Metering
 Accuracyofallmeteringvaluesassumes25°C,50/60Hzandlessthan20%THD.
Regulator-side Metering
Generator Voltage
Range: 10 Vac to 600 Vac
Accuracy: 0.5 %
Generator Current
Range: 0.1 to 5.000 Aac (5 Aac CTs)
Accuracy: 0.5 %
Power (Apparent, Real and Reactive)
Range: 0 to 5200 VA and W
  0to4160VARleading/lagging
Accuracy: 3.0 %
Power Factor
 Range: 0.6to1.0leading/lagging
Accuracy: 0.02
Frequency
Range: 40 to 75 Hz
Accuracy: 0.2 Hz
Field Voltage
Range: 0 to 200 Vdc
Accuracy: 5.0 %
Field Current
Range: 0 to 8.0 Adc
Accuracy: 0.5 %
Generator-side (Scaled) Metering
Generator Voltage
Range: 10 V to 15 kV
Accuracy: 0.5 %
Generator Current
Range: 0.1 to 5,000 Aac (5 Aac CTs)
Accuracy: 0.5 %
Power (Apparent, Real and Reactive)
Range: 0 to 10 MVA and MW
  0to8MVARleading/lagging
Accuracy: 3.0 %
