Marantz sr-18 u - Page 49

75
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QR08 4822 209 90909 IC TC7W74FU D-F/F HC10400050
Q601 IC YSS912
DTS AC-3 DECODER
HC10014640
Q602 IC TC7WT241FU HC007405K0
Q603 IC TC7WT126FU HC007305K0
Q604 IC 1M SRAM 8X128K 15NS HC10088000
Q605 IC TCW32FU OR *2 HC10419050
Q651 IC ZR38600
AC-3 THX5.1 DECODER
HU300JN50F
HC10051990
Q652 IC TC7SET04F HC007205K0
Q691 IC µPD78018 CPU
Q692 IC TC7WT126FU HC007305K0
Q693 IC S-80745AN HC10048530
Q694 4822 209 12845 IC S-80730SN-DT-X RESET HC10054530
P604-MISCELLANEOUS
JE01 TERMINAL YKC21-3707 YT02011030
JR01 TERMINAL RCA 2P AU BL YT02021540
JR02 4822 218 11487 OPTICAL RECEIVER GP1F32R YJ15000150
JR03 4822 218 11487 OPTICAL RECEIVER GP1F32R YJ15000150
JR04 4822 267 31369 OPTICAL OUTPUT GP1F32T YJ15000090
JR05 4822 290 81638 TERMINAL 14X14 RA 1L1P BL YT02010790
LD01
4822 526 10584 FERRITE CORE FC90090010
LD07 ZBF503D-00TA
LD41 4822 526 10584 FERRITE CORE
FOR SURROUND CONTROL
ZBF503D-00TA
FC90090010
LD42 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD45 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD46 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD81
4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LD86
LE01 CHIP INDUCTANCE 68µH
NL322522-680K
LU12683010
LE02 4822 242 10582 L.C. FLITTER SBP-4930
2.88MHz B.P.F.
FF30288010
LE03 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LE04 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LH01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH02 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH51 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH52 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LJ01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LJ02 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LK01 4822 526 10584 FERRITE CORE
BF503D-00TA
FC90090010
LR01 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LR02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L601 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L602 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L651 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L691 4822 157 10884 EMI FILTER BLM11A221S FN31000010
L692
4822 157 10884 EMI FILTER BLM11A221S FN31000010
L697
XE01 CRYSTAL 18.432MHz AT-49 JX18001260
X601 4822 242 10851 CRYSTAL 12.288MHz AT-49 JX12013260
X691 SERAMIC VIB.
CST10.0MTW-TF01 10.0MHz
FQ01005010
P704-3CH POWER-AMP.
CIRCUIT BOARD
P704-CAPACITORS
CT01 4822 124 22275 ELECT. 47µF 10V OA47601020
CT03 FILM 470pF ±5% 100V OF15471540
CT05 FILM 470pF ±5% OF15471540
CT07 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CT11 ELECT. 220µF M 100V RA2 OA22710020
CT13 ELECT. 220µF M 100V RA2 OA22710020
CT15 4822 124 11533 ELECT. 1µF M 100V RA2 OA10510020
CT17 4822 123 30088 MICA 10pF ±0.5pF DF31100520
CT19 ELECT 4.7µF M 100V EA47510010
CT27 4822 121 70544 FILM 120pF ±5% 100V APSV OF15121540
CT29 4822 121 70544 FILM 120pF ±5% 100V APSV OF15121540
C701 4822 124 22275 ELECT. 47µF 10V OA47601020
C702 4822 124 22275 ELECT. 47µF 10V OA47601020
C703
FILM 470pF ±5% 100V OF15471540
C706
C707 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
C708 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
C711
ELECT. 220µF M 100V RA-2 OA22710020
C714
C715 4822 124 11533 ELECT. 1µF M 100V RA-2 OA10510020
C716 4822 124 11533 ELECT. 1µF M 100V RA-2 OA10510020
C717 4822 123 30088 MICA 10pF ±0.5pF DF31100520
C718 4822 123 30088 MICA 10pF ±0.5pF DF31100520
C719 ELECT 4.7µF M 100V EA47510010
C720 ELECT 4.7µF M 100V EA47510010
C727
4822 121 70544 FILM 120pF ±5% 100V APSV OF15121540
C730
P704-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C721-C726 CT21
CT23 CT25
P704-RESISTORS
RT07 1.5kΩ ±5% 1/6W GG05152160
RT09 1.5kΩ ±5% 1/6W GG05152160
RT15 4822 100 11471 TRIM. 100kΩ RH0638CJ4R RA01040780
RT25 4822 052 10561 560Ω ±5% 1/6W GG05561160
RT27 4822 052 10561 560Ω ±5% 1/6W GG05561160
RT29 4822 052 10561 560Ω ±5% 1/6W GG05561160
RT31 4822 052 10561 560Ω ±5% 1/6W GG05561160
RT33 4822 052 10569 56Ω ±5% 1/6W GG05560160
RT35 4822 052 10569 56Ω ±5% 1/6W GG05560160
RT43 4822 100 20681 TRIM. 2.2kΩ RH0638CJ3R RA02220780
RT49 4822 052 10109 10Ω ±5% 1/4W GG05100140
RT51 4822 052 10109 10Ω ±5% 1/4W GG05100140
RT53 4822 052 10101 100Ω ±5% 1/6W GG05101160
RT55 4822 052 10101 100Ω ±5% 1/6W GG05101160
RT57 JUMPER 75060501P0
RT59 JUMPER 75060501P0
RT61 4822 052 10102 1kΩ ±5% 1/6W GG05102160
RT63 4822 052 10229 22Ω ±5% 1/6W GG05220160
RT65 4822 052 10229 22Ω ±5% 1/6W GG05220160
RT67 4822 116 60319 FUSIBLE 220Ω ±5% 1/2W NH05221120
RT69 JUMPER 75060501P0
RT71 JUMPER 75060501P0
RT73 0.10Ω ±10% 5W X2 RGC55 W BZ10102020
RT75 4822 052 10102 1kΩ ±5% 1/6W GG05102160
RT77 4822 050 22202 2.2kΩ ±5% 1/6W GG05222160
RT83 4822 116 83929 220Ω ±5% 1/4W GG05221140
