Marantz sr-18 u - Page 54

80
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CL71
JUMPER 75060501P0
CL74
CL75 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL79 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL80 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL81 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL82 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL83 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL84 4822 125 50384 TRIM. 20pF CT12000200
CL86 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CX84 4822 124 22277 ELECT. 470µF M 16V OA47701620
PL04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CL51 CL76-CL78
CL87-CL97[KS]
PLASTIC FILM CAPACITOR
±5% 50V :
PL04-RESISTORS
RL01 4822 111 41355 75Ω ± 5% 1/6W GD05750160
RL03 4822 111 41355 75Ω ± 5% 1/6W GD05750160
RL05 4822 111 41355 75Ω ± 5% 1/6W GD05750160
RL07 4822 111 41355 75Ω ± 5% 1/6W GD05750160
RL09 4822 111 41355 75Ω ± 5% 1/6W GD05750160
RV51 4822 050 21021 100Ω ± 5% 1/2W GG05101120
PL04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RL02 RL04 RL06
RL08 RL10-RL15 RL18-RL26
RL28-RL43 RV52 RV53
PL04-SEMICONDUCTORS
DL07 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DV01 4822 130 82421 DIODE 1D3 HD20002710
DV02 4822 130 82421 DIODE 1D3 HD20002710
DV03 4822 130 82421 DIODE 1D3 HD20002710
DV51 4822 130 82421 DIODE 1D3 HD20002710
DV52 4822 130 82421 DIODE 1D3 HD20002710
DV53 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QL01 IC MM1140XF HC10083550
QL02 IC BA7612N HC10201210
QL03 IC BA7649A G-1 VIDEO SW HC10179210
QL04 IC BA7613N HC10202210
QL05 IC BA7649A G-1 VIDEO SW HC10179210
QL06 IC BA7613N HC10202210
QL07 4822 209 16846 IC NJU3718L HC10171090
QL08 IC NJM2244
3IN SW 75Ω DRIVER
HC10119090
QL09 IC OSD HzLC74781 HC10377030
QL10 K KS 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QL11 K KS 4822 130 61189 DIG.TRS. DTC114TS UN4215
10K
BA20004000
QL12 K KS 4822 130 61189 DIG.TRS. DTC114TS UN4215
10K
BA20004000
QL14 IC NJM2244
3IN SW 75Ω DRIVER
HC10119090
QL15 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QL16 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL17 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QL18 IC TC74HC132AP HC713205D0
QL19 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QV51 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QV52 4822 130 63634 TRS. 2SA1837 Q Y HT118372A0
PL04-MISCELLANEOUS
JL01
4822 265 31299 TERMINAL 3P RCA PIN YT02030340
JL03 YELLOW X 3 AU
JL04 4822 265 10729 TERMINAL YKC21-3740 YT02080130
JL05 4822 290 81598 TERMINAL 2P RCA JACK
YKC21-3255 GOLD
YT02021130
JL06 4822 290 81638 TERMINAL 14X14 RA 1L1P BLK YT02010790
LL01 4822 157 62922 CHOKE COIL CHOKE 33µH J LC13333800
LL02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LL03
JUMPER 75060501P0
LL08
LV01 4822 280 20501 RELAY MR62-24SR 24V LY20240410
LV02 4822 280 20501 RELAY MR62-24SR 24V LY20240410
LV03 4822 280 20501 RELAY MR62-24SR 24V LY20240410
XL01 K KS 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
XL02 4822 242 80288 CRYSTAL AT49 14.31818MHz JX14001260
PL74-AUX INPUT
CIRCUIT BOARD
PL74-CAPACITORS
CL75 KS 4822 126 11568 CER. 470pF ±10% CHIP DK96471300
CL76 KS 4822 126 11568 CER. 470pF ±10% CHIP DK96471300
CL77 KS 4822 122 33777 CER. 47pF ±5% CHIP DD95470300
CL78 KS 4822 122 33777 CER. 47pF ±5% CHIP DD95470300
CL79
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CL82
CL83 4822 124 23112 ELECT 10µF 16V EQ10601630
CL84 4822 111 41305 RES. 0Ω GD05000140
CL88 4822 111 41305 RES. 0Ω GD05000140
CL89 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CL90 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CL91
4822 111 41305 RES. 0Ω GD05000140
CL98
PL74-RESISTORS
RL75 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RL76 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RL77 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RL78 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RL79
4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RL82
RL83 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RL84 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RL85 4822 051 30759 CHIP 75Ω ± 5% 1/16W NN05750610
RL86 4822 051 30759 CHIP 75Ω ± 5% 1/16W NN05750610
RL88 4822 051 30759 CHIP 75Ω ± 5% 1/16W NN05750610
PL4-SEMICONDUCTOR
QL75 4822 209 71451 IC NJM4558M Y HC10011090
PL74-MISCELLANEOU
JL75 TERMINAL RCA JACK 3P &
S-TERMINAL AUX
BY04040030
