81
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PM01-HDAM CIRCUIT BOARD
PM01-RESISTOR
RM09 4822 100 20681 TRIM. 2.2kΩ RA02220780
PM01-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RM01-RM08
PM01-SEMICONDUCTORS
DM01
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
DM05 30V 0.1A
QM01 4822 130 42839 F.E.T. 2SK369BL HF203691B0
QM02 4822 130 42839 F.E.T. 2SK369BL HF203691B0
QM03 4822 130 43233 TRS. 2SC2240 HT322402A0
QM04 4822 130 42949 TRS. 2SA970 HT109702A0
QM05 4822 130 42949 TRS. 2SA970 HT109702A0
QM06 4822 130 43233 TRS. 2SC2240 HT322402A0
PM04- HDAM CIRCUIT BOARD
PM04-CAPACITORS
CM21 4822 124 90358 ELECT. 22µF M 16V OA22601620
CM22 4822 124 90358 ELECT. 22µF M 16V OA22601620
CM23 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CM24 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CM25 4822 121 42708 FILM 330pF 100V ECQ-P DF15331550
CM26 4822 121 42708 FILM 330pF 100V ECQ-P DF15331550
CM27 4822 121 42712 FILM 100pF 100V DF15101550
CM28 4822 121 42712 FILM 100pF 100V DF15101550
CM29 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CM30 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CM31 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CM32 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
PM04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN21-RMRM24
RM27-RM40
PM04-SEMICONDUCTORS
DM21 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DM22 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QM21 4822 130 42949 TRS. 2SA970 HT109702A0
QM22 4822 130 42949 TRS. 2SA970 HT109702A0
QM23 4822 130 43233 TRS. 2SC2240 HT322402A0
QM24 4822 130 43233 TRS. 2SC2240 HT322402A0
QM25 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QM26 4822 130 43283 TRS. 2SC2705 O Y HT327052A0
QM27 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QM28 4822 130 42999 TRS. 2SA1145 O Y HT111452A0
QM29 UNIT & H-IC NEW HDAM KH269J1010
QM30 UNIT & H-IC NEW HDAM KH269J1010
PS04-A-FUNC/PRE SUPPLY
CIRCUIT BOARD KIT
PS04-CAPACITORS
CG01
4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
CG06
CG09 4822 124 22277 ELECT. 470µF M 16V OA47701620
CQ01 JUMPER 75060501P0
CQ02 JUMPER 75060501P0
CQ03 JUMPER 75060501P0
CQ08 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CQ09 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CQ10 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS01
4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CS14
CS15 4822 124 22571 ELECT. 10µF M 16V RA-2 OA10605020
CS16 4822 124 22571 ELECT. 10µF M 16V RA-2 OA10605020
CS17 4822 124 90358 ELECT. 22µF M 16V RA-2 OA22601620
CS18 4822 124 90358 ELECT. 22µF M 16V RA-2 OA22601620
CS19
4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CS22
CS23 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CS24 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CS25
4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
CS30
CS31 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CS32 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CS33 4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
CS34 4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
CS35 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CS36 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
CS55 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS56 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS57 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CS58 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CS59 KS
4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS62 KS
CS63 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CS64 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CS65 KS
4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS70 KS
CS73 KS
4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS76 KS
CS79 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS80 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS81 JUMPER 75060501P0
CS82 JUMPER 75060501P0
CS83 JUMPER 75060501P0
CS84 4822 122 40617 CER. 0.1µF +80 -20% DD38104010
CS85 4822 122 40617 CER. 0.1µF +80 -20% DD38104010
CS86 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CS87 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CS88 4822 122 40617 CER. 0.1µF +80 -20% DD38104010
CS89 4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
CS90 4822 124 22274 ELECT. 4.7µF M 50V RA-2 OA47505020
CS93 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS94 KS 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CS97 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CS98 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CS99 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
C809 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C810 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C811 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C812 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C813 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C814 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C815 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C816 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C819 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C820 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C821 ELECT 13000µF M 16V RE3 EA13901670
C824 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C825 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C826 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C827 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C828 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
To Next Page
