3.7.2 Connecting the Font Tubing:
.
Connect the return silicone tube marked black to the ball valve on the tank. Connect the
other font tube to the thermistor tee piece. Connect the drip tray overflow to the tank
overflow.
Secure all hoses with plastic hose clips, F clips on the tank tit and ball valve, G clips on the
Tee piece. Ensure the hose clips are turned in towards the tank so they do not crash against
the surround panel.
Thermistor T-Piece
Tape on edges to stop
damage to tubes during
installation
