FRONT
FRONT PCB ASS'Y
※Parts indicated b
"ns
"on this table cannot be su
lied
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4400 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4401 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4403-4405 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 3
D4406,4407 963209003510S D,ESD CHIP CDS3C05HDMI1 CERADIODE ESD FOR HDMI 1608REEL K067030500010S 2
D4408 963209500020S D,ESD CHIP CDS3C15GTA 1608REEL CERADIODE ESD B72500D0150A060 K067031500010S 1
D4409-4416 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 8
D4703 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
IC4400 963231101200S IC,LINEAR-REGULATOR NJM2887DL3-TE2 TO-252-5 LOW-DROP VOL REGULATOR J126288700010S 1
IC4401,4402 963232100450S IC,LINEAR OP NJM4580CG SOP8 J121458000050S 2
IC4700 00D2631286903 IC,LINEAR-REGULATOR PQ120DNA1ZPH 12V 1A SC-63 J126120010010S 1
IC4701 236810090504S IC,LOGIC-INTERFACE ILX3232D 3V3 RS232 INTERFACE TRANSCEIVER SOP16 J046323200020S 1
LED4406,4407 963263101060S LED,ROUND BL-BUF4V2-HS-NP-AV-FP3.5-TBF19.5C RED LED K500032001250S 2 *
LED4408 963263100510S LED,ROUND WEJ3290W-R2H0-BA 3PI RED/YELLOW GREEN BI-COLOR K500032451010S 1
Q4403 00D9630226705 SEMI,TR/GE NPN 2SC KTC1027Y,1W/TO92L-REEL J5021027Y0020S 1
Q4405-4409 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 5
Q4410 943215500030S SEMI,CHIP TR/PNP 2SA RT1P441C 0.2W/SC-59 ISAHAYA J520104411210S 1
ZD4400 nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040S 1
ZD4401 963202500420S D,ZENER ZJ18B-0.5W/5MA-52MM SEMTECH K06018R044522S 1
ZD4402 963202500430S D,ZENER ZJ24B-0.5W/5MA-52MM SEMTECH K06024R044522S 1
ZD4403,4404 963202500310D D,ZENER ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 2
ZD4407 963202500310D D,ZENER ZJ5.1B-0.5W/5MA-52MM SEMTECH K06005R144522S 1
ZD4700 963202500400S D,ZENER ZJ16B-0.5W/5MA-52MM SEMTECH K06016R044522S 1
RESISTOR GROUP
R4403 nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040S 1
R4405 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4406 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4409 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R4411 nsp R,CHIP THICK 75K-J,1/16W-1608REEL C20007536M160S 1
R4415 nsp R,CHIP THICK 150K-J,1/16W-1608REEL C20001546M160S 1
R4416 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4418 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4423 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R4425 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R4426 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4429 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R4430-4432 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 3
R4433 nsp R,CHIP THICK 120K-J,1/16W-1608REEL C20001246M160S 1
R4434 nsp R,CHIP THICK 1.2K-J,1/16W-1608REEL C20001226M160S 1
R4435 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4437 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4438 nsp R,CHIP THICK 1.2K-J,1/16W-1608REEL C20001226M160S 1
R4439 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R4441 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4442,4443 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 2
R4444 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4445 nsp R,CHIP THICK 300-J,1/16W-1608REEL C20003016M160S 1
R4446 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R4447 nsp R,CHIP THICK 390-J,1/16W-1608REEL C20003916M160S 1
R4448 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4450-4454 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 5
R4455 nsp R,CHIP THICK 18K-J,1/16W-1608REEL C20001836M160S 1
R4456,4457 nsp R,CARBON FILM 4.7K-J,1/5W-52RE-AX C00004726P520S 2
R4458 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R4459 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4460 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4461 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4462 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4465,4466 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 2
R4467,4468 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R4469 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 1
R4470 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4471,4472 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 2
R4473 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4474,4475 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R4476 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4477,4478 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R4479 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4481 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R4483,4484 nsp R,CARBON FILM 4.7K-J,1/5W-52RE-AX C00004726P520S 2
R4485,4486 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 2
R4489,4490 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 2
R4708,4709 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 2
R4710 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4711 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4714 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4721 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
CAPACIITORS GROUP
C4411 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4412 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4413 nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040S 1
C4414 963133502390S C,ELECT GE 85C 220UF-M/63V,10*16-5RE SHL SY D040221088050S 1
C4416 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4418 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4419 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4421 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C4422 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4424 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4426 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4427-4429 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 3
C4431,4432 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C4433 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4434 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C4435 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4436 nsp C,CERAMIC CHIP HIK Y5V0.047UF-Z/50V-1608REEL D011473597160S 1
C4437,4438 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C4440,4441 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 2
C4442,4443 nsp C,CERAMIC CHIP T.C COG470PF-J/50V-1608REEL D010471167160S 2
C4444 nsp C,CERAMIC CHIP T.C COG82PF-J/50V-1608REEL D010820167160S 1
C4445 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4446 nsp C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C4447 nsp C,CERAMIC CHIP HIK X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4448 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4449 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4450 nsp C,CERAMIC CHIP HIK X7R)0.047UF-K/25V-1608REEL D011473774161S 1
C4451 nsp C,CERAMIC CHIP HIK Y5V0.047UF-Z/50V-1608REEL D011473597160S 1
3
