GENERATOR LINE-TO-LINE VOLTAGES (GENERATOR OUTPUT) – This message contains the root-mean-square
line-to-line voltages for each individual phase at the output of the generator after possible step-up from a potential
transformer.
Message ID (0xFF1B) – Generator Line-to-Line Voltages (Generator Output)
Source: DVR
®
2000E+
Message Group: Metering
PDU Format: 255 (PDU2)
PDU Specific: 27
BYTE 0 BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7
Vab
RMS
(LSB)
Vab
RMS
(MSB)
Vbc
RMS
(LSB)
Vbc
RMS
(MSB)
Vca
RMS
(LSB)
Vca
RMS
(MSB)
Voltage
Units
Unused
0x?? 0x?? 0x?? 0x?? 0x?? 0x?? 0x?? 0xFF
Byte 0 Average Line-to-Line AC RMS Voltage Vab (LSB) – this is the Least Significant Byte
of the average line-to-line AC root-mean-square voltage, Vba.
Byte 1 Average Line-to-Line AC RMS Voltage Vab (MSB) – this is the Most Significant Byte
of the average line-to-line AC root-mean-square voltage, Vba.
Byte 2 Average Line-to-Line AC RMS Voltage Vbc (LSB) – this is the Least Significant Byte
of the average line-to-line AC root-mean-square voltage, Vac.
Byte 3 Average Line-to-Line AC RMS Voltage Vbc (MSB) – this is the Most Significant Byte
of the average line-to-line AC root-mean-square voltage, Vac.
Byte 4 Average Line-to-Line AC RMS Voltage Vca (LSB) – this is the Least Significant Byte
of the average line-to-line AC root-mean-square voltage, Vbc.
Byte 5 Average Line-to-Line AC RMS Voltage Vca (MSB) – this is the Most Significant Byte
of the average line-to-line AC root-mean-square voltage, Vbc.
Byte 6 Voltage Units – an enumerated quantity used to define the scaling for output volt-
ages as follows:
0x00 – scaling for all voltages are 1 bit = 0.1 Vrms
0x01 – scaling for all voltages are 1 bit = 0.1 kVrms
Note: this scaling also applies to output voltages in messages 0xFF19
Byte 7 Unused
