GENERATOR LINE-TO-NEUTRAL VOLTAGES (REGULATOR SENSING) – This message contains the root-mean-
square line-to-neutral voltages for each individual phase at the generator output after possible step-up from a
potential transformer.
Message ID (0xFF3C) – Generator Line-to-Neutral Voltages (Regulator Sensing)
Source: DVR
®
2000E+
Message Group: Metering
PDU Format: 255 (PDU2)
PDU Specific: 60
BYTE 0 BYTE 1 BYTE 2 BYTE 3 BYTE 4 BYTE 5 BYTE 6 BYTE 7
Va
RMS
(LSB)
Va
RMS
(MSB)
Vb
RMS
(LSB)
Vb
RMS
(MSB)
Vc
RMS
(LSB)
Vc
RMS
(MSB)
Unused Unused
0x?? 0x?? 0x?? 0x?? 0x?? 0x?? 0xFF 0xFF
Byte 0 Average Line-to-Neutral AC RMS Voltage Va (LSB) – this is the Least Significant
Byte of the average line-to-neutral root-mean-square voltage, Va. (1 bit = 0.1 Vrms)
Byte 1 Average Line-to-Neutral AC RMS Voltage Va (MSB) – this is the Most Significant
Byte of the average line-to-neutral root-mean-square voltage, Va. (1 bit = 0.1 Vrms)
Byte 2 Average Line-to-Neutral AC RMS Voltage Vb (LSB) – this is the Least Significant
Byte of the average line-to-neutral root-mean-square voltage, Vb. (1 bit = 0.1 Vrms)
Byte 3 Average Line-to-Neutral AC RMS Voltage Vb (MSB) – this is the Most Significant
Byte of the average line-to-neutral root-mean-square voltage, Vb. (1 bit = 0.1 Vrms)
Byte 4 Average Line-to-Neutral AC RMS Voltage Vc (LSB) – this is the Least Significant
Byte of the average line-to-neutral root-mean-square voltage, Vc. (1 bit = 0.1 Vrms)
Byte 5 Average Line-to-Neutral AC RMS Voltage Vc (MSB) – this is the Most Significant
Byte of the average line-to-neutral root-mean-square voltage, Vc. (1 bit = 0.1 Vrms)
Byte 6-7 Unused
