Marantz SR5010/U1B - Page 54

1.3. File structure on USB Memory
Copy the update les to the USB memory with the following structure.
USB memory root
Model Name Model Area Product ID
SR5010U North America (U) 100100410100
SU5010N Europe (N) 100100410200
SR5010K China (K) 100100410500
+ rmwares
+ X00100XXXXXX
+ APLD.bin
+ DSP.bin
+ enc_update.xml
+ GUI.bin
+ IMG.bcd
+ MAIN.bin
+ SBL.bcd
1.4. Insert the USB memory into the USB port
NOTE : Remove the LAN cable from this unit when performing updates.
1.5. Start the update
While holding down buttons "
TUNER PRESET CH +
" and "
STATUS
" simultaneously, press the power button to turn on
the power.
1.6. Display during USB update
After around half minutes, display shows the following message.
Display
FLD
L1
U S B U p d t
L2
S t a r t
L3
1.7. Press the "ENTER" key on the remote control unit or this unit
Then start Firmware Update.
Display
FLD
L1
U p d a t e
L2
F i l e
L3
C h e c k
Download firmware
in USB flash drive.
54
