Marantz sr-18 u - Electrical Parts List

76
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RT85 4822 053 10109 10Ω ±5% 1W GA05100010
R707
1.5kΩ ±5% 1/6W GG05152160
R710
R715 4822 100 11471 TRIM. 100kΩ
RH0638CJ4R
RA01040780
R716 4822 100 11471 TRIM. 100kΩ
RH0638CJ4R
RA01040780
R725
4822 052 10569 56Ω ±5% 1/6W GG05560160
R736
R743 4822 100 20681 TRIM. 2.2kΩ RH0638CJ3R RA02220780
R744 4822 100 20681 TRIM. 2.2kΩ RH0638CJ3R RA02220780
R749
4822 052 10109 10Ω ±5% 1/4W GG05100140
R752
R753
4822 052 10101 100Ω ±5% 1/6W GG05101160
R756
R757
JUMPER 75060501P0
R760
R761 4822 052 10102 1kΩ ±5% 1/6W GG05102160
R762 4822 052 10102 1kΩ ±5% 1/6W GG05102160
R763
4822 052 10229 22Ω ±5% 1/6W GG05220160
R766
R767 4822 116 60319 FUSIBLE 220Ω ±5% 1/2W NH05221120
R768 4822 116 60319 FUSIBLE 220Ω ±5% 1/2W NH05221120
R769
JUMPER 75060501P0
R772
R773 FIXED 0.10Ω ±10% 5W X2
RGC55 W TP
BZ10102020
R774 FIXED 0.10Ω ±10% 5W X2
RGC55 W TP
BZ10102020
R775 4822 052 10102 1kΩ ±5% 1/6W GG05102160
R776 4822 052 10102 1kΩ ±5% 1/6W GG05102160
R777 4822 050 22202 2.2kΩ ±5% 1/6W GG05222160
R778 4822 050 22202 2.2kΩ ±5% 1/6W GG05222160
R783 4822 116 83929 220Ω ±5% 1/4W GG05221140
R784 4822 116 83929 220Ω ±5% 1/4W GG05221140
R785 4822 053 10109 10Ω ±5% 1W GA05100010
R786 4822 053 10109 10Ω ±5% 1W GA05100010
P704-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R701-R706
R711-R714 R717-R724
R737-R742 R745-R748
R779-R782 R787-R790 RT01
RT03 RT05 RT11 RT13 RT17
RT19 RT21 RT23 RT37 RT39
RT41 RT45 RT47 RT79 RT81
RT87 RT89
P704-SEMICONDUCTORS
DT01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT03 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT05 JUMPER 75060501P0
DT07 JUMPER 75060501P0
DT09 JUMPER 75060501P0
DT11 JUMPER 75060501P0
DT13 4822 130 80837 DIODE HSS81 HD20027010
DT15 4822 130 80837 DIODE HSS81 HD20027010
DT17 4822 130 80317 ZENER DIODE NTJ5.1B 5.1V HD30511000
DT19 4822 130 80317 ZENER DIODE NTJ5.1B 5.1V HD30511000
DT21 4822 130 80837 DIODE HSS81 HD20027010
D701
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
D704 30V 0.1A
D705
JUMPER 75060501P0
D712
D713
4822 130 80837 DIODE HSS81 HD20027010
D716
D717
4822 130 80317 ZENER DIODE NTJ5.1B 5.1V HD30511000
D720
D721 4822 130 80837 DIODE HSS81 HD20027010
D722 4822 130 80837 DIODE HSS81 HD20027010
QT01 4822 130 42949 TRS. 2SA970 HT109702A0
QT03 4822 130 42949 TRS. 2SA970 HT109702A0
QT05 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QT07 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QT09 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QT11 5322 130 61728 TRS. 2SA1360 O Y HT113602A0
QT13 5322 130 61737 TRS. 2SC3423 O Y HT334232A0
QT17 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QT19 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QT21 4822 130 63635 TRS. 2SC4793 O Y HT347932A0
QT23 4822 130 63634 TRS. 2SA1837 O Y HT118372A0
QT29 4822 130 43233 TRS. 2SC2240 HT322402A0
Q701
4822 130 42949 TRS. 2SA970 HT109702A0
Q704
Q705 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
Q706 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
Q707
4822 130 43283 TRS. 2SC2705 O Y HT327052A0
Q710
Q711 5322 130 61728 TRS. 2SA1360 O Y HT113602A0
Q712 5322 130 61728 TRS. 2SA1360 O Y HT113602A0
Q713 5322 130 61737 TRS. 2SC3423 O Y HT334232A0
Q714 5322 130 61737 TRS. 2SC3423 O Y HT334232A0
Q717 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
Q718 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
Q719 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
Q720 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
Q721 4822 130 63635 TRS. 2SC4793 O Y HT347932A0
Q722 4822 130 63635 TRS. 2SC4793 O Y HT347932A0
Q723 4822 130 63634 TRS. 2SA1837 O Y HT118372A0
Q724 4822 130 63634 TRS. 2SA1837 O Y HT118372A0
Q729 4822 130 43233 TRS. 2SC2240 HT322402A0
Q730 4822 130 43233 TRS. 2SC2240 HT322402A0
K761
TRS. KIT 2SA1360 2SC3423 HK136019C0
K763 PAIR O Y
K766
TRS. KIT A1837 C4793 HFE HK183719C0
K768 MJI RANK
K771
4822 130 11394 TRS. KIT 2SA1216 2SC2922 HK121619F0
K773 O Y PAIR
P704-MISCELLANEOUS
LT01 4822 157 70022 AIR COIL SPK CHOCK ML08010030
L701 4822 157 70022 AIR COIL SPK CHOCK ML08010030
L702 4822 157 70022 AIR COIL SPK CHOCK ML08010030
S701 CIRCUIT BREAKER TEMP-SW
120DEG. OHD3-120B
FR31200020
S702 CIRCUIT BREAKER TEMP-SW
120DEG. OHD3-120B
FR31200020
