Environmental
Operating Temperature: -40° C to +70° C (-40° F to +158° F)
Storage Temperature: -40° C to +85° C (-40° F to +185° F)
Relative Humidity: < 95 %, non-condensating
Ingress Protection: IP52 (front side mounted in conduit box)
IP10 (rear side with protective cover)
Environmental Tests
Humidity: Tested per MIL-STD-705B, Method 711-D
Salt Fog: Tested per MIL-STD-810E
Electromagnetic Compatibility
Immunity: Meets EN 61000-6-2: 2005 Electromagnetic compatibility (EMC) – Part
6-2: Generic standards – Immunity for industrial environments
Emission: Meets EN 61000-6-4: 2007 Electromagnetic compatibility (EMC) – Part
6-4: Generic standards – Emission standard for industrial environments
Electromagnetic Compatibility Tests
Immunity
Electrostatic Discharge (ESD): IEC 61000-4-2
Radiated RF: IEC 61000-4-3
 ElectricalFastTransient(EFT)/Burst:  IEC61000-4-4
Conducted RF: IEC 61000-4-6
Power Frequency and Magnetic Field: IEC 61000-4-8
Emission
Radiated RF: EN 61000-6-4: 2007, 30 MHz to 1000 MHz
Mechanical Tests
Shock: 20 Gs in 3 perpendicular planes
Vibration: 2.5 Gs at 5 to 26 Hz
  0.050”doubleamplitude(27to52Hz)
7 Gs at 53 to 500 Hz
Physical
Weight: 3 lb. (1361 g)
Mating Connectors
 J1: MatingPlugHousing: DeutschDT06-12SB-P012
Mating Plug Wedge Lock: W12S-P012
Mating Plug Terminals: 0462-201-16141
 J2: MatingPlugHousing: DeutschDT06-12SA-P012
Mating Plug Wedge Lock: W12S-P012
Mating Plug Terminals: 0462-201-16141
 J3: MatingPlugHousing: Amp/Tyco172166-1
Mating Plug Terminals: 170366-3
