MAIN
MAIN PCB ASS'Y
※Parts indicated b
"ns
"on this table cannot be su
lied
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4000-4004 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 5
D4007 963201500530S D,SWITCHING 1N4148 K000414800050S 1 *
D4008 963203500300D D,RECTIFIER BRIDGE DIODE BRIDGE D10SB60 600V/10A STRAIGHT TYPE K047100600220S 1
D4009,4010 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 2
D4013 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4014 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4016 963201500530S D,SWITCHING 1N4148 K000414800050S 1 *
D4017 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4019 963201500530S D,SWITCHING 1N4148 K000414800050S 1 *
D4020 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4022 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4023 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4025 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4026 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4027-4030 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 4
D4031,4032 963201500530S D,SWITCHING 1N4148 K000414800050S 2 *
D4033-4035 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 3
D4037 963201500530S D,SWITCHING 1N4148 K000414800050S 1 *
D4039-4044 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 6
IC4000 00D2631100005 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4001 00D2631099006 IC,LINEAR-REGULATOR KIA7905PI,20W-TO220IS MOLD J126790500070S 1
IC4002 00D2631104001 IC,LINEAR-REGULATOR BA08T 8V TO220FP LOW-DROP POSITIVE VOLTAGE REG J126080000020S 1
IC4003 00D2631100005 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4004 00D2631251006 IC,LINEAR-REGULATOR KIA7908PI,20W-TO220IS J126790800060S 1
IC4005 963232100450S IC,LINEAR OP NJM4580CG SOP8 J121458000050S 1
Q4005-4010 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 0.2W/SC-59 ISAHAYA J522102371210S 6
ZD4002 963202500330D D,ZENER ZJ6.8B-0.5W/5MA-52MM SEMTECH K06006R844522S 1
ZD4157,4158 963202500290D D,ZENER ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 2
RESISTOR GROUP
R4000,4001 963125010110S R,METAL FILM 100PPM 470-J,2W-R.REEL C060047166060S 2
R4002 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4003 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4004 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4005 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4006 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4007 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4008 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4009 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4010 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4011 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4012 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4013 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4014 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4015 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4016 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 1
R4017-4020 nsp R,CARBON FILM 20-J,1/5W-52RE-AX C00002006P520S 4
R4025-4027 963125500070D R,METAL FILM 100PPM 1.1K-J,1W-R.REEL C060011265050S 3
R4029 nsp R,METAL FILM 100PPM 10K-J,1/4W-R.REEL C060103063050S 1
R4035 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R4036-4038 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 3
R4039,4040 nsp R,CHIP THICK 82K-J,1/16W-1608REEL C20008236M160S 2
R4041 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4042 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R4043 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4044,4045 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 2
R4046 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4047 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4048 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R4049 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4052 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R4056 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R4057 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4058 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4059 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R4060 nsp R,CHIP THICK 330K-J,1/16W-1608REEL C20003346M160S 1
R4061 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R4062 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4063 nsp R,CHIP THICK 3.3K-J,1/16W-1608REEL C20003326M160S 1
R4064 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4065 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160S 1
R4066,4067 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4069 963129501010S R,CEMENT MPR 0.01-J/5W W14*H18 9MM PITCH C144R01069000S 1
R4070 nsp R,CARBON FILM 20-J,1/5W-52RE-AX C00002006P520S 1
CAPACIITORS GROUP
C4000 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1
C4001 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4003 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1
C4004 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4006,4007 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 2
C4008 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4010,4011 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 2
C4012 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4014 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4016,4017 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 2
C4018 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4020 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1
C4021 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4023-4025 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 3
C4027 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4027 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4028 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1
C4030 963133502350S C,FILM POLYESTER MI-0.047UF-J/100V-5RE HMM473J2AP050T DAEHUNG D02047316C250S 1
C4032 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4032 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4035 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4035 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4038 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4038 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4041 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4041 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4044 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4044 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4047 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL U, K D011102777160S 1
C4047 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL N D011104577160S 1
C4049 nsp C,ELECT GE 85C 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
1
