Marathon Electric DVR 2000E+ - Inbound Messages from ECU1 or ECU2 or ECU3

70
Marathon Electric (a division of RBC Manufacturing Corp.) reserves the right to change specications and this manual without notice.
Revised 06/2011
INBOUND MESSAGES FROM ECU1 or ECU2 or ECU3
RESET VR - This message from an ECU resets the regulator. The regulator responds by clearing any faults and
executing its soft start ramp to a stable regulation point.
Message ID: (0xFF00) Reset VR
Source: ECU1 or ECU2 or ECU3
Message Group: None
PDU Format: 255 (PDU2)
PDU Specific: 0
BYTE 0 BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7
Unused Fixed Fixed Fixed Fixed Fixed Unused Unused
0Xff 0x01 0xA5 0x5A 0x49 0x94 0xFF 0xFF
Byte 0 Unused Unused
Byte 1-5 FIXED This is a fixed constant. If these bytes are not loaded with the given
fixed constants, the reset will not take place.
Byte 6-7 Unused Unused
