
JC06 TERMINAL YKC21-3953 GLD
W/R SURR.IN L/R
YT02021500
J101 4822 290 81632 TERMINAL YKD31-0215A
FM/AM ANT PAL TYPE
YT03030020
LA01 4822 157 63084 MW ANT COIL 280µH LA10295170
LA02 4822 157 70779 OSC. COIL MW LO70013010
LA05 4822 157 53589 CHOKE COIL 39MH J LC23960710
LA06 4822 148 81095 I.F.T. COIL AM K7-H5
FOR SFP450D
LI70033510
L201 4822 157 63904 I.F.T. COIL FM DET
M292BEAS-5968Z
LI70376010
L301 4822 157 71731 M.P.X. COIL LPF-V10-A1
19/38kHz
LS10293020
L302 4822 157 71731 M.P.X. COIL LPF-V10-A1
19/38kHz
LS10293020
L350 KS
4822 157 62911 CHOKE COIL LAL02TA3R3J LC13323800
L354 KS 3.3µH
L355 KS 4822 157 62911 CHOKE COIL LAL02TA3R3J
3.3µH
LC13323800
L356 KS 4822 157 62911 CHOKE COIL LAL02TA3R3J
3.3µH
LC13323800
L359 KS 4822 157 62911 CHOKE COIL LAL02TA3R3J
3.3µH
LC13323800
L501
4822 157 70813 CHOKE COIL LAL02TA470J LC14733800
L504 47µH
S301 K 4822 277 21712 SLIDE SWITCH SSSS92 SS02021470
X351 KS 4822 242 10857 CRYSTAL 4.332MHz AT-49 JX04003260
X501 4822 242 72333 CRYSTAL AD0618CTB 7.2MHz JX07001260
P604-AC-3 DTS&THX DECODE
CIRCUIT BOARD
P604-CAPACITORS
CD01 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD02 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD03 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD05 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD06 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD07 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD09 4822 124 21894 ELECT 10µF 16V EJ10601610
CD10 4822 124 21894 ELECT 10µF 16V EJ10601610
CD11 4822 124 21894 ELECT 10µF 16V EJ10601610
CD13 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD14 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD15 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD17 4822 124 21894 ELECT 10µF 16V EJ10601610
CD18 4822 124 21894 ELECT 10µF 16V EJ10601610
CD19 4822 124 21894 ELECT 10µF 16V EJ10601610
CD21 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD22 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD23 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD25 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD26 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD27 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD29 5322 126 11578 CER. 1000pF +80%-20% CHIP DK96102300
CD30 5322 126 11578 CER. 1000pF +80%-20% CHIP DK96102300
CD31 5322 126 11578 CER. 1000pF +80%-20% CHIP DK96102300
CD41 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD42 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD43 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD44 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD45 4822 124 21894 ELECT 10µF 16V EJ10601610
CD46 4822 124 21894 ELECT 10µF 16V EJ10601610
CD47 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD48 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD49 4822 124 21894 ELECT 10µF 16V EJ10601610
CD50 4822 124 21894 ELECT 10µF 16V EJ10601610
CD51 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD52 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD53 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD54 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD55 5322 126 11578 CER. 1000pF +80%-20% CHIP DK96102300
CD56 5322 126 11578 CER. 1000pF +80%-20% CHIP DK96102300
CD61 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD62 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD63
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD74
CD81
4822 126 11703 CER. 0.01µF +80%-20% CHIP DK98103300
CD92
CD93
4822 124 90363 ELECT. 220µF M 10V RA-2 OA22701020
CD96
CD97 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
CD98 4822 124 41535 ELECT. 100µF M 25V RA-2 OA10702520
CE01 4822 126 11567 CER. 0.022µF ± 10% XTR CHIP DK96223200
CE02 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CE03 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE04 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CE05 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE06 5322 126 11578 CER. 1000pF ± 10% B CHIP DK96102300
CE11 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE13 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE14 4822 122 33753 CER. 150pF ± 5% CG 50V CHIP DD95151300
CE15 4822 122 33753 CER. 150pF ± 5% CG 50V CHIP DD95151300
CE18 4822 126 13837 CER. 0.1µF ± 10% B 10V CHIP DK96104200
CE19 4822 126 14417 CER. 0.01µF ±10% 50V CHIP DK96103300
CE33 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CE34 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE35 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CE36 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE37 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE39 ELECT 47µF 16V BP EQ47601630
CE42 4822 126 14417 CER. 0.01µF ±10% 50V CHIP DK96103300
CE43 4822 126 14417 CER. 0.01µF ±10% 50V CHIP DK96103300
CE44 4822 122 33752 CER. 18pF 50V ±5% CHIP DD95150300
CE45 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE46 4822 122 33757 CER. 18pF ±5% CHIP DD95180300
CE51 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE52 5322 126 11578 CER. 1000pF +80%-20% CHIP DK96102300
CE53 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE54 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE56
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE60
CE61 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CE62 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CE63 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CE65 4822 126 11703 CER. 0.01µF +80%-20% CHIP DK98103300
CE66 4822 126 11703 CER. 0.01µF +80%-20% CHIP DK98103300
CH05
4822 121 10792 FILM 220pF ±5% OF15221540
CH08
CH14 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CH15
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CH18
CH26 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
