Marantz sr-18 u - Page 56

82
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C830 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C832 ELECT 470µF 63V EA47706310
C833 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C834 ELECT. 47µF M 35V RA-2 OA47603520
C835 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C836 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C840 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
C841 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C843 4822 124 90355 ELECT. 100µF M 50V RA-2 OA10705020
C844 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C845 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C847 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C848 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C851 4822 124 41538 ELECT. 220µF 35V OA22703520
C852 4822 124 90357 ELECT. 2.2µF 50V OA22505020
PS04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C823 C824 C849 CG07[KS]
CG08[KS] CQ06 CQ07
CS37-CS54[KS] CS71[KS]
CS72[KS] CS91[KS] CS92[KS]
CS95[KS] CS96[KS]
ELECTROLYTIC CAPACITOR
±20% :
PS04-RESISTORS
RG15 4822 115 90166 FUSE 10Ω ±2% 1/4W NF02100140
RS96 JUMPER 75060501P0
RS97 JUMPER 75060501P0
R804 4822 117 10158 1Ω ± 5% 1/4W GG05010140
R807 4822 053 10102 1kΩ ± 5% 1W GA05102010
R811 4822 111 90731 FUSE 47Ω ±2% 1/4W NF02470140
R817 4822 115 90167 FUSE 100Ω ±2% 1/4W NF02101140
R818 JUMPER 75060501P0
PS04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R806 R808-R810
R812 R814-R816 R819
RG01-RG06 RG09-RRG14
RG16-RG20 RQ25-RQ30
RS01-RS96 RS98 RS99
PS04-SEMICONDUCTORS
DG01 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DG02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DG03 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DS01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DS02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D803
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D806
D808 4822 130 83438 DIODE D5SB-20 5A 200V HE20016290
D810 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D811 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D812 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D813 4822 130 81729 ZENER DIODE MTZJ33D HD33301000
D814 4822 130 80273 ZENER DIODE 8.2V
RD8.2JB2 MTZJ8.2C
HD30821000
D815
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D825
D826 DIODE 1GWJ43 HD20031050
D827 JUMPER 75060501P0
D828 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D829 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D830 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QG01 IC ELE.VOL.TC9459N HC10443050
QG02 4822 209 83631 IC NJM4558D-D HC10008090
QG03 4822 130 63634 TRS. 2SA1837 Q.Y HT118372A0
QG04 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QG05 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QG06 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QG07 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QS01
4822 209 83631 IC NJM4558D-D HC10008090
QS11
QS12 4822 209 32552 IC LC78211 HC10308030
QS13 4822 209 32553 IC LC78212 HC10309030
QS14 4822 209 32553 IC LC78212 HC10309030
QS15 4822 209 32552 IC LC78211 HC10308030
QS16 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QS17
4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QS20
QS21 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QS22 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QS23 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QS24 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QS25 4822 209 83631 IC NJM4558D-D HC10008090
QS26 4822 130 90347 PHOTO UNIT PC-817
PHOTO CUPLER 1PAIR
HW10006320
QS27 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
Q802 IC L780S15 +15V 1A HC38915030
Q803 4822 209 31864 IC NJM7915FA -15V 1A HC39915090
Q804 TRS. 2SD1415 HT41415100
Q805 4822 209 31864 IC NJM7915FA -15V 1A HC39915090
Q807 4822 209 63179 IC NJM7905FA -5V 1A HC39905090
Q808 4822 209 61533 IC NJM7806FA +6V HC38906090
Q809 4822 130 61666 TRS. 2SC3419 O Y
40V 0.8A PC=1.2W 5W
HT334192A0
Q810 4822 130 41947 TRS. 2SC2458 2SC1704S
2SC3199 ETC.
HT30001000
Q811 4822 209 15921 IC RESET HZS-806D-Z SEIKO HC10077530
Q812 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
Q813 4822 130 60588 DIG.TRS. DTC114ES ETC BA20001000
PS04-MISCELLANEOUS
JS01 4822 265 10729 TERMINAL 8P RCA PIN JACK YT02080130
JS03 4822 290 61244 TERMINAL 6P RCA PIN JACK YT02060490
JS04 4822 290 61244 TERMINAL 6P RCA PIN JACK YT02060490
JS06 4822 290 61244 TERMINAL 6P RCA PIN JACK YT02060490
JS07 TERMINAL 4P RCA YT02041260
LG01 4822 280 20501 RELAY MR62-24SR 24V LY20240410
L801 RELAY FTR-F1AA024T LY20240460
PT04-SPK. TERMINAL
CIRCUIT BOARD
PT04-CAPACITORS
CN51 KS
4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CN58 KS
