83
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PT04-SEMICONDUCTORS
DN51 4822 130 82421 DIODE 1D3 HD20002710
DN52 4822 130 82421 DIODE 1D3 HD20002710
DN53 4822 130 82421 DIODE 1D3 HD20002710
PT04-MISCELLANEOUS
JN54 K KS TERMINAL SPK. 4P RR BB IEC YT01040830
JN54 U 4822 290 81673 TERMINAL SPK. 4P RR BB YT01040710
JN55 K KS TERMINAL SPK. 4P BB RR IEC YT01040840
JN55 U 4822 290 81674 TERMINAL SPK. 4P BB RR YT01040720
LN51 4822 280 10305 RELAY VB-18MBU-565-UL3 LY20180020
LN52 4822 280 10305 RELAY VB-18MBU-565-UL3 LY20180020
LN53 4822 280 10305 RELAY VB-18MBU-565-UL3 LY20180020
PT74-CENTER SPEAKER
TERMINAL CIRCUIT BOARD
PT74-CAPACITORS
CN71 KSBL 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CN71 KSGL 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
PT74-MISCELLANEOUS
JN71 K KS TERMINAL T6976 2P SPK. YT01020390
JN71 U TERMINAL T6543 2P SPK. YT01020370
PU04-FRONT/FL DISPLAY/
SWITCH CIRCUIT BOARD
PU04-CAPACITORS
CU01 4822 126 11558 CER. 0.1µF +80%-20% 50V DA17104110
CU02 4822 126 11558 CER. 0.1µF +80%-20% 50V DA17104110
CU03 4822 126 11558 CER. 0.1µF +80%-20% 50V DA17104110
CU04 4822 126 10935 ELECT 100µF 6.3V EJ10700610
CU05
4822 126 10364 CER. 100pF ±10% DA16101110
CU08
CU09 4822 122 40586 CER. 10000pF ±20% DA17103110
CU10 4822 122 40586 CER. 10000pF ±20% DA17103110
CU11 4822 126 11558 CER. 0.1µF +80%-20% 50V DA17104110
CU12 4822 126 11558 CER. 0.1µF +80%-20% 50V DA17104110
CU13 CER. 1000pF +-10% DK16102300
CU14 RES. 100kΩ ± 5% 1/6W GD05104160
PU04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RU01-RU09
RU11-RU19 RU21-RU29 RU31
RU34-RU48 RU51-RU63
PU04-SEMICONDUCTORS
DU01
4822 130 11363 L.E.D. LT3K44B GREEN 30MA HI10095320
DU06
DU07 L.E.D. HLMF-K200 #2UL RED HI10005340
DU08 L.E.D. HLMF-K200 #2UL RED HI10005340
DU09 L.E.D. HLMF-K200 #2UL RED HI10005340
DU10
4822 130 11363 L.E.D. LT3K44B GREEN 30MA HI10095320
DU17
DU18 L.E.D. HLMF-K200 #2UL RED HI10005340
DU20 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DU21 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QU01 4822 209 90244 IC UPD16311GC-AB6
FTD DRIVER
HC10283060
QU02 4822 209 16846 IC NJU3718L HC10171090
QU03
4822 130 41947 TRS. 2SC2458 2SC1740S HT30001000
QU06 2SC3199 ETC.
QU07 4822 130 63211 DIG.TRS. DTA114TS UN4115
10K
BA10004000
PU04-MISCELLANEOUS
SU01
PUSH SWITCH EVQ11L05R SP01013370
SU26
SU32 ROTARY ENCODER
FOR MASTER
SR02010070
SU33 ROTARY ENCODER
FOR INP. SELECT
SR02010080
VU01 DISPLAY UNIT SVA-12MM20 HQ31201920
PU74-STANDBY LED
CIRCUIT BOARD
CU71 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
RU71 RES. 680Ω ± 5% 1/6W GD0568160
DU71 L.E.D. HLMF-K200 #2UL RED HI10005340
PU84-IR SENSOR
CIRCUIT BOARD
CU81 4822 122 40588 CER. 0.022µF TP050F223Z DA17223110
CU82 4822 124 80087 ELECT 220µF 6.3V EJ22700610
QU81 4822 209 16157 PHOTO UNIT PNA4655M00XB
IR SENSOR
HW10005020
PU94-GYRO ENCODER
CIRCUIT BOARD
CU91 4822 122 40617 CER. 0.1µF +80 -20% DD38104010
RU91 RES. 330Ω ± 5% 1/6W GD05331160
QU91 4822 130 11143 PHOTO UNIT GP1A06 2PHASE
PHOTO INTERRUPTER
HW10033320
PW04-HEADPHONE
CIRCUIT BOARD
CW01 4822 122 40586 CER. 0.01µF +80%-20% DA17103110
CW02 4822 122 40586 CER. 0.01µF +80%-20% DA17103110
CW03 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CW04 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
PY04-µ-COM CIRCUIT BOARD
PY04-CAPACITORS
CY01 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CY02 4822 124 23056 ELECT 47µF 10V EJ47601010
CY04 5322 126 11583 CER. 0.01µF ± 10% B CHIP DK96103200
CY07 4822 126 13303 CER. 1µF +80%-20% 10V CHIP DK98105200
CY08 5322 126 11583 CER. 0.01µF +80%-20% CHIP DK96103200
CY09 5322 126 11583 CER. 0.01µF +80%-20% CHIP DK96103200
CY10 5322 126 11583 CER. 0.01µF +80%-20% CHIP DK96103200
CY11
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CY19
CY25 5322 126 11578 CER. 1000pF ±10% B 50V CHIP DK96102300
CY26 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CY30 BIG ELECT 1F 5.5V
DB-5R5D105
EX10500530
PY04-RESISTORS
RY01 4822 051 30479 CHIP 47Ω ± 5% 1/16W NN05470610
RY02 4822 116 83819 CHIP 18kΩ ± 5% 1/16W NN05183610
RY03 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RY04 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RY05 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RY06
4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RY11
To Next Page
