Marathon Electric DVR 2000E+ - Front Panel Display

38
Marathon Electric (a division of RBC Manufacturing Corp.) reserves the right to change specications and this manual without notice.
Revised 06/2011
FRONT PANEL DISPLAY
The HMI display has three display modes:
1. STATUS mode – the HMI displays the non-editable operating state of the DVR
®
2000E+ as described in
Table 5-2. The display flashes while in STATUS mode.
2. EDIT mode - The HMI displays a multi-layer menu for reading and editing operating parameters of the
DVR
®
2000E+ as described in Table 5-3. The display is steady-on while in EDIT mode.
3. SLEEP mode – The HMI turns off the display after a period of button-press inactivity.
Display Description
(no display) No display is the default mode of the HMI. No display indicates that
the regulator is operating normally, but operating in a sleep mode.
PYN
This display indicates that the regulator is operating normally with
excitation enabled.
O
ff
This display indicates that the regulator is operating normally and
excitation is disabled.
Axxx (where xxx in-
dicates a three-digit
alarm code)
This display indicates that the regulator is in an alarm state. During
this state, the regulator continues to provide excitation if excitation
is enabled. (See Appendix for description of Alarm Codes)
fxxx (where xxx
indicates a three-digit
alarm code)
This display indicates that the regulator is in a fault state. During
this state, the regulator ceases to provide excitation.
(See Appendix for description of Fault Codes)
Table 5-2. DVR
®
2000E+HMI STATUS Mode Display Descriptions
