Marantz SR5010/U1B - Page 184

EXPLODED
REF No. Part No. Part Name Remarks Q'ty New Ver
Q410 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q422 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q434 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q446 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q458 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q470 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q482 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
Q409 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q421 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q433 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q445 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q457 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q469 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q481 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q404 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
Q416 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
Q428 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
Q440 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
Q452 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
Q464 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
Q476 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
SCREW
A nsp SCREW,TAP TITE NR1606U1B(MARANTZ) +2S 3*10 B-TITE CZN /BH
B020030101B10S
B020030101B10S
V
30
B nsp SCREW,TAP TITE () +2S 3*6(ROUND) BK/BH
B020230063B10S
B020230063B10S
V
2
C nsp SCREW,TAP TITE KRA4030(K) +2S 3*8 B-TYPE ZNW/BH
B020030081B10S
B020030081B10S
V
32
D nsp SCREW HCD3700 +2S 3*8 ZnY WASHER PI12
1500001456010
S
1500001456010S
V
1
E nsp SCREW,TAP TITE XHM82K/SYXEV8 +2S 3*8(ROUND) BK/BH B020230083B10SV 8 *
F nsp NUT
G nsp SCREW,TAP TITE ASSY AVR1910BKE3 +3S 4*10 P+S-WASHER(ROUND)BK/BH
B028940101B11S
B028940101B11S
V
4
H nsp SCREW,TAPPING ASSY AVR1404(KE3) +2S 3*14 P(Φ6)S-WASHER ZNY/HH
B018230141H11
D
B018230141H11S
V
21
I nsp SCREW,TAP TITE HCD60M +2S 3*17 B-TYPE ZNW/BH
B020030171B10S
B020030171B10S
V
2
J nsp SCREW AVR3300(E3) +2S 4*8 B-TYPE(DOT) BK/BH
1500040083B10S
1500040083B10S
V
8
K nsp SCREW,TAP TITE AVR3300(E3) +2S 3*10 B-TYPE(DOT) BK/BH
B020030103B11S
B020030103B11S
V
35
L nsp SCREW,TAP TITE VSX925K/CUXCN +3S 3*4 S-TYPE BK/BH B020030043B10SV 11
M nsp SCREW(+3S 3X8 BK/FH) B020930083F10SV 1
N nsp SCREW(+3S 3X8 BK/BH) B020930083B10SV 3
O nsp SCREW HRV4000(K) +2S 3*8 PI9.5 B-TYPE ZNW 1500001206010SV 2
P nsp SCREW,TAP TITE N-70A/JXEV +2S 3*6 B-TYPE ZNW/BH B020030061B10SV 4
★ nsp SPRING NR1605U1BSUS304 PI1.2 PI7.4 A4/KNOB 3720210576000
S
1
★ nsp TAPE DMS3 NO_156(15*30)(A4)/ACETATE CLOTH 1220210059020S 2
★ nsp TAPE NR1606U1B(MARANTZ) NO_156(15X45)SCETATE CLOTH TAPE 1220210059050SV 1
★ nsp BRACKET SR5006U1BSPTH t0.5(CMD1A792) A4/USB 4010215216000S 1
★ nsp HOLDER SR5006U1B(MARANTZ) SPTH t0.5(CMD1A793) A4/FLT 4320211106000S 1
★ nsp TAPE () NITTO #500,10MM*50M DOUBLE A710000520000S 0.06
27
