SECTION 2 – SPECIFICATIONS
Operating Power
Type: 1-phase, ungrounded PMG
Range: 180 to 240 Vac, 250 to 300 Hz
Burden: 350 VA
 FuseType: Timedelay250V/4.0A
Terminals: 3, 4
Generator Voltage Sensing
 Type: 1-phase/3-phase
 Range: 100to600Vac,50/60Hz
Burden: <1 VA per phase
Terminals: E1, E2, E3
Generator Current Sensing
 Type: 1-phase(BØ)/3-phase
 Rating: 5Aacmaximumcontinuous50/60Hz
Input Impedance: <10 mΩ
Terminals: CT1, CT2 for 1-phase (BØ)
  J2-1,J2-12for3-phase(AØ)
  J2-2,J2-11for3-phase(BØ)
  J2-3,J2-10for3-phase(CØ)
Contact Inputs
Type: Dry Contact
Input Pull-Up Voltage: 3.3 Vdc
 Terminals: DROOP_OFF:  J1-10,J1-4
  UP:  J1-2,J1-4
  DOWN:  J1-3,J1-4
  EXCITATION_OFF: J1-11,J1-4
Fault Contact Output
Type: Form A
Rated Load: 3 A continuous
 Break: 3Aac/0.1Adc
 OperatingVoltage: 240Vac/250Vdcmaximum
 Terminals: J1-6,J1-7
Field Output
Continuous Rating: 75 Vdc, 3.0 Adc
10 Second Forcing Rating
200 Vac Power Input: 150 Vdc, 7.5 Adc
Field Resistance: 18 to 35 *
Terminals: F+, F-
