78
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
K764 TRS. KIT 2SA1360 2SC3423
PAIR O Y
HK136019C0
K765 TRS. KIT 2SA1360 2SC3423
PAIR O Y
HK136019C0
K769 TRS. KIT A1837 C4793
HFE MJI RANK
HK183719C0
K770 TRS. KIT A1837 C4793
HFE MJI RANK
HK183719C0
K774 4822 130 11394 TRS. KIT 2SA1216 2SC2922
O Y PAIR
HK121619F0
K775 4822 130 11394 TRS. KIT 2SA1216 2SC2922
O Y PAIR
HK121619F0
QN01 4822 209 83312 IC TA7317P HC10042050
QN02 4822 130 42594 DIG.TRS. DTC144ES UN4213
47k 47k
BA20002000
QN03 4822 130 42949 TRS. 2SA970 HT109702A0
QN04 4822 130 60526 TRS. 2SD1508 HFE>4000 HT415080A0
QN05 4822 130 42594 DIG.TRS. DTC144ES UN4213
47k 47k
BA20002000
QN06 4822 130 60696 TRS. 2SC1627 O Y HT316272B0
QN07 IC PQ30RV11 HC36930320
QN08
4822 130 41947 TRS. 2SC2458 2SC1740S HT30001000
QN10 2SC3199 ETC.
QN11 4822 130 43233 TRS. 2SC2240 HT322402A0
QN12 4822 130 43233 TRS. 2SC2240 HT322402A0
QN13 4822 130 41947 TRS. 2SC536SP ETC HT30001000
QN14 4822 130 42715 TRS. 2SA608SP ETC HT10001000
QP01
4822 130 42949 TRS. 2SA970 HT109702A0
QP04
QP05 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QP06 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QP07
4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QP10
QP11 5322 130 61728 TRS. 2SA1360 O Y HT113602A0
QP12 5322 130 61728 TRS. 2SA1360 O Y HT113602A0
QP13 5322 130 61737 TRS. 2SC3423 O Y HT334232A0
QP14 5322 130 61737 TRS. 2SC3423 O Y HT334232A0
QP15 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
QP16 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
QP17 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QP18 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QP19 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QP20 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QP21 4822 130 63635 TRS. 2SC4793 O Y HT347932A0
QP22 4822 130 63635 TRS. 2SC4793 O Y HT347932A0
QP23 4822 130 63634 TRS. 2SA1837 O Y HT118372A0
QP24 4822 130 63634 TRS. 2SA1837 O Y HT118372A0
QP25 TRS. 2SC2922 O Y HT329222A0
QP26 TRS. 2SC2922 O Y HT329222A0
QP27 TRS. 2SA1216 O Y HT112162A0
QP28 TRS. 2SA1216 O Y HT112162A0
QP29 4822 130 43233 TRS. 2SC2240 HT322402A0
QP30 4822 130 43233 TRS. 2SC2240 HT322402A0
Q861 4822 209 31631 IC NJM7805FA +5V HC38905090
Q871 4822 209 31631 IC NJM7805FA +5V HC38905090
Q881 4822 130 63635 TRS. 2SC4793 O Y HT347932A0
P754-MISCELLANEOUS
LN01 RELAY MR62-12SR LY20120510
LP01 4822 157 70022 AIR COIL SPK CHOCK ML08010030
LP02 4822 157 70022 AIR COIL SPK CHOCK ML08010030
MN51 D.C MOTOR FBA08A12H0
DC FAN 12V
MM01200320
ZN51 UNIT KIT DC FAN MOTOR
UNIT W 3P WIRE
ZK300J0020
P774-PO-AMP.TR-BLOCK 3CH
CIRCUIT BOARD
P774-SEMICONDUCTORS
D799 4822 130 43564 VARISTOR
PTH9M04BE222TS2F333
HP00004230
QT15 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
QT25 TRS. 2SC2922 O Y HT329222A0
QT27 TRS. 2SA1216 O Y HT112162A0
Q715 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
Q716 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
Q725 TRS. 2SC2922 O Y HT329222A0
Q726 TRS. 2SC2922 O Y HT329222A0
Q727 TRS. 2SA1216 O Y HT112162A0
Q728 TRS. 2SA1216 O Y HT112162A0
P804-POWER SUPPLY +/-15V
CIRCUIT BOARD
P804-CAPACITORS
C801 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C802 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C803 4822 124 81133 ELECT. 4700µF 25V OA47802520
C804 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C805 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C806 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C807 4822 124 81133 ELECT. 4700µF 25V OA47802520
C808 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C817 4822 124 22571 ELECT. 10µF M 50V OA10605020
C818 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
P804-RESISTORS
R801 JUMPER 75060501P0
R802 JUMPER 75060501P0
P804-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R813 R851-R854
P804-SEMICONDUCTORS
D801 4822 130 83067 DIODE D3SB 20
V=200V IO=3.0A
HE20020290
D802 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D807 4822 130 82421 DIODE 1D3 1A 200V HD20002710
Q801 4822 209 60826 IC NJM7812FA +12V 1A HC38912090
Q806 TRS. 2SD1415 HT41415100
P804-MISCELLANEOUS
F801 K KS 4822 117 10158 RES. 1Ω ± 5% 1/4W GG05010140
F801 U FUSE T2A 250V TR5 NO.19374 FS20200210
F802 K KS 4822 117 10158 RES. 1Ω ± 5% 1/4W GG05010140
F802 U FUSE T2A 250V TR5 NO 19374 FS20200210
P854-MAIN+B
CIRCUIT BOARD
P854-CAPACITORS
C851 4822 126 12453 CER. 0.01µF +80%-20% E 500 DK18103560
C852 4822 126 12453 CER. 0.01µF +80%-20% E 500 DK18103560
C853 ELECT 56000µF 71V X2 EI56907110
C854 4822 126 12453 CER. 0.01µF +80%-20% E 500 DK18103560
C857 4822 124 90357 ELECT. 2.2µF M 50V RA-2 OA22505020
P854-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
P854-SEMICONDUCTORS
D851 DIODE D25XB60 HE20029290
D853 4822 130 82421 DIODE 1D3 HD20002710
D854 4822 130 82421 DIODE 1D3 HD20002710
