Service manual April 2017 Uber boiler
3.7 FONT TO TILE INSTALLATION INSTRUCTIONS
Make sure all parts are on clean sponges or polystyrene to stop scratching. Build up a
platform so the font can rest on its side at the correct height to be bolted onto the tile.
Now place tape around the 4 sides of the opening in the tile to prevent the tubes rubbing off
the bare metal cut-out.
Insert the locking bracket into the bottom of the Font.(see diagram on next page).
Carefully place the Font against the tile. Loosely screw in the 4 bolts.
