SMPS
SMPS PCB ASS'Y
※Parts indicated b
"ns
"on this table cannot be su
lied
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4140-4146 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 7
! D4147 203050019501S D,FAST RECOVERY AP01C-V1 52RE-AX FAST RECOVERY RECTIFIER DIODES K050000015000S 1
D4148 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4149 963204500210D D,SCHOTTKY S30SC6MT 60V 30A TO-3P(MTO-3PT) SHINDENGEN K120300600010S 1
D4150 963201500530S D,SWITCHING 1N4148 K000414800050S 1 *
IC4140 943231102160S IC,LINEAR POWER TOP268VG eDIP-12 OFF-LINE POWER SUPPLY IC J122268001010S 1
! IC4142 00D2623047008 PHOTO,COUPLER PC123X2YFZ (DIP4P SHARP) K614123000010S 1
IC4143 212050010508S IC,LINEAR-REGULATOR KIA2431AP,0.7W TO-92 J126243118010S 1
TR4140 943229500110S SEMI,FET CHIP INK0010AC1 N-CH MOSFET SC-59 ISAHAYA J543001012010S 1
TR4142 963213500170D SEMI,TR/GE NPN 2SC KTC3198G,0.6W/TO92-REEL J5023198G0000S 1
U4000 23981007450AS IC,LINEAR-RESET PST8448UR SYSTEM RESET SC-82AB MITSUMI J125844800010S 1 3
ZD4147-4149 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM SEMTECH U K06039R044522S 3
ZD4150 963202500970S D,ZENER ZJ27B-0.5W/5MA-52MM SEMTECH K06027R044522S 1
ZD4151-4157 963202500350D D,ZENER ZJ22B-0.5W/5MA-52MM SEMTECH K06022R044522S 7
ZD4158 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM SEMTECH K06039R044522S 1
ZD4159 963202500320D D,ZENER ZJ5.6B-0.5W/5MA-52MM SEMTECH K06005R644522S 1
ZD4160 963202501020S D,ZENER ZJ7.5B-0.5W/5MA-52MM SEMTECH U K06007R544522S 1
ZD4160 963202500340D D,ZENER ZJ15B-0.5W/5MA-52MM SEMTECH N, K K06015R044522S 1
ZD4162-4164 963202500960S D,ZENER ZJ12B-0.5W/5MA-52MM SEMTECH K06012R044522S 3
RESISTOR GROUP
R4141,4142 nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520S 2
R4143 nsp R,CARBON FILM 330K-J,1/5W-52RE-AX C00003346P520S 1
R4145 nsp R,CHIP THICK 1M-J,1/16W-1608REEL C20001056M160S 1
R4147 nsp R,CHIP THICK 270K-J,1/16W-1608REEL U C20002746M160S 1
R4147 nsp R,CHIP THICK 56K-J,1/16W-1608REEL N, K C20005636M160S 1
R4148,4149 nsp R,CARBON FILM 2.2M-J,1/5W-52RE-AX U C00002256P520S 2
R4150 nsp R,CARBON FILM 1M-J,1/5W-52RE-AX U C00001056P520S 1
R4151 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R4152 nsp R,CHIP THICK 10K-J,1/16W-1608REEL U C20001036M160S 1
R4152 nsp R,CHIP THICK 20K-J,1/16W-1608REEL N, K C20002036M160S
R4153 nsp R,CARBON FILM 6.8-J,1/5W-52RE-AX C0006R806P520S 1
R4154 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R4155 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4156 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4157 nsp R,CARBON FILM 56-J,1/5W-52RE-AX C00005606P520S 1
R4158 nsp R,CARBON FILM 3.3K-J,1/5W-52RE-AX C00003326P520S 1
R4159 nsp R,CARBON FILM 5.6K-J,1/5W-52RE-AX C00005626P520S 1
R4160 nsp R,CHIP THICK 22K-F,1/16W-1608REEL C20002234M161S 1
R4161 nsp R,CHIP THICK 6.8K-D,1/16W-1608REEL C20006821M160S 1
R4163 nsp R,CHIP THICK 47-F,1/16W-1608REEL C20004704M161S 1
R4164 nsp R,CARBON FILM 1M-J,1/5W-52RE-AX C00001056P520S 1
R4165 963125012630S R,METAL FILM 100PPM 22-J,1W-5REEL C060022065050S 1
CAPACIITORS GROUP
C4000 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4001 nsp C,CERAMIC CHIP HIK X7R0.015UF-K/50V-1608REEL D011153777160S 1
! C4140,4141 963134011730S C,CERAMIC AC(SAFETY) DE1B3KX471KB4BL01 AC250V BULK MURATA D00847127H010S 2
! C4142 963132011940S C,CERAMIC AC(SAFETY) DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 1
! C4143 nsp C,FILM P.PROPYLENE 0.1UF-K/275V BULK X2 MPX104K3ID2 P=15MM CARLI D02110407H010S 1
C4145 nsp C,CERAMIC CHIP T.C X7R 0.047UF-K/50V-1608REEL D010473777160S 1
C4146 nsp C,CERAMIC CHIP T.C X7R)0.01UF-K/50V-1608REEL D010103777160S 1
C4147 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
! C4148,4149 963132011940S C,CERAMIC AC(SAFETY) DE2F3KY103MB3BM02 AC250V BULK MURATA D008103589010S 2
C4150 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4151 943134501590S C,ELECT GE 105C 100UF-M/200V,16*20 BULK NHA SY U D04110108G000S 1
C4151 963134010200S C,ELECT GE 105C 100UF-M/400V,18*31.5 BULK NHA SY N, K D04110108K000S 1
C4152 963134010210S C,ELECT GE 105C 47UF-M/25V,5*11-5RE NXA SY D041470084050S 1
C4153 963132010120S C,CERAMIC AC(SAFETY) DEHR33A102KB2B D00810207Q010S 1
C4154 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4155 963134010190S C,ELECT GE 105C 10UF-M/50V,5*11-5RE NXA SY D041100087050S 1
! C4156 963133502500S C,CERAMIC AC(SAFETY) DE1E3KX332MB4BN01F D00833208H010S 1
C4159 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4160 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C4161 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C4162 963134010220S C,ELECT GE 105C 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
C4163 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C4164,4165 963134010220S C,ELECT GE 105C 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 2
C4166 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C4169 963133502510S C,FILM POLYESTER ST-0.0022UF-J/100V-5RE HPE222J2AP050T DAEHUNG D02022206C250S 1
OTHER PARTS GROUP
BKT4141 nsp BRACKET AVRX2200WBKE3BURRING HOLE SPCC t0.8+SN A4/S 401021019610DS 1 *
BKT4143 nsp BRACKET AVRX2200WBKE3 SPCC t0.8+SN plating A4/SCREW 401021019600DS 1
BKT4144 nsp SHIELD SR5010U1B SPTE t0.3/SMPS 3070210836000S 1
CN4141 nsp CN,WIRE 150MM/6P YMH025-06=CKM2509HV-06 WH1007#22 L000151060180S 1
! CP4142 nsp CN.WAFER 7.92MM LWB1143-02P 7.92MM HEADER,VER,2CKT L108011430210S 1
! F4140 963652010510S FUSE GLASS TUBE 20MM T2A/250V-IVBSUCPCcUR S506 U N751502001160S 1
! F4140 963652010500S FUSE GLASS TUBE 20MM T1.6A/250V-IVBSUCPCcUR S506 N, K N751501601160S 1
★F4140 ns
LABEL AVR1611 T1.6AL/250V /FUSE K 5507000006790
1
! F4141 963652010520S FUSE GLASS TUBE 20MM T6.3A/250V-IVBSUCPCcUR S506 U N751506301160S 1
! F4141 963652010910S FUSE GLASS TUBE 20MM T3.15A/250V-IVBSUCPCcUR S506 N, K N751503151160S 1
★F4141 ns
LABEL AVR1911 T3.15AL/250V /FUSE K 5507000006800
1
FC4140A nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
FC4140B,4141 nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 2
FC4141B nsp HOLDER,FUSE CLIP PI5.2-REEL G645000050010S 1
! JK4140 963641011240S SOCKET,POWER AC AC0152PPA66 AC INLET 2P_REV1.0 CCC G4300152P0001S 1
! L4140 963111101060S COIL,LINE FILTER SQ2014 27mH VERTICAL TYPE LINE FILTER U D320201405510V 1
! RLY4140 963682100290D RELAY JZC-36FD/005-HLT 23.8*9.5*24.5mm G680060103030S 1
T4140 963102100540S TRANS,SWITCHING EER2525 SW TRANSFORMER E060252505510V 1
8
