85
Speaker connection
Connecting 7.1-channel speakers using front wide speakers
The illustration on the right shows a connection example for performing 7.1-channel playback using the
front wide speakers.
To perform 7.1-channel playback using the front wide speaker, set “Assign Mode” to “Front Wide” in
steps 3 to 5 for “Set up “Amp Assign”” (vpage91).
Cables used for connections
Audio cable (sold separately)
Speaker
cable
Subwoofer
cable
When using Audyssey DSX
®
, install front wide speakers.
NOTE
•For speaker cable connections, see page82.
•For speaker impedance , see page82.
FL FR
C
SL
SR
SW
FWR
FWL
Basic version
Advanced version
Information
Advanced version
DVD
