79
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PB04-PRIMARYCIRCUIT
BOARD [F U] VERSION
PB04-CAPACITORS
CB01 U 4822 122 33276 CER. 0.01µF ±20% DE7150 F DK17103840
CB02 U 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB03 U 4822 122 33276 CER. 0.01µF ±20% DE7150 F DK17103840
PB04-RESISTORS
RB01 U 2.2MΩ ± 10% 1/2W FOR UL RC10225820
RB02 U ROTOR 2.2Ω 7W
TEMP. FUSE
NQ15022070
RB05 U ROTOR 2.2Ω 7W
TEMP. FUSE
NQ15022070
PB04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RB03[U] RB04[U]
PB04-SEMICONDUCTORS
DB01 U 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB02 U 4822 130 82421 DIODE 1D3 1A 200V HD20002710
QB01 U 4822 130 42682 DIG.TRS. DTA144ES UN4113
47K 47K
BA10002000
QB02 U 4822 130 61666 TRS. C3419 O Y 40V 0.8A
PC=1.2W 5W
HT334192A0
PB04-MISCELLANEOUS
FB01 U FUSE 12A 250V
UL CSA MITI NO.314
FS11200440
FB02 U FUSE 630MA 250V
UL CSA FBM
FS10063360
JB03 U JACK 2P AC OUTLET
CCT1304-0212
YJ04002040
LB02 U 4822 280 80773 RELAY VS24MB-NR
TV-8 SEMKO LISTED
LY10240240
LB03 U 4822 280 80773 RELAY VS24MB-NR
TV-8 SEMKO LISTED
LY10240240
PB54-PRIMARY CIRCUIT
BOARD [K KS] VERSION
PB54-CAPACITORS
CB51 K KS 4822 122 33276 CER. 0.01µF ±20% DE7150 F DK17103840
CB52 K KS 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB53 K KS 4822 122 33276 CER. 0.01µF ±20% DE7150 F
SPARK KILLER
DK17103840
PB54-RESISTORS
RB52 K KS ROTOR 2.2Ω 7W
TEMP. FUSE
NQ15022070
RB55 K KS ROTOR 2.2Ω 7W
TEMP. FUSE
NQ15022070
PB54-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RB53 RB54
PB54-SEMICONDUCTORS
DB51 K KS 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB52 K KS 4822 130 82421 DIODE 1D3 1A 200V HD20002710
QB51 K KS 4822 130 42682 DIG.TRS. DTA144ES UN4113
47K 47K
BA10002000
QB52 K KS 4822 130 61666 TRS. 2SC3419 O.Y
40V 0.8A PC=1.2W
HT334192A0
PB54-MISCELLANEOUS
FB51 K KS 4822 070 36302 FUSE T6.3A 250V BS LISTED FS10630850
FB52 K KS 4822 070 32001 FUSE T200mA 250V
BS LISTED
FS10020850
LB52 K KS 4822 280 80773 RELAY VS24MB-NR
TV-8 SEMKO LISTED
LY10240240
LB53 K KS 4822 280 80773 RELAY VS24MB-NR
TV-8 SEMKO LISTED
LY10240240
PB74-POWER SW
CIRCUIT BOARD
CB71 4822 122 33276 CER. 0.01µF ±20% DE7150 F DK17103840
SB71 PUSH SWITCH SDDLB1
POWER TV-5
SP01012460
PL04-CVBS VIDEO SELECTOR
CIRCUIT BOARD
PL04-CAPACITORS
CL01 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL02 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL03 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL04 JUMPER 75060501P0
CL05 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL07 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL08 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL09 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL10 JUMPER 75060501P0
CL11
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL23
CL24 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CL25
CL26
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL31
CL32 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CL33 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CL34 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL35 4822 124 41537 ELECT. 220 UV M 6.3V RA-2 OA22700620
CL36 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL37 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CL38 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL39 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL40 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL41 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CL42 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL43 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL44 4822 122 40617 CER. 0.1µF ±5% DD38104010
CL46 K KS 4822 126 10362 CER. 22pF ±5% DA15220110
CL47 K KS 4822 126 11553 CER. 15pF ±5% DA15150120
CL48 U 4822 122 33792 CER. 10pF ±5% DA15100120
CL49 4822 126 11591 CER. 24pF ±5% CH 50V BLK DD15240300
CL50 4822 126 10362 CER. 22pF ±5% DA15220110
CL52 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL53 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CL54 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL55 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL56 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL57 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL58 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL59 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CL60 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL61 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CL62 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL63 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL64 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL65 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CL66 JUMPER 75060501P0
CL67 UBL 4822 126 10362 CER. 22pF ±5% ±5% DA15220110
CL67 UGL 4822 126 10362 CER. 22pF ±5% ±6% DA15220110
CL68 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL69 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL70 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
