VIDEO
VIDEO PCB ASS'Y
※Parts indicated b
"ns
"on this table cannot be su
lied
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D5617 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
IC5001 963235100700S IC,MONITOR SW NJM2595M-TE1 DMP16 5-INPUT 3-OUTPUT VIDEO SWITCH J171259500010S 1
IC5002 963235100630S IC,MONITOR SW NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
Q4219 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5625,5626 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q5628 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 0.15W/SC-59 REEL ISAHAYA J522305200050S 1
Q5629 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q5630 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
RESISTOR GROUP
R5002 nsp R,CHIP THICK 82-J,1/16W-1608REEL C20008206M160S 1
R5003 nsp R,CHIP THICK 1.8K-J,1/16W-1608REEL C20001826M160S 1
R5007,5008 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 2
R5009 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5011 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 1
R5013,5014 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 2
R5015,5016 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R5017,5018 nsp R,CHIP THICK 160-J,1/16W-1608REEL C20001616M160S 2
R5019,5020 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R5021,5022 nsp R,CHIP THICK 160-J,1/16W-1608REEL C20001616M160S 2
R5023,5024 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R5025,5026 nsp R,CHIP THICK 160-J,1/16W-1608REEL C20001616M160S 2
R5033-5035 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 3
R5036 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5037-5039 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 3
R5718 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 1
R5719 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R5720 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160S 1
R5736 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R5737 nsp R,CHIP THICK 18K-J,1/16W-1608REEL C20001836M160S 1
R5740 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
CAPACIITORS GROUP
C5008-5010 nsp C,CERAMIC CHIP T.C COG68PF-J/50V-1608REEL D010680167160S 3
C5011 nsp C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5012 nsp C,CERAMIC CHIP T.C COG68PF-J/50V-1608REEL D010680167160S 1
C5013,5014 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C5015,5016 nsp C,CERAMIC CHIP T.C COG68PF-J/50V-1608REEL D010680167160S 2
C5017,5018 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C5019,5020 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C5021 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C5022 nsp C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5023-5025 nsp C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 3
C5026-5028 nsp C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 3
C5029 nsp C,ELECT GE 85C 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C5030 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C5031 nsp C,ELECT GE 85C 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C5032 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C5048 963133502380S C,FILM POLYESTER MI-0.1UF-J/100V-5RE HMM104J2AP050T DAEHUNG D02010416C250S 1
C5051 963133502380S C,FILM POLYESTER MI-0.1UF-J/100V-5RE HMM104J2AP050T DAEHUNG D02010416C250S 1
C5663 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C5678,5679 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 2
OTHER PARTS GROUP
BKT5001,5002 nsp BRACKET AVRX2200WBKE3BURRING HOLE SPCC t0.8+SN A4/S 401021019610DS 2 *
CLAMP300 nsp CLAMP HMX9800(ON) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4002 nsp CN,WAFER 1.25B-2-15Y 15P BtoB SOCKET(FEMALE) P=1.25MM L109125421510S 1
CN4003 nsp CN,WAFER 1.25B-2-19Y 19P BtoB SOCKET(FEMALE) P=1.25MM L109125421910S 1
CN5000 nsp CN,WAFER 1.25B-2-25Y 25P BtoB SOCKET(FEMALE) P=1.25MM L109125422510S 1
CN5003 nsp CN,WAFER 1.25B-2-11Y 11P BtoB SOCKET(FEMALE) P=1.25MM L109125421110S 1
CP3401 nsp CN,WAFER 1.25B-2-25A 25P BtoB HEADER(MALE) P=1.25MM L109125322510S 1
CP3403 nsp CN,WAFER 1.25B-2-21A 21P BtoB HEADER(MALE) P=1.25MM L109125322110S 1
CP4605 nsp CN,WAFER 1.25B-2-17A 17P BtoB HEADER(MALE) P=1.25MM L109125321710S 1
CP5000 nsp CN,WAFER 1.25B-2-25A 25P BtoB HEADER(MALE) P=1.25MM L109125322510S 1
CP5003 nsp CN.WAFER 2.5MM YMAW025-08R DIP RA L102025080010S 1
! F5005 963652500120S FUSE GLASS TUBE 20MM T1.25A/250V-IVBSUCPCcUR S506 N751501251160S 1
F5005A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F5005B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
! F5006 963652010500S FUSE GLASS TUBE 20MM T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5006A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F5006B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
! F5007 963652010500S FUSE GLASS TUBE 20MM T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5007A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F5007B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
! F5008 963652010500S FUSE GLASS TUBE 20MM T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5008A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F5008B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
! F5009 963652010500S FUSE GLASS TUBE 20MM T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5009A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
F5009B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
JACK5000 963643101620D TER,RCA 3PIN RCA-303B1-01(YL,YL,YL) G606303B1010YS 1
JACK5001-5003 963643101630D TER,RCA 3PIN RCA-303B1-08(GN,BL,RD) G606303B1080YS 3
JACK5005 963646012090S TER,RCA 2PIN RCA-206B-02(OR,OR) G601206B0200YS 1
5
